AR Farmer's Division Parts for Washer EXTREME 9.160 Z TSS - 11945
We are AR Farmer's Division original Accessories and spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer EXTREME 9.160 Z TSS - 11945.
In the following tables, look for the spare part and its respective code.
| Pressure Washer EXTREME 9.160 Z TSS - 11945 Spare Parts |
||
| Casing Pag.1 | ||
| # | Part Num. | Description |
| 1 | 2180690 | Yellow Casing |
| 2 | 2180760 | Sponge |
| 4 | 390440 | Nut |
| 5 | 1263020 | Clamp |
| 6 | 2180700 | Plate |
| 7 | 2180040 | Handle |
| 8 | 2180060 | Knob |
| 9 | 2180090 | Grid |
| 10 | 1261560 | Lives |
| 11 | 2180300 | Washer |
| 12 | 1343510 | Lives |
| 13 | 2180050 | Holders Accessories |
| 14 | 850370 | Lives |
| 15 | 961340 | Washer |
| 16 | 2180080 | Axle |
| 17 | 2180140 | Wheel |
| 18 | 1680880 | Washer |
| 19 | 1680890 | Washer |
| 20 | 2180010 | Base |
| 21 | 1270960 | Tube Cleaner |
| 22 | 40008 | Tank |
| 23 | 2180710 | Plate |
| 26 | 1680650 | Screw |
| 27 | 2180330 | Rubber |
| 28 | 2000110 | Screw |
| 29 | 2020940 | Band |
| 30 | 2180441 | Grid |
| 31 | 2189001 | Pre-Assembly Base |
| Pump Pag.2 |
||
| 1 | 110640 | Screw |
| 2 | 1980300 | Nut |
| 3 | 1980530 | Piston Guide |
| 4 | 740290 | O-Ring |
| 5 | 800560 | O-Ring |
| 6 | 1080250 | O-Ring |
| 7 | 1271170 | Ring |
| 8 | 1080190 | O-Ring |
| 9 | 1271160 | Piston |
| 10 | 1980200 | Office |
| 11 | 1470210 | O-Ring |
| 12 | 1982520 | Hose |
| 13 | 480480 | O-Ring |
| 14 | 1250280 | Ball |
| 15 | 1560520 | Spring |
| 16 | 1460430 | O-Ring |
| 17 | 1540170 | Shutter |
| 18 | 1080091 | Spring |
| 19 | 394280 | O-Ring |
| 20 | 1200690 | O-Ring |
| 21 | 1270091 | Injector |
| 22 | 1981190 | Screw |
| 23 | 1080190 | O-Ring |
| 24 | 660190 | O-Ring |
| 25 | 1982990 | Piston |
| 26 | 1981320 | Spring |
| 27 | 880840 | O-Ring |
| 28 | 1983360 | Junction |
| 29 | 1982170 | Head |
| 30 | 820510 | O-Ring |
| 31 | 880581 | Stopper |
| 32 | 2029752 | Pre-Assembly Box Tss |
| 33 | 1260162 | Cork |
| 34 | 960160 | O-Ring |
| 35 | 1981460 | Bush |
| 36 | 880240 | Valve |
| 37 | 1981450 | Bush |
| 38 | 1080401 | Ring |
| 39 | 2460180 | O-Ring |
| 40 | 1981470 | Piston Guide |
| 41 | 770130 | O-Ring |
| 42 | 1260440 | Watertight |
| 43 | 1980170 | Ring |
| 44 | 1980430 | Spacer |
| 45 | 1260460 | Oil Seal |
| 46 | 770090 | O-Ring |
| 47 | 1980460 | Body Pump |
| 48 | 180030 | Screw |
| 49 | 1981140 | Spring |
| 50 | 1981440 | Piston |
| 51 | 1980150 | Ring |
| 52 | 1322230 | Spring |
| 53 | 1980130 | Fifth Wheel |
| 54 | 1980250 | Fifth Wheel |
| 55 | 1980240 | Fifth Wheel |
| 56 | 1980340 | O-Ring |
| 57 | 2022201 | Fork |
| 58 | 1270940 | Connection |
| 59 | 1989257 | Pre-Assembly Head |
| 60 | 1980310 | Screw |
| 61 | 1260820 | O-Ring |
| 62 | 650530 | Washer |
| 63 | 1260660 | Filter |
| 68 | 1980290 | Level Indicator |
| 72 | 1080041 | Piston |
| 73 | 1080070 | Thorn |
| 74 | 1980520 | Spring |
| 75 | 1980220 | Disk |
| 76 | 1980540 | Insert |
| 77 | 42143 | Kit Tss |
| A | 2581 | Valve Kit |
| B | 2593 | Piston Kit |
| C | 2511 | Oil Seals Kit |
| E | 2582 | Kit Held Water |
| F | 2799 | Seal Kit |
| Motor Pag.3 |
||
| 1 | 1983110 | Disk |
| 2 | 1981210 | Bearing |
| 3 | 1980340 | O-Ring |
| 4 | 2320830 | Screw |
| 5 | 1982040 | Flange |
| 6 | 1260750 | Ring |
| 7 | 1460590 | Bearing |
| 8 | 1460040 | Shield |
| 9 | 1461200 | Oil Seal |
| 10 | 394280 | O-Ring |
| 11 | 1460370 | Fan |
| 12 | 1460340 | Conveyor |
| 13 | 1680960 | Washer |
| 14 | 1460460 | Screw |
| 15 | 660170 | O-Ring |
| 16 | 2320131 | Box |
| 17 | 1262400 | Washer |
| 18 | 2020570 | Screw |
| 19 | 2320270 | Cover |
| 20 | 2320280 | Switch |
| 21 | 2021480 | Fairlead |
| 22 | 1760450 | Cable |
| 23 | 2320640 | O-Ring |
| 24 | 1982190 | Condenser |
| 25 | 4704 | Engine |
| 26 | 2021560 | Cable |
| Accessories Pag.4 |
||
| 1 | 40167 | Lance + Rotopower |
| 2 | 40029 | LANCE + head |
| 3 | 40925 | gun |
| 4 | 1262443 | High pressure hose |
| 5 | 2000770 | O-ring |
