Bosch Spare Parts for Jig Saw GST 120 E
We are BOSCH original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Jig Saw GST 120 E - 0601510603.
In the following table, look for the model of the jig Saw and the respective parts of the code.
| GST 120 E/0 601 510 603 | ||
| # | Part Num. | Description |
| 5 | 2600101048 | Shim 0,5 MM |
| 6 | 2601923010 | Fork Lever |
| 7 | 2601098087 | Counterweight |
| 8 | 2600913040 | Needle-Roller Assembly |
| 9 | 2606320101 | Eccentric Cog Wheel |
| 10 | 2600101047 | Shim 0,3 MM |
| 12 | 2600200038 | Intermediate Ring |
| 13 | 2600917900 | Needle bearing |
| 14 | 2602026116 | Rotary Knob BLACK |
| 15 | 2600590006 | Ratchet Cap |
| 16 | 2916080908 | Locking Washer 5 DIN 6799 |
| 18 | 2600118013 | Spring retaining ring |
| 19 | 2603105104 | Bearing bolt |
| 20 | 2602305051 | Air Eliminator |
| 22 | 2602026109 | Rotary Knob BLACK |
| 28 | 2602098018 | Tensioning Lever |
| 29 | 2600591022 | Cap-Handle RED |
| 31 | 2608000925 | Base Plate |
| 31/31 | 2608000305 | Base Plate |
| 31/32 | 2601098099 | Work Board |
| 31/33 | 2603421014 | Thread-forming tap. Screw |
| 72 | 2604610042 | Compression Spring |
| 87 | 2603410051 | Thread-forming tap. Screw |
| 102 | 2604220715 | Field 220-240V |
| 103 | 2604011343 | Armature 220-240V |
| 103/9 | 2606610093 | Fan |
| 105 | 2604460311 | Power supply cord EU 4,15m 2 x 1,0mm H05 RN-F |
| 106 | 2600703012 | Grommet Ø6,5-Ø6,9x95 MM |
| 107 | 2601035001 | Cable Clip |
| 109 | 2601116847 | Manufacturer's nameplate GST 120 E |
| 115 | 2603490022 | Torx Oval-Head Screw 4x16 |
| 116 | 2605807108 | Brush Plate |
| 121 | 2603435086 | Tapping Screw |
| 122 | 2603490023 | Torx Oval-Head Screw 4x20 |
| 123 | 2601328073 | Cover Disc |
| 125 | 2607230082 | Speed governor 220-240V |
| 126 | 2605190442 | Mushroom Handle |
| 127 | 2600508050 | Housing Cover |
| 128 | 2601099111 | Adjusting Slide |
| 129 | 2602026107 | Switch Handle |
| 130 | 2603410049 | Thread-forming tap. Screw M4x12 MM |
| 653/4 | 2601016087 | Splintering Protector |
| 654 | 2608000309 | Pad |
| 655 | 2605730040 | Suction Nozzle |
| 656 | 2605510205 | Covering hood |
| 801 | 2605806889 | Gear Housing BLACK |
| 805 | 1607000386 | Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-F |
| 808 | 2601116806 | Nameplate |
| 810 | 2605108912 | Motor Housing |
| 811 | 2600916900 | Locking Washer |
| 816 | 2604321941 | Carbon-Brush Set |
| 817 | 2600905095 | Deep-Groove Ball Bearing 9x24x7 |
| 823 | 2601990907 | Fan Cover |
| 828 | 2601990042 | Tensioning Lever |
| 835 | 2602317900 | Clamping Piece |
| 836 | 2605808929 | Gear Cover |
| 836/86 | 2603101046 | Protecting Cover BLACK |
| 837 | 2601321907 | Roller Lever |
| 866 | 2601990911 | Control Unit |
| 870 | 2600591900 | Cap-Handle |
| 873 | 2601322901 | Carrier |
| 877 | 2600780911 | Lifting Rod |
| 884 | 2600290903 | Seal Kit |
