Bosch Spare Parts for Jig Saw GST 150 CE
€1.56
Tax included
Bosch Spare Parts for Jig Saw GST 150 CE
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Jig Saw GST 150 CE - 3601E12000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Jig Saw GST 150 CE
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Jig Saw GST 150 CE - 3601E12000.
In the following table, look for the model of the jig Saw and the respective parts of the code.
| Jig Saw GST 150 CE/3 601 E12 000 | ||
| # | Part Num. | Description |
| 1 | 2605105129 | Housing Section BLUE |
| 2 | 2604220584 | Field 230-240V |
| 3/9 | 2606610089 | Fan |
| 4 | 2607200662 | Switch |
| 6 | 2600703017 | Grommet Ø6,4-Ø7,2x76 MM |
| 7 | 2601035004 | Cable Clip |
| 8 | 2601111171 | Nameplate |
| 9 | 2601113553 | Manufacturer's nameplate GST 150 CE |
| 14 | 2600905112 | groove ball bearing 9x24x7 |
| 16 | 2605807108 | Brush Plate |
| 17 | 1603100036 | Rubber Buffer |
| 18 | 2916660008 | Spring retaining ring DIN 472-24x1,2 MM |
| 19 | 2603490022 | Screw 4x16 |
| 26 | 2600100040 | Shim |
| 27 | 2916080908 | Locking Washer 5 DIN 6799 |
| 31 | 2600101119 | Shim |
| 32 | 2600913040 | Needle-Roller Assembly |
| 33 | 2606320099 | Eccentric Cog Wheel |
| 35 | 2601923015 | Fork Lever |
| 36 | 2601098117 | Counterweight |
| 37 | 2600101047 | Shim 0,3 MM |
| 38 | 2916080909 | Locking Washer DIN 6799-6-FST |
| 41 | 2600917900 | Needle bearing |
| 51 | 2603105131 | Bearing bolt |
| 53 | 2603124156 | Control Shaft |
| 56 | 2602026158 | Rotary Knob BLACK |
| 61 | 2604610140 | Compression Spring |
| 64 | 2601322035 | Straight Pin |
| 80/2 | 2601099198 | Work Board |
| 80/4 | 1613435023 | Thread-forming tap. Screw |
| 84 | 1907950006 | Offset Screwdriver DIN 911-SW5 BLACK |
| 85 | 2601030022 | Profile Beading |
| 87 | 2605500203 | Air Eliminator BLACK |
| 88 | 2600040004 | fixing plate |
| 90 | 2910141201 | Hex Socket Head Cap Screw DIN 912-M6x20-8.8 |
| 95 | 2603101065 | Protecting Cover |
| 97 | 2604448339 | Earth Conductor |
| 98 | 2604448337 | Connecting Cable |
| 99 | 2603410051 | Thread-forming tap. Screw |
| 105 | 2604690056 | Torsion Spring |
| 110 | 2602026161 | Switch Handle |
| 111 | 2601099192 | Adjusting Slide |
| 113 | 1607233560 | Speed governor 220-240V |
| 117 | 2603490023 | Torx Oval-Head Screw 4x20 |
| 654 | 2601099183 | Pad |
| 655 | 2601016093 | Splintering Protector |
| 656 | 2605730055 | Suction Nozzle |
| 657 | 2605510293 | Covering hood |
| 801 | 2602026908 | Cap-Handle BLACK |
| 803 | 2604011394 | Armature 230-240V |
| 805 | 1607000386 | Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-F |
| 810 | 2604321941 | Carbon-Brush Set |
| 810 | 1607000494 | Carbon-Brush Set 10 x 2 604 321 94 |
| 823 | 2605806881 | Gear Housing |
| 845 | 2601321908 | Roller Lever |
| 854 | 2602026909 | Rotary Knob BLACK |
| 860 | 2605808934 | Gear Cover |
| 866 | 1600A00HG2 | Lifting Rod |
| 880 | 2601016905 | Base Plat |
