Annovi & Reverberi Parts for Pressure Washer AR1010
€11.93
Tax included
Annovi Reverberi Parts for Pressure Washer AR1010
Annovi Reverberi Original spare parts sourced from the manufacturer, with after-sales service at the lowest price on the web for to make maintenance or repair deteriorated parts for Pressure Washer Blue Clean AR1010 - 23890.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi Reverberi Parts for Pressure Washer AR1010
Annovi Reverberi Original spare parts sourced from the manufacturer, with after-sales service at the lowest price on the web for to make maintenance or repair deteriorated parts for Pressure Washer Blue Clean AR1010 - 23890.In the following tables, look for the spare part and its respective code.
| Pressure Washer Blue Clean AR1010 - 23890 | ||
| Casing 1010 | ||
| # | Part Num. | Description |
| 1 | 50601 | Gasket |
| 2 | 51387 | Hood |
| 3 | 1262790 | Pipe Cleaner |
| 4 | 1341030 | Filter |
| 5 | 50531 | Junction |
| 6 | 1123960 | Junction |
| 7 | 51219 | Pressure Switch |
| 8 | 50641 | Frame |
| 9 | 50447 | Spring |
| 10 | 50627 | Wheel |
| 11 | 50628 | Protection |
| 12 | 3260170 | Junction |
| Pump 1010 | ||
| 1 | 960090 | Stopper |
| 2 | 960160 | O-Ring |
| 3 | 1389051 | Complete Valve |
| 4 | 880830 | O-Ring |
| 5 | 880581 | Stopper |
| 6 | 820510 | O-Ring |
| 7 | 820150 | Screw |
| 8 | 1381850 | Washer |
| 9 | 1381071 | Head |
| 10 | 180101 | O-Ring |
| 11 | 820361 | Stopper |
| 12 | 1980740 | Stopper |
| 13 | 740290 | O-Ring |
| 15 | 1381580 | Manometer |
| 16 | 960110 | Ring |
| 17 | 1382740 | Tenuta Water |
| 18 | 1380090 | Piston Guide |
| 19 | 961240 | O-Ring |
| 20 | 880330 | Tenuta Water |
| 21 | 1383130 | Ring |
| 22 | 1382770 | Pump Housing |
| 23 | 1980740 | Stopper |
| 24 | 880130 | Stopper |
| 25 | 2280240 | Bearing |
| 26 | 640030 | O-Ring |
| 27 | 1380120 | Thickness 0.10 Mm |
| 27 | 1380130 | Thickness 0.20 Mm |
| 27 | 1380530 | Thickness 0.25 Mm |
| 27 | 1382810 | Thickness 0.05 Mm |
| 28 | 1380050 | Support |
| 29 | 850370 | Screw |
| 30 | 2280060 | Tree |
| 31 | 1380520 | Tongue |
| 32 | 840370 | Bearing |
| 33 | 180340 | Ring |
| 34 | 1380040 | Support |
| 35 | 962010 | Nut |
| 36 | 962000 | Washer |
| 37 | 1380940 | Piston |
| 38 | 1380950 | Disk |
| 39 | 600180 | O-Ring |
| 40 | 1080401 | Ring |
| 41 | 1380920 | Piston |
| 42 | 1380060 | Plug |
| 43 | 1383050 | Piston Rod |
| 44 | 1780510 | O-Ring |
| 45 | 1260430 | Ring |
| 46 | 1780690 | Disk |
| 47 | 1260250 | Level Indicator |
| 48 | 1140450 | O-Ring |
| 49 | 1789010 | Cover |
| 50 | 1343510 | Screw |
| 51 | 1389270 | Pre-Assembly Head |
| 52 | 20897 | Pre-Assembly Pump |
| A | 2864 | Kit Valves |
| B | 2757 | Piston Kit |
| C | 1855 | Kit Oil Seals |
| E | 1857 | Water Seals Kit |
| G | 1829 | Kit Support Rings |
| Valve 1010 | ||
| 1 | 1560580 | Stopper |
| 2 | 540290 | Screw |
| 3 | 1660210 | Nut |
| 4 | 1560400 | Knob |
| 5 | 1080070 | Plug |
| 6 | 1560420 | Screw |
| 7 | 1560410 | Driving |
| 8 | 1560440 | Disk |
| 9 | 1560350 | Spring |
| 10 | 1080610 | Disk |
| 11 | 1080660 | Plug |
| 12 | 1080540 | Piston |
| 13 | 391000 | O-Ring |
| 14 | 1080640 | Ring |
| 15 | 1560150 | O-Ring |
| 16 | 1560100 | Shutter |
| 17 | 1560140 | Spring |
| 18 | 180101 | O-Ring |
| 19 | 1540272 | Screw |
| 21 | 1560010 | Valve Body |
| 22 | 1080550 | Ring |
| 23 | 480480 | O-Ring |
| 24 | 1560280 | Washer |
| 25 | 1560320 | Piston |
| 26 | 880270 | O-Ring |
| 27 | 1560051 | Junction |
| 28 | 390080 | O-Ring |
| 29 | 1560510 | Nut |
| 30 | 1560530 | Junction |
| 31 | 1560520 | Spring |
| 32 | 1250280 | Sphere |
| 33 | 480480 | O-Ring |
| 34 | 1560490 | Hose |
| 35 | 1540020 | Collector |
| 36 | 1540120 | Washer |
| 37 | 1540090 | Junction |
| 38 | 1560290 | Washer |
| 39 | 20082 | Complete Valve |
| F | 2611 | Gasket Kit |
| Engine 1010 | ||
| 1 | 50068 | Gasket |
| 2 | 1700080 | Plate |
| 3 | 1940410 | O-Ring |
| 4 | 1700740 | Mini-Contactor |
| 5 | 1261570 | Screw |
| 6 | 2360590 | Card |
| 7 | 1460460 | Screw |
| 8 | 1700590 | Nut |
| 9 | 2021480 | Fairlead |
| 10 | 51219 | Pressure Switch |
| 11 | 1341140 | Gasket |
| 12 | 2360730 | Switch |
| 13 | 880270 | O-Ring |
| 14 | 1382380 | Gland |
| 15 | 1261560 | Screw |
| 16 | 1080190 | O-Ring |
| 17 | 1701070 | Box |
| 18 | 1700640 | Cable |
| 19 | 44484 | Engine |
| Accessories 1010 | ||
| 1 | 41052 | Gun |
| 2 | 3160170 | High Pressure Hose |
| 3 | 40826 | Lance |
| 4 | 3095 | Nozzle |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Annovi Reverberi 1010 - 23890
