Alpina Spare Parts for Chainsaw C 41 (2017) 204016010/13P
€56.66
Tax included
Alpina Spare Parts for Chainsaw C 41 (2017) 204016010/13P
We supply original ALPINA spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Chainsaw C 41 (2017) 204016010/13P.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Chainsaw C 41 (2017) 204016010/13P
We supply original ALPINA spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Chainsaw C 41 (2017) 204016010/13P.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
| ALPINA C 41 (2017) 204016010/13P Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118800267/0 | Cylinder assembly |
| 2 | 2432040 | Nut |
| 3 | 112581500/0 | Grower |
| 4 | 2312090 | Washer |
| 5 | 123878022/0 | Screw |
| 6 | 118800243/0 | Plate |
| 7 | 118550582/0 | Muffler |
| 8 | 118550583/0 | Muffler gasket |
| 9 | 118550584/0 | Screw |
| 10 | 2135030 | Screw |
| 11 | 3210024 | Spark Plug |
| 12 | 118550585/0 | Cylinder Manifold Gasket |
| 13 | 118550586/0 | Intake manifold |
| 14 | 118550587/0 | Carburetor gaskets |
| 15 | 118550588/0 | Cylinder Base Gasket |
| 16 | 118800182/0 | Piston Ring |
| 17 | 118800244/0 | Piston pin |
| 18 | 118550590/0 | Circlip |
| 19 | 118805102/0 | Piston assembly |
| 20 | 118800246/0 | Bearing |
| 21 | 118550591/0 | Needle Bearing |
| 22 | 118800247/0 | Cranck shaft |
| 23 | 123072005/0 | Flywheel key |
| 24 | 118800248/0 | Crankcase, starter side |
| 25 | 3112030 | Ball bearing |
| 26 | 118800249/0 | Crankcase, gasket |
| 27 | 118800250/0 | Crankcase, clutch side |
| 29 | 118550592/0 | Locking ring |
| 30 | 2135050 | Screw |
| 31 | 118550593/0 | Screw |
| 34 | 118550596/0 | Spiked Bumper |
| 35 | 2135180 | Screw |
| 36 | 118550597/0 | Chain catcher |
| 37 | 118800251/0 | Screw |
| 38 | 118550598/0 | Bar Base Plate |
| 39 | 123878020/0 | Screw |
| 40 | 118550599/0 | Locking ring |
| 41 | 118804679/0 | Digital Ignition Coil Type A |
| 42 | 123878021/0 | Screw |
| 43 | 2321050 | Washer |
| 44 | 118550601/0 | Ground cable |
| 45 | 123120004/0 | Nut |
| 46 | 118804676/0 | Flywheel Assembly Magnet With Type A ignition |
| 51 | 118550603/0 | Clutch assembly |
| 55 | 118800252/0 | Clutch washer |
| 56 | 118801063/0 | Clutch Drum Assembly 7 Tooth - Pitch .325 " |
| 57 | 118550605/0 | Needle bearing |
| 58 | 118801064/0 | Worm Screw 3 Tooth - Pitch .325 " |
| 59 | 118800253/0 | Oil pump cover |
| 60 | 118550607/0 | Oil Pump Assembly |
| 61 | 118800254/0 | Pipe |
| 62 | 118550608/0 | Washer |
| 63 | 118800255/0 | Oil Pickup Pipe |
| 65 | 118800256/0 | Joint |
| 66 | 118550609/0 | Oil Filter Assembly |
| 67 | 118802952/0 | Oil Nozzle |
| 70 | 8724091 | Carburetor Membrane-Gasket Kit |
| 71 | 118800210/0 | Carburetor |
| 72 | 118800211/0 | Intake manifold |
| 73 | 118800212/0 | Screw |
| 74 | 118804231/0 | Primer |
| 75 | 118800204/0 | Pick-up pipe |
| 76 | 3657050 | Spark Plug Spring |
| 77 | 3748880 | Spark Plug Cap |
| ALPINA C 41 (2017) 204016010/13P Casing Pag.2 | ||
| 1 | 118800764/0 | White Clutch Cover Assembly |
| 2 | 123878017/0 | Screw |
| 3 | 123044213/0 | Bushing |
| 4 | 123044214/0 | Bushing |
| 5 | 118800765/0 | Handle Guard |
| 6 | 118800748/0 | Counterweight |
| 7 | 123430572/0 | Spring |
| 8 | 118800747/0 | Spring |
| 9 | 123657007/0 | Washer |
| 10 | 112154320/0 | Nut |
| 11 | 323670001/0 | plate |
| 12 | 118800745/0 | Spring |
| 13 | 118800257/0 | Bar Base Plate |
| 14 | 123753001/0 | Plug |
| 15 | 383315051/0 | Brake Link Lever |
| 17 | 123753000/0 | Needle |
| 18 | 323315067/0 | Brake Hooking Lever |
| 19 | 118800746/0 | Brake Spring |
| 20 | 118800185/0 | Brake Band |
| 21 | 123878023/0 | Screw |
| 22 | 323109525/0 | Brake Spring Cover |
| 24 | 118800186/0 | Nut |
| 25 | 118800767/0 | Air filter cover Black |
| 26 | 118800756/0 | knob |
| 27 | 118800188/0 | Air filter |
| 28 | 118800766/0 | Air Filter Cover White |
| 30 | 118800740/0 | Pin |
| 31 | 118800768/0 | knob |
| 32 | 118800749/0 | Cap |
| 34 | 118800189/0 | Screw |
| 35 | 118800742/0 | grommet |
| 36 | 118800264/0 | Air lever rubber |
| 37 | 118800755/0 | Air lever |
| 38 | 118800758/0 | Air conveyor |
| 39 | 118800757/0 | White Starter Assembly |
| 42 | 118800754/0 | Starter cup |
| 43 | 118800753/0 | Spring |
| 44 | 118801178/0 | Wire |
| 45 | 118800760/0 | Starter Pulley To 31-August-2013 |
| 45 | 118800760/1 | Starter Pulley Assembly From 01-September-2013 |
| 47 | 118800741/0 | Starter Spring |
| 48 | 118800759/0 | Starter handle |
| 50 | 123878024/0 | Screw |
| 51 | 123878025/0 | Screw |
| 52 | 118800743/0 | Dust guard |
| 53 | 118800266/0 | Shock Absorber |
| 54 | 123878022/0 | Screw |
| 55 | 118800194/0 | Shock Absorber |
| 56 | 118800195/0 | Shock Absorber cap |
| 57 | 118800196/0 | Spring |
| 58 | 118800197/0 | Grip-Handrail |
| 59 | 323208402/0 | plate |
| 60 | 118800198/0 | Breath Valve Assembly |
| 64 | 118800744/0 | grommet |
| 65 | 112728124/0 | Screw |
| 66 | 118800255/0 | Oil Pickup Hose |
| 67 | 118800214/0 | Fuel filter |
| 68 | 118801067/0 | Screw |
| 69 | 118801065/0 | Chain tensioner pin |
| 70 | 118801066/0 | Sproket |
| 72 | 118800199/0 | Fuel filter |
| 73 | 118800751/0 | engine casing White |
| 74 | 118800201/0 | Spring |
| 75 | 118800761/0 | Fuel Cap Assembly |
| 79 | 118800762/0 | Oil cap |
| 82 | 123510098/0 | Elastic pin |
| 83 | 118800205/0 | Safety Lever |
| 84 | 118800206/0 | Spring |
| 85 | 118800207/0 | Throttle lever |
| 86 | 118800750/0 | Spring |
| 87 | 118800763/0 | handle cover Black |
| 89 | 118800213/0 | Stop wire |
| 90 | 118800202/0 | Switch |
| 96 | 118800752/0 | Crankcase |
| 98 | 118801746/0 | chain 16inch |
| 99 | 123900369/0 | Guide Bar 16inch |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
