FIAC Spare Parts for Pumping Unit AB 851
€40.67
Tax included
FIAC Original Spare Parts for Pump Unit AB 851
Fiac Air Compressors service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for piston Air Compressors Lubricared Pump Unit AB 851.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Original Spare Parts for Pump Unit AB 851
Fiac Air Compressors service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for piston Air Compressors Lubricared Pump Unit AB 851.
In the following table , look for the model of the Pumping Unit and the respective parts of the code .
| Pump Unit AB 851 data validità - da 05/03/2012 | ||
| # | Part Num. | Description |
| 4 | 7458910000 | band |
| 5 | 7011460000 | Screw M6X16 TAP-TITE |
| 6 | 5131020008 | junction |
| 8 | 7012090000 | Screw M5X12 UNI-8112 |
| 9 | 7070140000 | O-Ring 4200 |
| 11 | 4080090000 | Piston Ring Set LP D. 105 mm |
| 12 | 7220140000 | Piston LP D.105 mm |
| 13 | 7040140000 | Seeger Ø18 UNI-7437 |
| 14 | 7050150000 | Piston Pin Ø18 X 94 |
| 15 | 4080080000 | Kit segments |
| 16 | 7220120000 | Piston HP |
| 17 | 7011040000 | Screw M6X20 UNI-5739 |
| 18 | 7050130000 | Piston pin Ø18x42 |
| 19 | 7085110000 | Fitting 1 "-1/2" MF |
| 20 | 7062170000 | bearing |
| 21 | 4190370008 | Conrod Assy |
| 22 | 5060720008 | cylinder |
| 23 | 7011160000 | Screw M10x30 UNI-5739 |
| 24 | 7079410000 | gasket |
| 25 | 5070270008 | sump |
| 26 | 7153050000 | Air Baffle |
| 27 | 7091120000 | stopper |
| 28 | 7011090000 | Screw M8X20 UNI-5739 |
| 29 | 5082090008 | support |
| 30 | 7070290000 | O-ring Ø82x2 |
| 31 | 7060160000 | Ball bearing 6006 |
| 32 | 7180060000 | Oil level warning |
| 33 | 7090090000 | Cap M1 / 4 "Brass |
| 34 | 7022040000 | Nut M8 DIN-980 |
| 35 | 5041150008 | Crank Shaft |
| 36 | 7051520000 | Woodruff key 9x6 UNI-6606 |
| 37 | 7060150000 | bearing 6206 |
| 38 | 7071130000 | Oil seal 30X47X7 MIM |
| 39 | 5082050008 | support |
| 40 | 7201240000 | flywheel |
| 41 | 7030270000 | Washer Ø8,5X30X4 UNI-6593 |
| 42 | 7031010000 | Washer Ø8 UNI-3703 |
| 43 | 7011110000 | Screw M8x30 UNI-5739 |
| 44 | 7230751000 | cooler |
| 45 | 7024150000 | A nut M6 GALLETTO |
| 46 | 7031030000 | Washer Ø6 UNI-3703 |
| 47 | 7210270000 | Filter Holder Assy ----> 425010000 |
| 48 | 7210280000 | filter element |
| 49 | 7210260000 | filter element |
| 50 | 7210290000 | sleeve |
| 51 | 7015160000 | rod M6X160 |
| 52 | 5130070008 | collector |
| 53 | 7010050000 | Screw M8X20 UNI-5931 |
| 54 | 7458460000 | plate |
| 55 | 7070260000 | O-Ring 3068 Ø17,12 X 2.62 |
| 56 | 5030590008 | head |
| 57 | 7010060000 | Screw M8x45 UNI-5931 |
| 58 | 7084600000 | Fitting M1 / 8 "x6 |
| 59 | 7230020000 | Tube Rilsan Ø8X6 |
| 60 | 7192350000 | Safety Valve 1/4 6 BAR |
| 61 | 7079250000 | gasket |
| 62 | 5130090008 | cooler |
| 63 | 7010220000 | Screw M10x25 UNI-5931 |
| 64 | 7458420000 | plate |
| 100 | 4231240000 | Kit valve plate |
| 101 | 4291110000 | Kit rod / piston |
| 102 | 4291150000 | HP piston kit |
| 103 | 4250100000 | Kit suction filter |
| 104 | 4251150000 | Kit cooler |
| 105 | 4082601000 | gasket kit |
| 106 | 4080460000 | Kit Screws |
| 019A | 7080160000 | Fitting "L" 1/2 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Fiac AB851 from 05/03/2012
