Annovi & Reverberi Parts for Pressure Washer AR 420 - 12355
€24.12
Tax included
Annovi Reverberi Parts for Pressure Washer AR 420 - 12355
We have the original Spares Annovi Reverberi for Pressure Washer AR BC 420 - 12355, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Pressure Washer AR BC 420 All Spares are original and can be supplied at Cheap and discounted prices.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi Reverberi Parts for Pressure Washer AR 420 - 12355
Fix Your Annovi Reverberi for Pressure Washer AR BC 420 - 12355 All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.
In the following tables, look for the spare part and its respective code.
| Pressure Cleaner AR BC 420 - 12355 / Modello 420 (230 V - 50 Hz) | ||
| CASING Pag.1 | ||
| # | Part Num. | Description |
| 1 | 2860088 | Blu Casing |
| 3 | 2440075 | Wheel |
| 4 | 2100300 | Screw |
| 5 | 2860030 | Black casing |
| 6 | 1680190 | Fan cowling |
| 7 | 1261570 | Screw |
| 8 | 2860060 | Bracket |
| 9 | 2440270 | Screw |
| 10 | 2860020 | Black casing |
| 11 | 1682420 | Plug |
| 12 | 2000240 | O-Ring |
| PUMP Pag.2 | ||
| 1 | 1340260 | Filter |
| 2 | 2101000 | Screw |
| 3 | 2100630 | Fitting |
| 5 | 550350 | O-ring |
| 7 | 2109051 | Valve |
| 8 | 850850 | Screw |
| 9 | 2020120 | Piston guide |
| 10 | 880840 | O-ring |
| 11 | 2123 | O-ring + head |
| 13 | 1260760 | Screw |
| 14 | 2256 | Fitting assembly |
| 15 | 2200140 | Water seal |
| 16 | 2020040 | Ring |
| 17 | 2021740 | O-ring |
| 18 | 2560480 | Bushing |
| 19 | 2020030 | Bushing |
| 20 | 1683500 | Oil seal |
| 21 | 2200210 | Screw |
| 22 | 2020150 | Spring |
| 23 | 2020130 | Piston |
| 24 | 2020140 | Ring |
| 25 | 2021570 | Bearing |
| 26 | 2021960 | Fork |
| 28 | 1680680 | O-ring |
| 30 | 1461470 | Fitting |
| 33 | 2223 | TSS pump assembly |
| 34 | 394280 | O-ring |
| 37 | 2101450 | Flange |
| A | 2577 | Valve kit |
| B | 2734 | Piston kit |
| D | 2687 | Seal kit |
| MOTOR Pag.3 | ||
| 1 | 1680250 | Fan |
| 2 | 2020850 | Washer |
| 3 | 1340350 | Seal |
| 4 | 1680035 | Shield |
| 5 | 1261551 | Screw |
| 6 | 850840 | O-ring |
| 7 | 1680670 | Capacitor |
| 8 | 840020 | Ring |
| 9 | 1461430 | Bearing |
| 10 | 1683000 | Wobble plate |
| 11 | 2029721 | TSS box assembly |
| 12 | 2440221 | Box |
| 13 | 2320280 | Switch |
| 14 | 2021480 | Gland |
| 15 | 1343400 | Cable |
| 16 | 4827 | Motor |
| RLW 8M Pag.4 | ||
| 1 | 40438 | Hose reel assembly |
| 2 | 2360150 | Lever |
| 3 | 2100300 | Screw |
| 4 | 2100300 | Screw |
| 5 | 2440490 | Bracket |
| 6 | 2440500 | Hub pin |
| 7 | 2560720 | Screw |
| 8 | 2360230 | Plate |
| 9 | 380420 | Ring |
| 10 | 2620551 | High pressure hose |
| 11 | 2440510 | Hub pin |
| 12 | 391000 | O-ring |
| 13 | 2440540 | Fitting |
| 14 | 2360320 | Ring |
| 15 | 2440480 | Bracket |
| 16 | 820510 | O-ring |
| 17 | 2360310 | Fitting |
| 18 | 2600170 | High pressure hose |
| 19 | 2360510 | Guard |
| 20 | 2360460 | Plate |
| 21 | 2440532 | Handle |
| 22 | 2440290 | Screw |
| STANDARD ACCESSORIES Pag.5 | ||
| 1 | 40356 | Lance Head |
| 2 | 1680220 | O-ring |
| 3 | 40344 | Rotopower head |
| 4 | 40667 | Lance |
| 5 | 40352 | Tank |
| 6 | 40350 | Gun |
| 7 | 40417 | Fixed brush |
| 8 | 880840 | O-Ring |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Annovi Reverberi 420 - 12355
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N AR:
- AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
