Annovi Reverberi Parts for Pressure Washer AR6970
We are Annovi Reverberi original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer Blue Clean AR6970 - 24104.
In the following tables, look for the spare part and its respective code.
| Pressure Washer Blue Clean AR6970 - 24104 | ||
| Casing 6970 - 24104 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 3164170 | Casing Bleu |
| 2 | 3160100 | Holders Accessories |
| 3 | 2100300 | Screw |
| 4 | 3160110 | Holders Accessories |
| 5 | 3164180 | Support |
| 6 | 3164190 | Support |
| 7 | 3164200 | Support |
| 8 | 3164210 | Frame |
| 9 | 3161070 | Fairlead |
| 10 | 3161900 | Plate |
| 11 | 3163140 | Handle |
| 12 | 3163150 | Cover |
| 13 | 3164220 | Tank |
| 14 | 3164230 | Tank |
| 15 | 3161920 | Cork |
| 16 | 3164380 | Wheel |
| 17 | 3162010 | Ring |
| 18 | 3161940 | Protection |
| 19 | 3160130 | Door |
| Pump 6970 - 24104 Pag.2 |
||
| 1 | 960090 | Cork |
| 2 | 960160 | O-Ring |
| 3 | 1389051 | Valve Complete |
| 4 | 880830 | O-Ring |
| 5 | 880581 | Cork |
| 6 | 820510 | O-Ring |
| 7 | 820150 | Screw |
| 8 | 1381850 | Washer |
| 9 | 1381071 | Top |
| 10 | 180101 | O-Ring |
| 11 | 820361 | Cork |
| 12 | 1980740 | Cork |
| 13 | 740290 | O-Ring |
| 14 | 1343510 | Screw |
| 15 | 44275 | Engine |
| 16 | 960110 | Ring |
| 17 | 1382740 | Watertight |
| 18 | 1380090 | Piston Guide |
| 19 | 961240 | O-Ring |
| 20 | 880330 | Watertight |
| 21 | 1383130 | Ring |
| 22 | 1382770 | Body Pump |
| 23 | 1980740 | Cork |
| 24 | 880130 | Cork |
| 25 | 2280340 | Bearing |
| 26 | 640030 | O-Ring |
| 27 | 1380120 | Thickness 0.10 Mm |
| 27 | 1380130 | Thickness 0.20 Mm |
| 27 | 1380530 | Thickness 0.25 Mm |
| 27 | 1382810 | Thickness 0.05 Mm |
| 28 | 1380050 | Support |
| 29 | 850370 | Screw |
| 30 | 2280060 | Shaft |
| 31 | 1380520 | Tab |
| 32 | 1383140 | Bearing |
| 33 | 180340 | Ring |
| 34 | 1380040 | Support |
| 35 | 962010 | Nut |
| 36 | 962000 | Washer |
| 37 | 1380940 | Piston |
| 38 | 1380950 | Disk |
| 39 | 600180 | O-Ring |
| 40 | 1080401 | Ring |
| 41 | 1380920 | Piston |
| 42 | 1380060 | Plug |
| 43 | 1383050 | Piston Rod |
| 44 | 1780510 | O-Ring |
| 45 | 1260430 | Ring |
| 46 | 1780690 | Disk |
| 47 | 1260250 | Level Indicator |
| 48 | 1140450 | O-Ring |
| 49 | 1789010 | Cover |
| 50 | 50068 | Gasket |
| 51 | 50069 | Box |
| 52 | 22953 | Pump Pre-Assembly |
| 53 | 1389115 | Pre-Assembly Head |
| A | 2864 | Valve Kit |
| B | 2757 | Piston Kit |
| C | 1855 | Oil Seals Kit |
| E | 1857 | Water Seal Kit |
| G | 1829 | Kit Support Rings |
| Valve 6970 - 24104 Pag.3 | ||
| 1 | 1560580 | Cork |
| 2 | 540290 | Screw |
| 3 | 1660210 | Nut |
| 4 | 1560400 | Knob |
| 5 | 1080070 | Plug |
| 6 | 1560420 | Screw |
| 7 | 1560410 | Guide |
| 8 | 1560440 | Disk |
| 9 | 1560350 | Spring |
| 10 | 1080610 | Disk |
| 11 | 1080660 | Plug |
| 12 | 1080540 | Piston |
| 13 | 391000 | O-Ring |
| 14 | 1080640 | Ring |
| 15 | 1560150 | O-Ring |
| 16 | 1560100 | Shutter |
| 17 | 1560140 | Spring |
| 18 | 180101 | O-Ring |
| 19 | 1540272 | Screw |
| 21 | 1560010 | Valve Body |
| 22 | 1080550 | Ring |
| 23 | 480480 | O-Ring |
| 24 | 1560280 | Washer |
| 25 | 1560320 | Piston |
| 26 | 880270 | O-Ring |
| 27 | 1560051 | Junction |
| 28 | 390080 | O-Ring |
| 29 | 1560510 | Nut |
| 30 | 1560530 | Junction |
| 31 | 1560520 | Spring |
| 32 | 1250280 | Ball |
| 33 | 480480 | O-Ring |
| 34 | 1560490 | Hose |
| 35 | 1540020 | Collector |
| 36 | 1540120 | Washer |
| 37 | 1540090 | Junction |
| 38 | 1560290 | Washer |
| 39 | 20082 | Valve Complete |
| F | 2611 | Seal Kit |
| Water Circuit 6970 - 24104 Pag.4 | ||
| 1 | 50713 | Filter |
| 2 | 3160480 | Junction |
| 3 | 3161180 | Junction |
| 4 | 3161300 | Tube |
| 5 | 3161150 | Junction |
| 6 | 3160470 | Junction |
| 7 | 3161160 | Junction |
| 8 | 3161400 | Safety Valve |
| 9 | 3160340 | Hose |
| 10 | 3161490 | Nut |
| 11 | 3162040 | Washer |
| 12 | 3161490 | Nut |
| 13 | 3161340 | Tube |
| 14 | 3160210 | Junction |
| 15 | 740290 | O-Ring |
| 16 | 3161570 | Tube |
| 17 | 3163560 | Filter |
| 18 | 3163810 | Tube |
| 19 | 3161050 | Fairlead |
| 20 | 3164300 | Pressure Switch |
| 21 | 3164250 | Tube |
| 22 | 3161260 | Junction |
| 23 | 3164070 | Junction |
| 24 | 3161040 | Manometer |
| 25 | 3164110 | Junction |
| 26 | 3164310 | Pressure Switch |
| 27 | 3161010 | Ferrule |
| 28 | 3161140 | Junction |
| 29 | 3164430 | Junction |
| 30 | 3162300 | Gasket |
| Fuel Circuit 6970 - 24104 Pag.5 | ||
| 1 | 3161650 | Tube |
| 2 | 3161820 | Fan |
| 3 | 3163540 | Screw |
| 4 | 3161050 | Fairlead |
| 5 | 3163490 | Engine |
| 6 | 3160320 | Solenoid |
| 7 | 3161440 | Cable |
| 8 | 3160310 | Pump |
| 9 | 3163770 | Standoff |
| 10 | 3160330 | Junction |
| 11 | 3160340 | Hose |
| 12 | 3162000 | Protection |
| 13 | 3163780 | Tube |
| 14 | 3161660 | Tube |
| 15 | 3161580 | Tube |
| 16 | 3162060 | Band |
| 17 | 3161510 | Filter |
| 18 | 3161600 | Tube |
| 19 | 3160300 | Coupling |
| Electric Circuit 6970 - 24104 Pag.6 | ||
| 1 | 3161980 | Knob |
| 2 | 3160840 | Switch |
| 3 | 3164260 | Fairlead |
| 4 | 3164270 | Plate |
| 5 | 3164280 | Support |
| 6 | 3164160 | Control PCB - ALB 529 |
| 7 | 3161800 | Thermostat |
| 8 | 3163720 | Fuse Holder |
| 9 | 3160920 | Fuse |
| 10 | 3164290 | Box |
| 11 | 3160860 | Fairlead |
| 12 | 3160870 | Fairlead |
| 13 | 3160810 | Cable |
| 14 | 3161970 | Knob |
| Boiler 6970 - 24104 Pag.7 | ||
| 1 | 3162370 | Headphones |
| 2 | 3161100 | Junction |
| 3 | 3162030 | Ring |
| 4 | 3161860 | Glass |
| 5 | 3161230 | Junction |
| 6 | 3161840 | Disk |
| 7 | 3163960 | Nut |
| 8 | 3163940 | Washer |
| 9 | 3161790 | Cover |
| 10 | 3161780 | Cover |
| 11 | 3161870 | The Nozzle Holder |
| 12 | 3162830 | Nozzle |
| 13 | 3161560 | Support |
| 14 | 3161890 | Electrode |
| 15 | 3161770 | Cover |
| 16 | 3161830 | Disk |
| 17 | 3161430 | Ring |
| 18 | 3162040 | Washer |
| 19 | 3161760 | Resistance |
| 20 | 3161480 | Boiler |
| 21 | 3161470 | Boiler |
| 22 | 50717 | Transformer Danfoss / Fida |
| 23 | 3160820 | Cable |
| Accessories 6970 - 24104 Pag.8 | ||
| 1 | 41089 | Gun |
| 2 | 3160160 | High Pressure Tube |
| 3 | 40826 | Lance |
| 4 | 3086 | Nozzle |
