Bosch genuine spare parts for replacing or repairing Percussion Drill UniversalImpact 800 - 3603A31100.
In the following table, look for the model of the Percussion Drill and the respective parts of the code.
| Percussion Drill UniversalImpact 800/3 603 A31 100 | ||
| # | Part Num. | Description |
| 1 | 1600A0085E | Housing |
| 2 | 2609003196 | Field 220-240V |
| 3 | 2609007835 | Armature |
| 4 | 160720032X | Switch |
| 6 | 2609006376 | Grommet Ø6,4-Ø7,2x76 MM |
| 9 | 160111C0PN | Manufacturer's nameplate UniversalImpact 800 |
| 9 | 160111C1ZC | Manufacturer's nameplate UniversalImpact 8000 |
| 9 | 160111C1ZD | Manufacturer's nameplate PSB Universal + |
| 16 | 1600A004KY | Brush Holder |
| 17 | 1600A00Z5U | Turn Element |
| 19 | 2603490022 | Screw 4x16 |
| 20 | 2910611002 | Tapping Screw DIN 7981-ST2,2x9,5-C-H |
| 31 | 1600A00D25 | Change-Over Switch |
| 34 | 1600A004SA | Bearing Bracket |
| 37 | 160630000G | Toothed Gear |
| 39 | 1600A00MH4 | Keyless Chuck |
| 41 | 2609002581 | Compression Spring |
| 45 | 1600A00DC0 | Change-Over Switch |
| 46 | 2609003189 | Retaining snap ring |
| 49 | 2609007046 | Cylindrical Roller |
| 50 | 2916640005 | Spring retaining ring DIN 471-8x0,8 FSt |
| 51 | 16055002AX | Cover |
| 654 | 160202508W | Auxiliary Handle |
| 655 | 2609005615 | Depth-Gauge |
| 805 | 1607000387 | Power supply cord CN 2,65m 2 x 0,75mm H05 W-F |
| 808 | 160111A3Y3 | Nameplate |
| 836 | 1600A011KA | Spindle |
