ARSG Parts for Pressure Washer PROLINER Z 8.150 Z TSS RLW - 12463

€14.24
Tax included

ARSG Parts for Pressure Washer PROLINER Z 8.150 Z TSS RLW - 12463

We supply AR Farmer's Division original spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer PROLINER Z 8.150 Z TSS RLW - 12463
ITEM CODE: 2511
Quantity
on 10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

ARSG Parts for Pressure Washer PROLINER Z 8.150 Z TSS RLW - 12463

We supply AR Farmer's Division original spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer PROLINER Z 8.150 Z TSS RLW - 12463

In the following tables, look for the spare part and its respective code.
PROLINER Z 8.150 Z TSS RLW 12463

Casing 8.150 Z TSS RLW - 12463 Pag.1
# Part NUm. Description
1 2500050 Hook
2 2500034 Yellow Casing
3 1680880 Washer
4 2500320 Wheel
5 2500090 Plate
6 2320190 Screw
7 2100300 Screw
8 2600100 Strain Relief
9 850370 Screw
10 2100300 Screw
12 2500130 Rubber
13 880280 Screw
14 2180300 Washer
15 2500120 Axle
16 2500110 Tank
17 2500010 Base
18 1270960 Tube Cleaner
19 2500310 Knob
20 42113 Pre-Assembly Plug
21 2500330 Tube Cleaner
22 2000230 Filter
23 2509000 Pre-Assembly Base
Pump 8.150 Z TSS RLW - 12463 Pag.2
1 1980470 Screw
2 1980300 nut
3 1980210 piston guide
4 740290 O-ring
5 800560 O-ring
6 1080250 O-ring
7 1271170 ring
8 1080190 O-ring
9 1271160 piston
10 1980200 office
11 1470210 O-ring
12 1982520 hose
13 480480 O-ring
14 1250280 sphere
15 1560520 spring
16 1460430 O-ring
17 1540170 shutter
18 1080091 spring
19 394280 O-ring
20 1200690 O-ring
21 1270091 injector
22 1981190 Screw
23 1080190 O-ring
24 660190 O-ring
25 1982990 piston
26 1981320 spring
27 880840 O-ring
28 1983360 junction
29 1982170 head
30 820510 O-ring
31 880581 cork
32 2029752 Pre-assembly box TSS
33 1260162 cork
34 960160 O-ring
35 1981460 bush
36 880240 valve
37 1981450 bush
38 1080401 ring
39 2460180 O-ring
40 1981470 piston guide
41 770130 O-ring
42 1260440 Watertight
43 1980170 ring
44 1980430 spacer
45 1260460 Oil seal
46 770090 O-ring
47 1980460 pump housing
48 180030 Screw
49 1981140 spring
50 1981440 piston
51 1980150 ring
52 1322230 spring
53 1980130 fifth wheel
54 1980250 fifth wheel
55 1980240 fifth wheel
56 1980340 O-ring
57 2022201 fork
58 1461470 junction
59 1989265 Pre-assembly head
60 1980310 Screw
61 1260820 O-ring
62 650530 washer
63 1340260 filter
64 390180 O-ring
65 2440210 extension
66 1150640 O-ring
67 2500450 cork
68 1980290 level Indicator
69 1465850 junction
70 2500140 extension
71 3233 manometer
72 1080041 piston
73 1080070 thorn
74 1271070 spring
75 1980220 disk
76 1980390 insert
77 2500270 extension + 1267810 >>42575
78 2500080 knob
79 42143 Kit TSS
A 2581 valve Kit
B 2593 piston Kit
C 2511 Oil seals kit
E 2582 Kit held water
F 2799 seal Kit
Motor 8.150 Z TSS RLW - 12463 Pag.3
1 1983110 Disk
2 1981210 Bearing
3 1980340 O-Ring
4 2320090 Screw
5 1982040 Flange
6 1260750 Ring
7 1460590 Bearing
8 1460040 Shield
9 1461200 Oil Seal
10 394280 O-Ring
11 1460370 Fan
12 1460340 Conveyor
13 1680960 Washer
14 1460460 Screw
15 660170 O-Ring
16 2320131 Box
17 1262400 Washer
18 2020570 Screw
19 2320270 Cover
20 2320280 Switch
21 2021480 Fairlead
22 1760450 Cable
23 2100840 O-Ring
24 1982590 Capacitor
25 4601 Engine
RLW Z 8.150 Z TSS RLW - 12463 Pag.4
1 40644 Pre Mounting Hose Reel
2 40377 Hose Pre-Assembly
3 2360360 Screw
4 2360150 Lever
5 2100300 Screw
6 2500060 Stirrup
7 2500360 Pin
8 1681280 Screw
9 2360230 Disk
10 380420 Ring
11 2500460 High Pressure Tube
12 2360210 Pin
13 390080 O-Ring
14 2360220 Junction
15 2360320 Ring
16 2500070 Stirrup
17 820510 O-Ring
18 2360310 Junction
19 2360250 High Pressure Tube
20 2500020 Handle
Accessories 8.150 Z TSS RLW - 12463 Pag.5
1 40925 Gun
2 40206 Spear + Nozle
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
PROLINER Z 8.150 Z TSS RLW 12463
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:
AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
New

Download

Diagram AR Farmer's 8.150 Z RLW

Diagram AR Farmer's 8.150 Z RLW

Download (593.61KB)
