Bosch Spare Parts for Angle Grinder GWS 850 CE
€3.11
Tax included
Bosch Spare Parts for Angle Grinder GWS 850 CE
We are BOSCH original spare parts Dealers at low at unbeatable prices and a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder GWS 850 CE - 0601378703.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Angle Grinder GWS 850 CE
We are BOSCH original spare parts Dealers at low at unbeatable prices and a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder GWS 850 CE - 0601378703.In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder GWS 850 CE/0601378703 | ||
| # | Part Num. | Description |
| 1 | 1619P09772 | Motor Housing |
| 2 | 1604220340 | Field 220-240V |
| 3 | 1604010667 | Armature With Fan 220-240V |
| 3/50 | 1606610141 | Fan |
| 4 | 1607200179 | Switch |
| 6 | 2600703012 | Grommet Ø6,5-Ø6,9x95 MM |
| 7 | 1601302017 | Fastening Clamp |
| 9 | 1611110F57 | Manufacturer's nameplate GWS 850 CE |
| 12 | 2609120008 | Suppression Filter |
| 13 | 2600905032 | groove ball bearing 7x19x6 |
| 14 | 1619P11240 | groove ball bearing |
| 16 | 1619P01811 | Brush Holder |
| 17 | 1604652013 | Spiral Spring |
| 18 | 1604611031 | Compression Spring |
| 22 | 1602319009 | Adjusting Slide |
| 23 | 1602026068 | Switch Handle BLACK |
| 25 | 1605500196 | Housing Cover BLUE |
| 26 | 1600502023 | Intermediate Ring |
| 27 | 1600206025 | Rubber Ring |
| 30 | 1600591024 | Air-Deflector Ring |
| 33 | 1600210041 | O-Ring 42,0x1,1 MM |
| 35 | 1600136016 | Shim 0,1 MM THICK |
| 1600136017 | Shim 0,2 MM THICK | |
| 37 | 1600100033 | Cover Disc |
| 38 | 2609110150 | Crown Gear |
| 39 | 2609110149 | Bevel Gear |
| 45 | 2915011007 | Hex Nut DIN 934-M6-8-A |
| 47 | 2609110052 | Special Screw |
| 48 | 1619P00220 | Torx Oval-Head Screw 3x10 |
| 49 | 1603435068 | Thread-forming tap. Screw DIN 7500, M4x10, SR10.2 |
| 50 | 2910611020 | Tapping Screw DIN 7981-ST3,9x19-C-H |
| 51 | 1607233137 | Speed governor 220V |
| 55 | 2910611022 | Tapping Screw DIN 7981-ST3,9x25-C-H |
| 57 | 2910641081 | Oval-Head Screw DIN7985-M3,5x5-4.8-H |
| 80 | 3600150021 | Sealing disk |
| 650/10 | 2602025067 | Auxiliary Handle M10, Ø32,5x105 MM |
| 650/20 | 1603345043 | Round Nut M14 |
| 650/30 | 1607950052 | Pin-Type Face-Wrench |
| 650/50 | 2605703014 | Clamping-Flange Ø22,3xØ42 MM |
| 650/50/20 | 1600210039 | O-Ring 20,35x1,78 MM |
| 651 | 1605510250 | Protective Cover Ø 125 MM |
| 805 | 1607000385 | Power supply cord EU 2,6m 2 x 1,0 mm |
| 808 | 1619P00640 | Nameplate |
| 810 | 1619P11715 | Carbon-Brush Set |
| 821 | 1605806466 | Gear Housing |
| 828 | 1605805090 | Bearing Flange BLACK |
| 829 | 1600591023 | Air-Deflector Ring |
| 832 | 1603523110 | Grinding Spindle M14, SW17 |
| 840 | 1607000298 | Push-Button BLACK |
| 841 | 1600910018 | Needle bearing Ø8xØ12x8 MM |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
