Alpina Spare Parts for Brushcutter TB 26 J
€2.19
Tax included
Alpina Spare Parts for Brushcutter TB 26 J
Alpina-Stiga-Castor-Castelgarden-Mountfield Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to solve any maintenance for Brushcutter TB 26 J - 2011 - AIPL2011_20110203_TB26J.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter TB 26 J
Alpina-Stiga-Castor-Castelgarden-Mountfield Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to solve any maintenance for Brushcutter TB 26 J - 2011 - AIPL2011_20110203_TB26J.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| Alpina TB 26 J - Year 2011 - AIPL2011_20110203_TB26J Pag.1 | ||
| # | Part Num. | Description |
| 2 | 123604006/0 | Starter Pulley |
| 4 | 123430584/0 | Spring |
| 10 | 183058031/0 | Starter Ass.Y |
| 14 | 183082002/1 | Starter Cup Ass.Y |
| 15 | 119035159/0 | Seal Ring |
| 16 | 123685024/0 | Crank Case |
| 17 | 123280046/0 | Gasket |
| 18 | 114215218/0 | Ball Bearing |
| 19 | 123020024/0 | Crankshaft |
| 20 | 123072002/0 | Key |
| 22 | 123685025/0 | Crank Case |
| 24 | 123880010/0 | Flywheel |
| 27 | 112154200/0 | Nut |
| 28 | 123044017/0 | Ignition Ass'Y |
| 32 | 123430582/0 | Spring |
| 33 | 123400002/0 | Clutch Unit |
| 35 | 123878057/0 | Screw |
| 36 | 123208421/0 | Transm.Support Case |
| 37 | 123235006/0 | Needle Bearing |
| 38 | 123202005/0 | Washer, Piston Pin |
| 39 | 123590007/0 | Piston |
| 40 | 123760005/0 | Piston Pin |
| 41 | 123204009/0 | Piston Ring |
| 42 | 123280044/0 | Cylinder Gasket |
| 43 | 123071021/0 | Cilynder |
| 45 | 123087023/0 | Cylinder Cover Yellow |
| 47 | 3210024 | Spark Plug |
| 50 | 123053002/0 | Spark Plug Cover |
| 51 | 123275023/0 | Grommet |
| 52 | 123109551/0 | Cover, Spark Plug |
| 53 | 123280042/0 | Gasket |
| 54 | 183740021/0 | Muffler |
| 58 | 123280084/0 | Intake Manif-Gasket |
| 59 | 123073519/0 | Intake Manifold |
| 60 | 123280059/0 | Intake-Carb Gasket |
| 61 | 123054025/1 | Carburettor |
| 62 | 123315089/0 | Choke Lever |
| 66 | 2132160 | Screw |
| 67 | 123190000/0 | Shutter |
| 68 | 183220003/0 | Air Filter assy |
| 69 | 123220011/0 | Air Filter |
| 70 | 123090026/0 | Air Cleaner Cover |
| 71 | 123878056/0 | Knob |
| 72 | 123784009/0 | Support |
| 73 | 123275033/0 | Grommet |
| 74 | 183520005/0 | Intake Filter |
| 75 | 123867030/0 | Tube |
| 76 | 123275021/0 | Grommet |
| 77 | 123867031/0 | Tube |
| 79 | 123733002/0 | Kit Fuel Tank |
| 85 | 123280060/0 | Grommet |
| 86 | 183790009/0 | Fuel Cap Assy |
| Alpina TB 26 J - Year 2011 - Trasmission Shaft Pag.2 | ||
| 1 | 183785003/0 | Support Trasm.Assy |
| 2 | 123050011/0 | Drum Ass'Y, Clutch |
| 3 | 123275036/0 | Grommet |
| 4 | 123720005/0 | Upper Clamp |
| 5 | 123720004/0 | Lower Clamp |
| 11 | 183300027/0 | Handle Assy |
| 12 | 123315104/0 | Safety Lever |
| 13 | 123066026/0 | Throttle Cable |
| 14 | 123315105/0 | Throttle Lever |
| 15 | 123430612/0 | Spring |
| 16 | 183303002/0 | Switch |
| 21 | 123170004/0 | Spacer |
| 22 | 183780002/0 | Harness Support Ass.Y |
| 23 | 183300025/0 | Front Handle |
| 24 | 123655005/0 | Grommet |
| 25 | 183869072/0 | Assy Transm. Tube+Flex |
| 26 | 123020035/0 | Trasmission Shaft |
| 27 | 183260002/0 | Connecting Head Assy |
| 28 | 123593510/0 | Knob |
| 29A | 123020035/0 | Trasmission Shaft |
| 29 | 183869074/0 | Assy Transm. Tube+Flex |
| 30 | 123784012/0 | Support |
| 31 | 123465007/0 | Safety Cover |
| 32 | 183600055/0 | Guard |
| 33 | 123311013/0 | Line Cutter |
| 35 | 183820507/0 | Gear Case Assy |
| 36 | 123670002/0 | Guard |
| 37 | 123250002/0 | Upper Ring Nut |
| 38 | 123250003/0 | Lower Ring Nut |
| 39 | 123120015/0 | Nut |
| 41 | 123155009/0 | 2 Hedges Nylon Head |
| 42 | 123155010/0 | 3 Teeth Disc |
| 43 | 123046005/0 | Harness |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
