Bosch Spare Parts for Marble Cutting Saw GDC 125
€1.56
Tax included
Bosch Spare Parts for Marble Cutting Saw GDC 125
Bosch original spare parts for to replace broken parts for to fix Marble Cutting Saw Bosch GDC 125 - 3601E48000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Marble Cutting Saw GDC 125
Bosch original spare parts for to replace broken parts for to fix Marble Cutting Saw Bosch GDC 125 - 3601E48000.
In the following table, look for the model of the Marble Cutting Saw and the respective parts of the code.
| Marble Cutting Saw GDC 125/3 601 E48 000 | ||
| 2 | F000607063 | Field 220 V |
| 3 | F000605231 | Armature With Fan 220V |
| 8 | F000616044 | Supporting Disc |
| 9 | 9618082293 | Brake Disc |
| 10 | F000616134 | Hex Socket Head Cap Screw |
| 12 | F000608414 | Suppression Capacitor |
| 13 | 2600905032 | Ball Bearing 7x19x6 |
| 14 | F000615004 | groove ball bearing |
| 16 | F000612082 | Brush Holder |
| 25 | F000618002 | Cylindrical Gear |
| 26 | F000619026 | Spindle |
| 27 | F000613083 | Bearing |
| 28 | F000604013 | Cover Disc |
| 33 | F000603061 | Brush Holder |
| 35 | F000617024 | Cylindrical Gear |
| 36 | F000613053 | Motor Bearing |
| 37 | 1600502011 | Intermediate Ring |
| 38 | F000603029 | Protective Guard |
| 39 | F000603027 | Protective Cover |
| 40 | 9618087099 | Tapping Screw 4x16 MM |
| 42 | 9618086615 | Screw M 4x12 MM |
| 44 | F000600217 | Tapping Screw |
| 45 | F000616166 | Hex Socket Head Cap Screw |
| 46 | F000613064 | Base Plate |
| 48 | F000603060 | Sealing cap |
| 49 | F000615011 | Needle bearing |
| 50 | F000616165 | Hex Nut |
| 52 | F000640007 | O-Ring |
| 53 | F000640008 | O-Ring |
| 54 | 1601025001 | Wire Guide |
| 56 | 2916012014 | Plain Washer A 6,4 DIN 125-ST |
| 58 | F000616053 | Knob |
| 71 | F000620013 | Spring |
| 72 | F000616122 | Detent Pin |
| 73 | 2916080008 | Locking Washer DIN 6799-5-FSt |
| 74 | F000600290 | Time-Delay Switch |
| 98 | F000616394 | Screw |
| 99 | F000616395 | Toothed lock washer |
| 650/6 | F000630036 | Low Pressure Hose |
| 801 | F000601323 | Housing |
| 804 | F000608006 | On-Off Switch |
| 805 | F000609274 | Power supply cord BR 2,00m 2 x 1,00mm H05 VVF |
| 806 | 3600703011 | Grommet Ø9,2-Ø12x120 MM |
| 816 | F000611036 | Carbon Brush |
| 853 | F000634146 | Shut-Off Tap |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GDC 125 - 3601E48000
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N BOSCH:
- BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
