Bosch Spare Parts for Planer GHO 15-82
€3.79
Tax included
Bosch Spare Parts for Planer GHO 15-82
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Planer GHO 15-82 - 3601E94003.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Planer GHO 15-82
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Planer GHO 15-82 - 3601E94003.
In the following table, look for the model of the Planer and the respective parts of the code.
| Planer GHO 15-82/3 601 E94 003 | ||
| # | Part Num. | Description |
| 2 | 2604220480 | Field 230-240V |
| 4 | 1607200158 | Switch |
| 6 | 2600703017 | Grommet Ø6,4-Ø7,2x76 MM |
| 7 | 2601035001 | Cable Clip |
| 9 | 2609132301 | Manufacturer's nameplate GHO 15-82 |
| 12 | 2609120389 | Suppression Capacitor |
| 16 | 2604449055 | Carbon Brush Holder |
| 17 | 2609100087 | Cover |
| 19 | 2910611020 | Tapping Screw DIN 7981-ST3,9x19-C-H |
| 20 | 2609110155 | Screw |
| 26 | 2609110131 | Adjusting Nut |
| 28 | 2609110268 | Pulley |
| 29 | 2609110267 | Pulley |
| 30 | 2609100805 | Handle |
| 31 | 2609100410 | Micro Poli-V-Belt 5PH271 |
| 32 | 2609100024 | Gear Cover |
| 33 | 2609110077 | Compression Spring |
| 35 | 2609100023 | Brush-Cover BLUE |
| 37 | 2609100140 | Cap-Handle |
| 38 | 2609110162 | Ratchet Disc |
| 40 | 2609100028 | Air-Deflector Ring |
| 41 | 2601329053 | Contact Strap |
| 44 | 2603320004 | Square Nut M6 |
| 47 | 2601254000 | Ratchet Spring |
| 49 | 2609100022 | Handle Cover BLUE |
| 57 | 2604448181 | Connecting Cable L=233 MM WHITE |
| 58 | 2604448118 | Connecting Cable L=213 MM BLUE |
| 74 | 2608635341 | Planing Knife |
| 75 | 2603400016 | Set screw |
| 76 | 2603111001 | Gripping Wedge |
| 80 | 2609100088 | Knife Guard |
| 81 | 2609110109 | Spring |
| 654 | 1907950003 | Offset Screwdriver DIN 911 SW2,5 |
| 655 | 2609170013 | Dust Bag |
| 656 | 2608005015 | Stop Bracket |
| 657/1 | 1610210043 | O-Ring 4,0x1,5 MM |
| 657/2 | 2916011014 | Plain Washer DIN 125-A 6,4-ST |
| 657/3 | 2603480003 | Wing Screw M 6x16 MM |
| 657/4 | 1601332018 | Stop Bracket |
| 657/5 | 2910281201 | Round-Head Bolt DIN 603-M6x20 |
| 657/6 | 2609199008 | Wing Nut |
| 801 | 2609199577 | Motor Housing |
| 803 | 2609199269 | Armature 230-240V |
| 805 | 1607000386 | Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-F |
| 808 | 160111A3H3 | Nameplate |
| 810 | 2609120398 | Carbon Brush |
| 813 | 2600905051 | groove ball bearing 7x19x6 |
| 814 | 2600905052 | groove ball bearing 8x22x7 |
| 825 | 2609110174 | Bearing Flange |
| 827 | 2600905051 | groove ball bearing 7x19x6 |
| 855 | 2600905064 | groove ball bearing 10x26x8 |
| 870 | 2609110193 | Planer Head |
