AR Farmer's Division Parts for Washer EXTREME 150 TSS REG - 11572
€23.30
Tax included
AR Farmer's Division Parts for Washer EXTREME 150 TSS REG - 11572
We have the original AR Farmer's Division parts and tool repair help you need to get your tools running like new again.Fix Your Pressure Washer EXTREME 150 TSS REG - 11572. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
AR Farmer's Division Parts for Washer EXTREME 150 TSS REG - 11572
Fix Your Pressure Washer EXTREME 150 TSS REG - 11572. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| Casing 150 TSS REG - 11572 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 2180420 | Yellow Casing |
| 2 | 1460340 | Conveyor |
| 4 | 390440 | Nut |
| 5 | 1263020 | Clamp |
| 6 | 2320250 | Plate |
| 7 | 2180040 | Handle |
| 8 | 2180060 | Knob |
| 9 | 2180090 | Grid |
| 10 | 1261560 | Screw |
| 11 | 2180300 | Washer |
| 12 | 1343510 | Screw |
| 13 | 2180050 | Holders Accessories |
| 14 | 2320310 | Screw |
| 16 | 2180080 | Axle |
| 17 | 2180140 | Wheel |
| 18 | 1680880 | Washer |
| 19 | 1680890 | Washer |
| 20 | 2180360 | Base |
| 21 | 1270960 | Tube Cleaner |
| 22 | 40008 | Tank |
| 23 | 2320260 | Connection |
| 27 | 2180330 | Rubber |
| 28 | 2000110 | Screw |
| 30 | 2180740 | Ferrule |
| 31 | 2000240 | O-Ring |
| 32 | 1682420 | Stopper |
| 33 | 2189000 | Pre-Assembly Base |
| Pump 150 TSS REG - 11572 Pag.2 |
||
| 1 | 2101000 | Screw |
| 2 | 2100610 | Connection |
| 3 | 550350 | O-Ring |
| 4 | 2123 | Head + OR |
| 5 | 850850 | Screw |
| 6 | 2020481 | Office |
| 7 | 394280 | O-Ring |
| 8 | 2109051 | Valve |
| 9 | 880840 | O-Ring |
| 10 | 2200140 | Watertight |
| 11 | 2320080 | Ring |
| 12 | 770590 | O-Ring |
| 13 | 2320070 | Bush |
| 14 | 1683500 | Oil Seal |
| 15 | 2020120 | Piston Guide |
| 16 | 2200210 | Screw |
| 17 | 2020150 | Spring |
| 18 | 2020130 | Piston |
| 19 | 2020140 | Ring |
| 20 | 1680680 | O-Ring |
| 21 | 1260760 | Screw |
| 22 | 2021570 | Bearing |
| 23 | 2180720 | Curve |
| 24 | 1140690 | Band |
| 25 | 2180730 | Tube Feeding |
| 27 | 550460 | Curve |
| 28 | 550450 | Walker |
| 29 | 2000520 | O-Ring |
| 30 | 2329409 | Pump Pre-Assembly |
| 31 | 1470830 | Connection |
| A | 2577 | Valve Kit |
| B | 2734 | Piston Kit |
| D | 2791 | Kit Held |
| Connection Flow 150 TSS REG - 11572 Pag.3 |
||
| 1 | 1981770 | Stopper |
| 2 | 1981780 | Knob |
| 3 | 1060120 | Nut |
| 4 | 392840 | Screw |
| 5 | 1980390 | Insert |
| 6 | 1080070 | Thorn |
| 7 | 1343000 | Disk |
| 8 | 1460190 | Spring |
| 9 | 1343450 | Disk |
| 10 | 600180 | O-Ring |
| 11 | 2021900 | Piston |
| 12 | 1080190 | O-Ring |
| 13 | 2021960 | Fork |
| 14 | 620301 | Stopper |
| 15 | 1460430 | O-Ring |
| 16 | 1460260 | Piston |
| 17 | 1540140 | Spring |
| 18 | 2021540 | Injector |
| 19 | 820510 | O-Ring |
| 20 | 1465720 | O-Ring |
| 21 | 1250270 | Spring |
| 22 | 1250280 | Ball |
| 23 | 480480 | O-Ring |
| 24 | 2320210 | Connection |
| 25 | 480560 | O-Ring |
| 26 | 2320180 | Hose |
| 27 | 1460150 | Piston |
| 28 | 2240 | Pre-Assembly Fitting - DISCONTINUED |
| D | 2791 | Kit Held |
| Motor 150 TSS REG - 11572 Pag.4 |
||
| 1 | 2029738 | Pre-Assembly Box TSS |
| 2 | 2320060 | Disk |
| 3 | 1461430 | Bearing |
| 4 | 1460530 | Oil Seal |
| 5 | 2320020 | Body Pump |
| 6 | 2320090 | Screw |
| 7 | 1460590 | Bearing |
| 8 | 1460040 | Shield |
| 9 | 1461200 | Oil Seal |
| 10 | 394280 | O-Ring |
| 11 | 1460370 | Fan |
| 12 | 660170 | O-Ring |
| 13 | 2320131 | Box |
| 14 | 1262400 | Washer |
| 15 | 2020570 | Screw |
| 16 | 2320270 | Cover |
| 17 | 2320280 | Switch |
| 18 | 2021480 | Fairlead |
| 19 | 1760450 | Cable |
| 20 | 2320640 | O-Ring |
| 21 | 1982190 | Condenser |
| 22 | 4609 | Engine |
| Accessories 150 TSS REG - 11572 Pag.5 |
||
| 1 | 40167 | Lance + Rotopower |
| 2 | 40206 | Lance + Head |
| 3 | 40925 | Gun |
| 4 | 1460702 | High Pressure Hose |
| 5 | 2000770 | O-Ring |
