Alpina Spare Parts for Chainsaw ACS 538 (2021)
€1.57
Tax included
Alpina Spare Parts for Chainsaw ACS 538 (2021)
We are ALPINA original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Chainsaw ACS 538 (2021) 240381404/A21.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Chainsaw ACS 538 (2021)
We are ALPINA original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Chainsaw ACS 538 (2021) 240381404/A21.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
| ALPINA ACS 538 (2021) 240381404/A21 | ||
| Chassis Pag.1 | ||
| # | Part Num. | Description |
| 1 | 2135040 | Screw |
| 2 | 112731601/0 | Screw |
| 3 | 118804328/0 | Spring |
| 4 | 118805367/0 | Handle Assembly Gray |
| 5 | 118804307/1 | Tank Cap Assembly |
| 9 | 118805368/0 | Handle Cover Gray |
| 10 | 118804330/0 | Spring |
| 11 | 118805369/0 | Throttle lever Yellow |
| 12 | 118805370/0 | Safety Lever Yellow |
| 13 | 118804327/0 | Valve cap |
| 14 | 118804881/0 | Spring |
| 15 | 118804227/0 | Vent valve |
| 16 | 118804911/0 | Fuel Pipe Assembly |
| 17 | 118804233/0 | Fuel Filter |
| 19 | 118804354/0 | Hose clamp |
| 21 | 118804326/0 | Pipe, Fuel Return |
| 23 | 118804325/0 | Fuel Pipe |
| 24 | 118804932/0 | Fuel Filter Balancing Weight |
| 26 | 323059046/0 | Plate |
| 27 | 112728523/0 | Screw |
| 29 | 118804222/0 | Spring |
| 30 | 118804221/0 | Wrench, Spark Plug |
| 31 | 118801179/0 | Pin |
| 32 | 118804913/0 | Primer |
| 33 | 118804232/0 | Suction Pipe |
| 34 | 118804912/0 | Anti-vibration cover |
| 35 | 118804322/0 | Bush |
| 36 | 323300022/0 | Front handle |
| Engine - Carburettor Pag.2 | ||
| 1 | 2135040 | Screw |
| 2 | 112731601/0 | Screw |
| 37 | 118805347/0 | Air Filter Cover Assembly Gray |
| 38 | 118804215/0 | Lever |
| 43 | 118804909/0 | Cylinder cover assembly |
| 44 | 118804321/0 | Flange |
| 45 | 323059042/0 | Cylinder cover |
| 46 | 118804304/0 | Heat shield |
| 47 | 118804908/0 | Air Filter Assembly |
| 48 | 118804282/0 | Knob |
| 49 | 118804344/0 | Air Filter Lock |
| 51 | 112760471/0 | Screw |
| 52 | 118804409/0 | Air Filter Base |
| 53 | 118804349/0 | Guide |
| 54 | 323315115/0 | Choke knob |
| 55 | 118804278/0 | Choke knob bush |
| 56 | 118804351/1 | Carburetor |
| 57 | 118804347/0 | Knob |
| 58 | 118804348/0 | Throttle rod |
| 59 | 118804273/0 | Support Ring |
| 60 | 118804354/0 | Hose clamp |
| 61 | 118804353/1 | Fuel Pipe |
| 62 | 118804352/0 | Tube |
| 63 | 323784016/0 | Carburettor support |
| 64 | 118804346/0 | Intake manifold |
| 68 | 118804381/0 | Muffler gasket |
| 69 | 118804904/0 | Spacer |
| 70 | 118804649/0 | MUFFLER (RHS) |
| 71 | 112581500/0 | Washer M5 |
| 72 | 112521320/0 | Washer |
| 73 | 118804379/0 | Screw |
| 74 | 118804651/0 | Muffler cover |
| 75 | 2135120 | Screw |
| 76 | 2135180 | Screw |
| 161 | 118804524/0 | Carburetor Repair Kit |
| 162 | 118804525/0 | Carburetor gasket kit |
| 163 | 114369741/0 | Label |
| Engine Cylider - Piston Pag.3 | ||
| 1 | 2135040 | Screw |
| 5 | 118804307/1 | Tank Cap Assembly |
| 11 | 3210024 | Spark Plug CPCJ7Y - CJ7Y - CPRCJ7Y |
| 66 | 118804382/0 | Nozzle |
| 68 | 118804381/0 | Muffler gasket |
| 77 | 118804905/0 | Crankcase Assembly Left |
| 78 | 118804366/0 | Heat Insulator |
| 79 | 123753000/0 | Pin D.3x9 |
| 80A | 118804363/0 | Ball bearing |
| 80B | 118804364/0 | Oil Seal |
| 81 | 118804617/0 | Crankcase gasket |
| 82 | 2132550 | Screw |
| 83 | 118804616/0 | Cylinder gasket |
| 85 | 118804342/0 | Piston assembly |
| 86 | 118804376/0 | Piston Ring |
| 88 | 118804373/0 | Piston pin |
| 89 | 118804372/0 | Clip |
| 90 | 118804374/0 | Needle Bearing |
| 91 | 118804375/0 | Needle Bearing Gasket |
| 92 | 118804371/1 | Crankshaft |
| 93 | 118804906/0 | Crankcase Assembly Right |
| 94 | 118804587/0 | Oil Spray Nozzle |
| 98 | 118804358/0 | Bolt |
| 99 | 118801158/0 | Pin D.5x10 |
| 100 | 323059044/0 | Chain Guard |
| 101 | 118804907/0 | Chain Tensioner assembly |
| 102 | 118804285/0 | Plate |
| 105 | 118804289/0 | Chain Tensioner Screw |
| 106 | 118804288/0 | Chain tensioner |
| 107 | 118804361/0 | Gear Cover |
| 108 | 112726389/0 | Screw |
| 109 | 118804343/0 | Cylinder - Piston assembly |
| 110 | 118804340/0 | Gaskets Kit |
| 170 | 118800959/0 | Key |
| Engine- Clutch Pag.4 | ||
| 1 | 2135040 | Screw |
| 76 | 2135120 | Screw |
| 109 | 118804250/0 | Oil tube Assembly |
| 113 | 118804301/0 | Oil Pump Cover |
| 114 | 118804300/1 | Oil pump |
| 115 | 118804299/0 | Oil Spray Nozzle |
| 116 | 118804357/0 | Bush |
| 117 | 118804297/0 | Worm screw |
| 118 | 118804296/0 | Washer |
| 119 | 118804295/0 | Clutch Assy |
| 120 | 118804355/0 | Clutch Drum |
| 121 | 118804511/0 | Needle Bearing |
| 122 | 118804290/0 | Washer |
| 123 | 112000955/0 | Circlip D.8 |
| 124 | 118804318/0 | Bush |
| 125 | 118804910/0 | Return Spring Guard Assy |
| 126 | 323455013/0 | Handguard |
| 127 | 118804312/0 | Spring |
| 128 | 118804313/0 | Chain Brake Lever |
| 129 | 118804407/0 | Retaining ring |
| 130 | 123753000/0 | Pin D.3x9 |
| 131 | 118804314/0 | Brake Band |
| 132 | 118804311/0 | Gasket |
| 133 | 118804310/0 | Brake Spring Cover |
| 134 | 118804362/0 | Spike |
| 135 | 118805349/0 | Clutch Cover Assembly Gray |
| 164 | 118805079/0 | Oil Pump AssemblyThe bush inside the kit is needed only for SP386-426 / ACS 538-542 |
| 165 | 118804303/0 | Screw |
| 166 | 118800127/0 | Guide Bar 14 "-3/8" -0.050 " |
| 167 | 1519-9117-02 | Chain 14 "-3/8" -0.050 "-53E to 31-August 2021 |
| 167 | 1519-9117-03 | Chain, 3/8 "x .050" (1.3mm) - 53E From 01-September 2021 |
| Starter Assembly Pag.5 | ||
| 1 | 2135040 | Screw |
| 5 | 112731601/0 | Screw |
| 136 | 118805348/0 | Starter Assembly Gray |
| 137 | 118805371/0 | Starter Handle Gray |
| 139 | 118804385/0 | Starter Spring Assembly |
| 142 | 118804243/1 | Starter Pulley |
| 144 | 112521330/0 | Washer |
| 145 | 118804333/0 | Air Guide |
| 146 | 118804370/0 | Ignition coil assembly |
| 147 | 118804522/0 | Spark Plug cap assembly |
| 153 | 118804367/0 | Switch |
| 155 | 112154220/0 | Nut |
| 156 | 118800959/0 | WOODRUFF KEY 3 x 3.5 x 10 |
| 157 | 118804356/1 | Flywheel |
| 168 | 118804523/0 | Flywheel Hooks Assembly |
| 169 | 118804369/0 | Washer |
| 170 | 114369742/0 | Only for STIGA Brand Machine label |
