AR Farmer's Division Parts for Pressure HOT 1310
€30.06
Tax included
AR Farmer's Division Parts for Pressure HOT 1310
We have the original AR Farmer's Division Parts for Pressure Washer HOT 1310 - 24398 Parts, the diagram and parts list and tool repair that help you need to get your tools running like new again.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
AR Farmer's Division Parts for Pressure HOT 1310
We have the original AR Farmer's Division Parts for Pressure Washer HOT 1310 - 24398 Parts, the diagram and parts list and tool repair that help you need to get your tools running like new again.
Fix Your Pressure Washer HOT 1310. All Spares are original and can be supplied at Low and discounted prices. Our Parts are Genuine and with a Guarantee.
In the following tables, look for the spare part and its respective code.
| Casing HOT 1310 - 24398 Pag.1 |
||
| # | Part Num. | Description |
| 1 | 3160720 | Yellow Casing |
| 2 | 3160100 | Accessory Cases |
| 3 | 2100300 | Screw |
| 4 | 3160110 | Accessory Cases |
| 5 | 3164380 | Wheel |
| 6 | 3163890 | Knob |
| 7 | 3163290 | Washer |
| 8 | 3163880 | Protection |
| 9 | 3161920 | Stopper |
| 10 | 3163900 | Tank |
| 11 | 3160760 | Wheel |
| 12 | 3163910 | Stirrup |
| 13 | 3161550 | Tank |
| 14 | 3162010 | Ring |
| 15 | 3161940 | Protection |
| 16 | 3160090 | Accessory Cases |
| 17 | 2360360 | Screw |
| 18 | 3160710 | Casing |
| Pump HOT 1310 - 24398 Pag.2 |
||
| 1 | 680570 | Screw |
| 2 | 1381550 | Washer |
| 3 | 1260250 | Level Indicator |
| 4 | 1260430 | Ring |
| 5 | 1780690 | Disk |
| 6 | 1140450 | O-Ring |
| 7 | 1260162 | Stopper |
| 8 | 960160 | O-Ring |
| 9 | 1269050 | Complete Valve |
| 10 | 880830 | O-Ring |
| 11 | 1320340 | Ring |
| 12 | 1780720 | Watertight |
| 13 | 1320351 | Piston Guide |
| 14 | 1260420 | O-Ring |
| 15 | 1260450 | Watertight |
| 16 | 1260460 | Oil Seal |
| 17 | 1260164 | Stopper |
| 18 | 1266740 | Oil Seal |
| 19 | 1260790 | Ring |
| 20 | 1320370 | Bearing |
| 21 | 1320330 | Bush |
| 22 | 1320010 | Pump Housing |
| 23 | 880130 | Stopper |
| 24 | 1260110 | Nut |
| 25 | 1260100 | Washer |
| 26 | 1260210 | Piston |
| 27 | 480480 | O-Ring |
| 28 | 1260091 | Disk |
| 29 | 1260070 | Piston |
| 30 | 1260080 | Plug |
| 31 | 1260760 | Screw |
| 32 | 1329010 | Cover |
| 33 | 1260040 | Oil Seal |
| 34 | 1320140 | Piston Rod |
| 35 | 740290 | O-Ring |
| 36 | 1980740 | Stopper |
| 37 | 180101 | O-Ring |
| 38 | 820361 | Stopper |
| 39 | 1322780 | Shaft |
| 40 | 1380520 | Tab |
| 41 | 1320020 | Head |
| 42 | 1269299 | Pre-Assembly Head |
| 43 | 1260750 | Ring |
| 44 | 51230 | Capacitor |
| 45 | 44272 | Engine |
| 46 | 20566 | Pre-Installing Pump |
| 47 | 50068 | Gasket |
| 48 | 1200430 | Screw |
| A | 1864 | Valve Kit |
| B | 2629 | Piston Kit |
| C | 1872 | Oil Seals Kit |
| E | 42479 | Kit Held Water |
| Valve HOT 1310 - 24398 Pag.3 |
||
| 1 | 1980470 | Screw |
| 2 | 1980300 | Nut |
| 3 | 1980390 | Insert |
| 4 | 1980220 | Disk |
| 5 | 1271070 | Spring |
| 6 | 1080041 | Piston |
| 7 | 1080070 | Plug |
| 8 | 1080401 | Ring |
| 9 | 1080250 | O-Ring |
| 10 | 1980210 | Piston Guide |
| 11 | 740290 | O-Ring |
| 12 | 800560 | O-Ring |
| 13 | 880830 | O-Ring |
| 14 | 1271170 | Ring |
| 15 | 1080190 | O-Ring |
| 16 | 1271160 | Piston |
| 17 | 1980200 | Venue |
| 18 | 1470210 | O-Ring |
| 19 | 1540270 | Screw |
| 20 | 390080 | O-Ring |
| 21 | 1540510 | Valve Body |
| 22 | 1140450 | O-Ring |
| 23 | 1540630 | O-Ring |
| 24 | 1540280 | Collector |
| 25 | 880270 | O-Ring |
| 26 | 2260420 | Screw |
| 27 | 1460430 | O-Ring |
| 28 | 1500170 | Bearing |
| 29 | 1080090 | Spring |
| 30 | 394280 | O-Ring |
| 31 | 1540300 | Nut |
| 32 | 1540570 | Junction |
| 33 | 1560490 | Hose |
| 34 | 480480 | O-Ring |
| 35 | 1250280 | Ball |
| 36 | 1560520 | Spring |
| 37 | 23030 | Complete Valve |
| F | 2812 | Seal Kit |
| Water Circuit HOT 1310 - 24398 Pag.4 |
||
| 1 | 3161040 | Manometer |
| 2 | 3164070 | Junction |
| 3 | 3163500 | Tube |
| 4 | 3161110 | Junction |
| 5 | 3162890 | Pressure Switch |
| 6 | 3163850 | Pipe Cleaner |
| 7 | 3161210 | Junction |
| 8 | 3163560 | Filter |
| 9 | 1461470 | Junction |
| 10 | 480440 | O-Ring |
| 11 | 1540050 | Junction |
| 12 | 3162040 | Washer |
| 13 | 3160430 | Junction |
| 14 | 3161080 | Pressure Switch |
| 15 | 3160510 | Junction |
| 16 | 3164400 | Tube |
| 17 | 3161310 | Tube |
| 18 | 3161190 | Junction |
| 19 | 3161260 | Junction |
| 20 | 3160540 | Valve |
| 21 | 3161170 | Junction |
| 22 | 3161150 | Junction |
| 23 | 3161290 | Tube |
| 24 | 3161180 | Junction |
| 25 | 3160480 | Junction |
| 26 | 50713 | Filter |
| 27 | 3161050 | Fairlead |
| 28 | 3163840 | Tube |
| Fuel Circuit HOT 1310 - 24398 Pag.5 |
||
| 1 | 3161900 | Plate |
| 2 | 3161810 | Fan |
| 3 | 3161530 | Engine |
| 4 | 3160300 | Joint |
| 5 | 3160330 | Junction |
| 6 | 3161440 | Cable |
| 7 | 3160320 | Solenoid |
| 8 | 3162910 | Diesel Pump |
| 9 | 3160340 | Hose |
| 10 | 3161460 | Boiler |
| 11 | 3161620 | Tube |
| 12 | 3162060 | Band |
| 13 | 3161520 | Filter |
| 14 | 3161610 | Tube |
| 15 | 3161580 | Tube |
| 16 | 3163920 | Band |
| 17 | 3163540 | Screw |
| Electric Circuit HOT 1310 - 24398 Pag.6 |
||
| 1 | 3161960 | Knob |
| 2 | 3160850 | Switch |
| 3 | 3161990 | Support |
| 4 | 3162080 | Plate |
| 5 | 3160940 | Support |
| 6 | 3160900 | Card - ALB 012 |
| 6 | 3163660 | Card - TSP 16 |
| 7 | 50720 | Thermostat |
| 8 | 3163720 | Fuse Holder |
| 9 | 3160920 | Fuse |
| 10 | 3160930 | Box |
| 11 | 3160860 | Fairlead |
| 12 | 3160870 | Fairlead |
| 13 | 3160800 | Cable |
| Boiler HOT 1310 - 24398 Pag.7 |
||
| 1 | 3162370 | Cap |
| 2 | 3161100 | Junction |
| 3 | 3162030 | Ring |
| 4 | 3161860 | Glass |
| 5 | 3161230 | Junction |
| 6 | 3161840 | Disk |
| 7 | 3161870 | The Nozzle Holder |
| 8 | 3162820 | Nozzle |
| 9 | 3161890 | Electrode |
| 10 | 3161680 | Tube |
| 11 | 3161560 | Support |
| 12 | 3161790 | Cover |
| 13 | 3161780 | Cover |
| 14 | 3161750 | Resistance |
| 15 | 3161430 | Ring |
| 16 | 3161830 | Disk |
| 17 | 3161770 | Cover |
| 18 | 3161450 | Boiler |
| 19 | 50717 | Transformer Danfoss / Fida |
| 20 | 3160830 | Danfoss Cable / Fida |
| 21 | 3163940 | Washer |
| 22 | 3163960 | Nut |
| Accessories HOT 1310 - 24398 Pag.8 |
||
| 1 | 41089 | Gun |
| 2 | 3160160 | High Pressure Tube |
| 3 | 40826 | Lance |
| 4 | 3082 | Nozzle |
