Bosch Spare Parts for Electric Chain Saw AKE 40-19 S
€1.71
Tax included
Bosch Spare Parts for Electric Chain Saw AKE 40-19 S
Bosch original spare parts for to replace broken parts for to fix Electric Chain Saw AKE 40-19 S - 3600H36F00.1900 Watt motor, 40 cm bar and 12 m / s chain speed, for an excellent quality cut
Weight of only 4.7 kg, for easy handling
Practical Bosch SDS system, for easy tensioning and without the use of tools
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Electric Chain Saw AKE 40-19 S
Bosch original spare parts for to replace broken parts for to fix Electric Chain Saw AKE 40-19 S - 3600H36F00.
In the following table, look for the model of the Electric Chain Saw and the respective parts of the code.
| Electric Chain Saw AKE 40-19 S | ||
| # | Part Num. | Description |
| 1 | 1605190228 | Motor Housing |
| 4 | 1607200193 | Switch |
| 5 | 1604460242 | Power supply cord EU 230V 0,55m 2 x 1,0mm H07 RN-F |
| 6 | 2609005766 | Grommet |
| 7 | 1602002008 | Lever |
| 9 | 1603231020 | Push-Button |
| 12 | 1607328028 | Suppression Filter |
| 21 | 1600390019 | Locking Bolt |
| 22 | 1604617008 | Compression Spring |
| 23 | 1604617015 | Compression Spring |
| 24 | 1605510315 | Protective Shield |
| 25 | 1601098008 | Spiked bumper |
| 27 | 1605133045 | Handle |
| 28 | 1600206038 | Intermediate Ring |
| 29 | 1600300096 | Bushing |
| 30 | 1602319019 | Pusher |
| 31 | 1604431003 | Connecting Cable |
| 32 | 1604431004 | Connecting Cable |
| 33 | 2916650001 | Spring retaining ring DIN 471-10x1MM-FSt |
| 35 | 1606100039 | Shaft |
| 36 | 1604650016 | Extension Spring |
| 37 | 1600205037 | Felt Washer |
| 38 | 2600917006 | Needle bearing |
| 43 | 1605405004 | Oil Reservoir |
| 44 | 1605437003 | Oil Pump |
| 46 | 1603023003 | Rod |
| 47 | 1600590014 | Swivelling Lever |
| 51 | 1604651013 | Clamp Spring |
| 52 | 2916080012 | Locking Washer DIN 6799-9-FSt |
| 53 | 1600328030 | Collar Disc |
| 54 | 1604652020 | Brake Band |
| 55 | 1600590019 | Lever Arm |
| 56 | 1600590016 | Spring Guide |
| 57 | 1600390018 | Lever Carrier |
| 60 | 1600590012 | Pressure Plate |
| 63 | 1604617017 | Compression Spring |
| 65 | 2914211528 | Oval-Head Screw 5x22 |
| 66 | 2914211528 | Oval-Head Screw 5x22 |
| 67 | 2914201506 | Oval-Head Screw 4x18 MM,TORX T20 |
| 68 | 2914201506 | Oval-Head Screw 4x18 MM,TORX T20 |
| 69 | 1600100038 | Friction Washer |
| 70 | 2910601325 | Tapping Screw 4,2x13 |
| 79 | 1601118K69 | Reference Plate |
| 80 | 1601118K63 | Manufacturer's nameplate AKE 40-19 S |
| 82 | 1601010009 | Seal Strip |
| 83 | 1601118A64 | Sticker |
| 653 | 1602317007 | Guide Rail 400 MM |
| 654 | 2609007365 | Saw Chain AKE 40 |
| 655 | 1601015035 | Adjusting Plate |
| 656 | 1603421003 | Countersunk-Head Screw |
| 802 | 1607000A62 | Alternating-Current Motor |
| 808 | 160111A3H3 | Nameplate |
| 810 | 1607014170 | Carbon-Brush Set |
| 818 | 2603410001 | Socket head cap screw M3x6,5-4.8 |
| 821 | 1607000A88 | Housing Section |
| 822 | 1607000884 | Housing Section |
| 823 | 1605133046 | Handle |
| 839 | 1607000A06 | Ring Gear |
| 840 | 1607000885 | Sprocket wheel |
| 842 | 1607431000 | Strainer |
| 843 | 1607000A47 | Reservoir Cap |
| 850 | 1605510329 | Chain Guard |
| 853 | 1605190190 | Dust-Protection Cover |
| 865 | 1607000A89 | Protective Cover |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
