ARSG Parts for Pressure Washer PROLINER S 1308 - 12462
€19.97
Tax included
ARSG Parts for Pressure Washer PROLINER S 1308 - 12462
We supply AR Farmer's Division original spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer PROLINER S 1308 - 12462.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
ARSG Parts for Pressure Washer PROLINER S 1308 - 12462
We supply AR Farmer's Division original spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer PROLINER S 1308 - 12462.
In the following tables, look for the spare part and its respective code.
| Pressure Washer PROLINER S 1308 - 12462 Spare Parts |
||
| Casing S 1308 - 12462 Pag.1 |
||
| # | Part Num. | Description |
| 1 | 2500044 | Yellow Casing |
| 2 | 2500340 | Cork |
| 3 | 2500310 | Knob |
| 4 | 2500050 | Hook |
| 5 | 2500260 | Bowl |
| 6 | 1680880 | Washer |
| 7 | 2500320 | Wheel |
| 8 | 1260780 | Screw |
| 9 | 2500100 | Plate |
| 10 | 320350 | Screw |
| 11 | 2100300 | Lives |
| 12 | 2600100 | Strain Relief |
| 13 | 2100300 | Screw |
| 14 | 2500020 | Handle |
| 15 | 2500130 | Grommet |
| 16 | 880280 | Screw |
| 17 | 2180300 | Washer |
| 18 | 2500120 | Axle |
| 19 | 2500110 | Tank |
| 20 | 2500010 | Base |
| 21 | 1342040 | Fan Cover |
| 22 | 42113 | Pre-Assembly Plug |
| 23 | 2500330 | Tube Cleaner |
| 24 | 2500330 | Tube Cleaner |
| 25 | 2000230 | Filter |
| 26 | 2509000 | Pre-Assembly Base |
| Pump S 1308 - 12462 Pag.2 |
||
| 1 | 1260780 | Screw |
| 2 | 1344060 | Cover |
| 3 | 1040710 | O-Ring |
| 4 | 1260050 | Bush |
| 5 | 1344050 | Body Pump |
| 7 | 1340170 | Shaft |
| 8 | 880111 | Tongue |
| 9 | 1341070 | Bearing |
| 10 | 480890 | Ring |
| 11 | 111120 | Ring |
| 12 | 1341080 | Ring |
| 13 | 1340060 | Piston Rod |
| 14 | 1340080 | Thorn |
| 15 | 1340070 | Piston |
| 16 | 1260460 | Oil Seal |
| 17 | 600180 | O-Ring |
| 18 | 1341010 | Disk |
| 19 | 1342740 | Piston |
| 20 | 1341020 | Washer |
| 21 | 850670 | Screw |
| 22 | 600180 | O-Ring |
| 25 | 1349265 | Pump Pre-Assembly |
| 26 | 1260440 | Watertight |
| 27 | 770260 | O-Ring |
| 28 | 1342730 | Piston Guide |
| 29 | 1342760 | Watertight |
| 30 | 1342720 | Ring |
| 31 | 1342750 | Disk |
| 32 | 1349053 | Valve |
| 33 | 800560 | O-Ring |
| 34 | 390341 | O-Ring |
| 35 | 1343110 | O-Ring |
| 36 | 1342710 | Nozzle |
| 37 | 1460430 | O-Ring |
| 38 | 1460260 | Piston |
| 39 | 1540140 | Spring |
| 40 | 880270 | O-Ring |
| 41 | 1560090 | Junction |
| 42 | 770570 | O-Ring |
| 43 | 2500190 | Cork |
| 44 | 1461470 | Junction |
| 45 | 1340260 | Filter |
| 47 | 881470 | Screw |
| 48 | 680700 | Screw |
| 49 | 480480 | O-Ring |
| 50 | 1340190 | Cover |
| 51 | 780050 | O-Ring |
| 52 | 620301 | Cork |
| 53 | 1342670 | Head |
| 54 | 851100 | Screw |
| 55 | 1250270 | Spring |
| 56 | 1250280 | Sphere |
| 58 | 3226 | Manometer |
| 59 | 1342700 | Office |
| 60 | 1460430 | O-Ring |
| 61 | 1460150 | Piston |
| 62 | 1343810 | Tablet |
| 63 | 740290 | O-Ring |
| 64 | 1260670 | Junction |
| 66 | 1342680 | Cover |
| 67 | 1381550 | Washer |
| 68 | 1343510 | Screw |
| 69 | 1080190 | O-Ring |
| 70 | 2021900 | Piston |
| 71 | 2500330 | Tube Cleaner |
| 72 | 1080401 | Ring |
| 73 | 1343450 | Disk |
| 74 | 1460190 | Spring |
| 75 | 1343000 | Disk |
| 76 | 2500400 | Insert |
| 77 | 1060120 | Nut |
| 78 | 2500480 | Screw |
| 79 | 2500210 | Knob |
| 80 | 1343900 | Cork |
| 81 | 880840 | O-Ring |
| 82 | 2180740 | Ferrule |
| 83 | 2500280 | Curve |
| 84 | 480560 | O-Ring |
| 85 | 2500200 | Junction |
| 86 | 42391 | Pre-Assembly Head |
| 87 | 42520 | Kit Valve Adjustment |
| A | 1880 | Valve Kit |
| B | 2623 | Piston Kit |
| C | 1876 | Oil Seals Kit |
| E | 2624 | Kit Held Water |
| F | 2767 | Seal Kit |
| Motor S 1308 - 12462 Pag.3 |
||
| 1 | 1260300 | Fan |
| 2 | 1340350 | Sealing |
| 3 | 1260760 | Screw |
| 4 | 1340320 | Shield |
| 5 | 1340340 | Bearing |
| 6 | 1269100 | Clamp |
| 7 | 1340780 | Gasket |
| 8 | 1340480 | Case |
| 9 | 1261560 | Screw |
| 10 | 1263520 | Capacitor |
| 11 | 1340280 | Band |
| 12 | 1260810 | Screw |
| 13 | 2320280 | Switch |
| 16 | 1760450 | Cable |
| 17 | 4919 | Engine |
| 18 | 1340660 | Fairlead |
| 19 | 1340640 | Ring |
| 20 | 1340650 | Fairlead |
| Accessories S 1308 - 12462 Pag.4 |
||
| 1 | 40925 | Gun |
| 2 | 40030 | Lance + Nozle |
| 3 | 1460702 | High Pressure Hose |
| 4 | 2000770 | O-Ring |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
PROLINER S 1308 - 12462
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N AR:
- AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
