Annovi Reverberi Parts for Pressure Washer AR4590
Annovi Reverberi Original spare parts at attractive prices never seen on the web, we are a licensed service center with after-sales service able to quickly solve the maintenance or repair any issues for Pressure Washer AR Blue Clean AR4590 - 24426.
In the following tables, look for the spare part and its respective code.
| Pressure Washer AR Blue Clean 4590 - 24426 | ||
| Casing AR4590 - 24426 Pag.1 |
||
| # | Part Num. | Description |
| 1 | 3520091 | Casing |
| 2 | 3523550 | Foot |
| 3 | 3520260 | Fairlead |
| 4 | 3520230 | Wheel |
| 5 | 3520240 | Washer |
| 6 | 3520254 | Protection |
| 7 | 3520170 | Tank |
| 8 | 3520180 | Stopper |
| 9 | 3520070 | Knob |
| 10 | 3520081 | Blue Casing |
| 11 | 3520060 | Handle |
| 12 | 3520870 | Cable |
| 13 | 3523560 | Antivibration |
| Pump 4590 Pag.2 |
||
| 1 | 1344970 | O-Ring |
| 2 | 3520370 | Junction |
| 3 | 2901060 | Injector |
| 4 | 800560 | O-Ring |
| 5 | 1080091 | Spring |
| 6 | 2901070 | Shutter |
| 7 | 1460430 | O-Ring |
| 8 | 1344850 | Head |
| 9 | 1349055 | Valve |
| 10 | 1344770 | Spacer |
| 11 | 1465720 | O-Ring |
| 12 | 1344800 | Stopper |
| 13 | 1344790 | Fork |
| 14 | 850850 | Screw |
| 15 | 620301 | Stopper |
| 16 | 2500280 | Curve |
| 17 | 1342701 | Office |
| 18 | 600180 | O-Ring |
| 19 | 1460151 | Piston |
| 20 | 2021900 | Piston |
| 21 | 1080190 | O-Ring |
| 22 | 600180 | O-Ring |
| 23 | 1080401 | Ring |
| 24 | 820510 | O-Ring |
| 25 | 740290 | O-Ring |
| 26 | 1344870 | Piston Guide |
| 27 | 1343450 | Disk |
| 28 | 1460190 | Spring |
| 29 | 1980220 | Disk |
| 30 | 2500550 | Cotter Pin |
| 31 | 1344881 | Insert |
| 32 | 1980740 | Stopper |
| 33 | 1060120 | Nut |
| 34 | 1345020 | Stopper |
| 35 | 620301 | Stopper |
| 36 | 1344890 | Stopper |
| 37 | 2560870 | O-Ring |
| 38 | 2460180 | O-Ring |
| 39 | 770260 | O-Ring |
| 40 | 1344750 | Piston Guide |
| 41 | 1260440 | Tenuta Water |
| 42 | 1344760 | Ring |
| 43 | 1344050 | Pump Housing |
| 44 | 1260050 | Bushing |
| 45 | 1040710 | O-Ring |
| 46 | 1344060 | Cover |
| 47 | 1260780 | Screw |
| 48 | 880840 | O-Ring |
| 49 | 1343900 | Stopper |
| 50 | 880111 | Tongue |
| 51 | 1341070 | Bearing |
| 52 | 480890 | Ring |
| 53 | 111120 | Ring |
| 54 | 1341080 | Ring |
| 55 | 1340060 | Piston Rod |
| 56 | 1340080 | Plug |
| 57 | 1340070 | Piston |
| 58 | 1260460 | Oil Seal |
| 59 | 600180 | O-Ring |
| 60 | 1341010 | Disk |
| 61 | 1342740 | Piston |
| 62 | 1341020 | Washer |
| 63 | 850670 | Screw |
| 64 | 1340170 | Tree |
| 65 | 1120680 | O-Ring |
| 66 | 600180 | O-Ring |
| 67 | 2022040 | Rod |
| 68 | 2021630 | Spring |
| 69 | 2021650 | Washer |
| 70 | 1260820 | O-Ring |
| 71 | 1344830 | Junction |
| 72 | 42580 | Retrofit Kit TSS |
| 73 | 1349297 | Pre-Assembly Pump |
| 74 | 1349114 | Pre-Assembly Head |
| 75 | 42579 | Valve Kit Adjustment |
| 76 | 3520360 | Junction |
| A | 42566 | Kit Valves |
| B | 2623 | Piston Kit |
| C | 1876 | Kit Oil Seals |
| D | 42567 | Kit Kept Water |
| F | 42568 | Gasket Kit |
| Engine 4590 Pag.3 |
||
| 1 | 1260300 | Fan |
| 2 | 1340350 | Estate |
| 3 | 1260760 | Screw |
| 4 | 1340320 | Shield |
| 5 | 1340340 | Bearing |
| 6 | 3523500 | Connector |
| 7 | 1260490 | Washer |
| 8 | 2020570 | Screw |
| 9 | 1340780 | Gasket |
| 10 | 1341831 | Box |
| 11 | 1261560 | Screw |
| 12 | 1261560 | Screw |
| 13 | 1340280 | Band |
| 14 | 1263520 | Condenser |
| 15 | 1342040 | Fan Cover |
| 16 | 2029752 | Pre-Assembly Box TSS |
| 17 | 2022201 | Fork |
| 18 | 44534 | Motor |
| 19 | 1340660 | Fairlead |
| 20 | 1340640 | Ferrule |
| 21 | 1340650 | Fairlead |
| 22 | 1262400 | Washer |
| Boiler 4590 Pag.4 |
||
| 1 | 3520630 | Resistance |
| 2 | 3520620 | Plug |
| 3 | 3520610 | Band |
| 4 | 3520600 | Disk |
| 5 | 3520590 | Disk |
| 6 | 3520330 | Cover |
| 7 | 3520790 | Valve |
| 8 | 3520800 | Fan - Substituited by Kit 3520800 |
| 9 | 3520320 | Box - Substituited by Kit 3520800 |
| 10 | 3520810 | Boiler Motor - Substituited by Kit 3520800 |
| 11 | 3520310 | Cover |
| 12 | 3523570 | Boiler |
| 13 | 3520860 | Transformer |
| 14 | 3520770 | Cable |
| 15 | 3520650 | Gasket |
| 16 | 3520660 | Element |
| 17 | 3520670 | Support |
| 18 | 3520680 | Nozzle |
| 19 | 3520690 | Flange |
| 20 | 3520710 | Plate |
| 21 | 3520700 | Electrode |
| 22 | 3520820 | Cover |
| Circuit Petrol 4590 Pag.5 |
||
| 1 | 3522760 | Pump |
| 2 | 3520730 | Hose |
| 3 | 3520740 | Band |
| 4 | 3520750 | Tube |
| 5 | 3520760 | Filter |
| 6 | 3520750 | Tube |
| Circuit Water 4590 Pag.6 |
||
| 1 | 3521470 | Tube |
| 2 | 3520490 | Fork |
| 3 | 3520420 | Fitting |
| 4 | 3520430 | Piston |
| 5 | 3520440 | Spring |
| 6 | 3520450 | Bushing |
| 7 | 3520460 | O-Ring |
| 8 | 3520510 | Fork |
| 9 | 3520480 | Stopper |
| 10 | 3520500 | O-Ring |
| 11 | 3520540 | Ring |
| 12 | 3520240 | Washer |
| 13 | 3520410 | O-Ring |
| 14 | 3520530 | Fitting |
| 15 | 3520580 | Washer |
| 16 | 3520570 | Screw |
| 17 | 3520930 | Thermostat |
| 18 | 3520470 | O-Ring |
| Circuit Electric 4590 Pag.7 |
||
| 1 | 3520270 | Knob |
| 2 | 3520280 | Thickness |
| 3 | 3520300 | Element |
| 4 | 3520290 | O-Ring |
| 5 | 3520340 | O-Ring |
| 6 | 3520350 | Fuse Holder |
| 7 | 3520850 | Switch |
| 8 | 3520840 | Card |
| Accessories 4590 Pag.8 |
||
| 1 | 41047 | Gun |
| 2 | 50690 | Lance |
| 3 | 3104 | Nozzle |
| 4 | 40320 | Tank |
| 5 | 3520550 | High Pressure Hose |
