Bosch Spare Parts for Demolition Hammer GSH 388
€3.99
Tax included
Bosch Spare Parts for Demolition Hammer GSH 388
We are Dealers of BOSCH original spare parts at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Demolition Hammer GSH 388 - 0611388003.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Demolition Hammer GSH 388
We are Dealers of BOSCH original spare parts at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Demolition Hammer GSH 388 - 0611388003.
In the following table, look for the model of the Demolition Hammer and the respective parts of the code.
| Demolition Hammer GSH 388/0 611 388 003 | ||
| # | Part Num. | Description |
| 2 | 1614220122 | Field 230V |
| 4 | 1617200110 | Switch |
| 6 | 1610703053 | Grommet Ø9,7-Ø12x89 MM |
| 7 | 1601302018 | Fastening Clamp |
| 9 | 1611110C06 | Sticker |
| 12 | 1607328052 | Suppression Filter |
| 13 | 1610900026 | groove ball bearing 8x24x8 |
| 14 | 1610905028 | groove ball bearing 12x32x10 |
| 15 | 1616610085 | Fan |
| 16 | 1610499055 | Ratchet Sleeve |
| 17 | 1610241000 | Catch Disk |
| 18 | 1614601030 | Retaining ring |
| 21 | 1610508038 | Protective Cap |
| 22 | 1610591024 | Protection Sleeve |
| 25 | 1612300034 | Stopping Device |
| 27 | 1600591032 | Air-Deflector Ring |
| 28 | 1614621000 | Compression Spring |
| 31 | 1610251006 | Supporting Disc |
| 34 | 1610516013 | Flange |
| 38 | 1615190088 | Covering hood BLUE |
| 42 | 1614336041 | Brush Holder |
| 43 | 1615500303 | Fan Cover |
| 53 | 1610102054 | Support Disc |
| 57 | 1618710073 | Striker |
| 69 | 1610099004 | Retaining Bracket |
| 72 | 1616317062 | Eccentric Cog Wheel |
| 73 | 1615500358 | Housing Cover |
| 75 | 1615132078 | Handle BLUE |
| 81 | 1615132079 | Handle Cover |
| 84 | 160202507H | Auxiliary Handle |
| 85 | 1618040074 | Support clamp |
| 86 | 1613490002 | T-Head Bolt M8x40 MM |
| 87 | 1611316019 | Clamping Band Ø62 MM |
| 95 | 1610210173 | O-Ring 32,0x1,5 MM |
| 104 | 1610210095 | O-Ring 55,0x2,0 MM |
| 111 | 1610290064 | Bushing |
| 112 | 1613300008 | Hex Nut DIN 936-M8x1-8 |
| 113 | 1613435009 | Tapping Screw ST-4,8x57,5-TORX,T20 |
| 116 | 1610311017 | Inner Ring |
| 121 | 1610328018 | Bushing |
| 126 | 2603490022 | Screw 4x16 |
| 131 | 160111C021 | Sticker |
| 138 | 1611015050 | Sealing Frame |
| 141 | 1610290066 | Rotary shaft lip seal |
| 142 | 1610290061 | Rotary shaft lip seal |
| 143 | 1614601021 | Retaining ring DIN 7993-28x2 |
| 145 | 1610119012 | Spring retaining ring |
| 150 | 1614601041 | Retaining ring |
| 154 | 2916660024 | Spring retaining ring 55x2MM, DIN 472 |
| 160 | 1610210172 | Damping Ring |
| 162 | 1610210091 | O-Ring 24,0x4,0 MM |
| 163 | 1610290065 | Seal ring |
| 164 | 1610210144 | O-Ring 22,0x3,0 MM |
| 165 | 1610210153 | O-Ring 25,0x4,0 MM |
| 167 | 1610290062 | Rotary shaft lip seal |
| 171 | 1613435014 | Torx Oval-Head Screw M5x16-TORX,T25 SILVER |
| 172 | 1613435013 | Torx Oval-Head Screw M6x30-TORX,T30 SILVER |
| 174 | 1613435012 | Torx Oval-Head Screw M4,8x25-TORX,T25 SILVER |
| 175 | 2912401018 | Tapping Screw DIN7981-ST3,9x13-C-Z |
| 176 | 1613435012 | Torx Oval-Head Screw M4,8x25-TORX,T25 SILVER |
| 177 | 1603435051 | Tapping Screw ST3,9x32 SILVER |
| 178 | 1604412069 | Connecting Cable |
| 661 | 1615430010 | Grease Tube 30 ML |
| 801 | 1615102154 | Motor Housing BLUE |
| 803 | 1614011083 | Armature 230V |
| 805 | 1617000723 | Power supply cord |
| 806 | 3604477009 | End Splice |
| 808 | 160111A3H5 | Nameplate |
| 811 | 1617014138 | Carbon-Brush Set |
| 817 | 1614652004 | Spiral Spring |
| 818 | 2910011088 | Socket head cap screw DIN 84-AM3,5x12-5.8 |
| 821 | 1617000835 | Bushing |
| 835 | 1617000838 | Hammer Pipe |
| 840 | 1617000837 | Impact Mechanism Housing - DISCONTINUED |
| 841 | 1617000452 | Striker Pin |
| 854 | 1617000442 | Stop Disc |
| 856 | 1617000836 | Hammer Piston |
| 874 | 1617000422 | Holding-Down-Appliance |
| 884 | 1612025055 | Auxiliary Handle Ø62 MM BLACK |
| 886 | 1617000459 | Auxiliary Handle M8 BLACK |
| 890 | 1609244B42 | Mounting Sleeve |
| 892 | 1609244B43 | Bow |
| 895 | 1615430019 | Oil Reservoir 1000 ML |
| 897 | 1617000A15 | Wear and Tear Part Set |
| 898 | 1615437512 | Oil Reservoir 50 ML |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GSH 388 - 0611388003
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N BOSCH:
- BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
