AGP Europe Parts for Diamond Core Drill DM6P

Name: AGP Europe Parts for Diamond Core Drill DM6P
Brand: AGP EUROPE
SKU: DM6P Version 2.6
Price: 55.74 EUR
Availability: InStock

€55.74

Tax included

AGP Europe Parts for Diamond Core Drill DM6P

We have the original Spares AGP Europe Spare Parts for DM6P/3 Speed Diamond Core Drill the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your DM6P/3 Speed Diamond Core Drill. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Guaranteed Genuine Parts.

ITEM CODE: 206-031503014-01

206-031503014-01
304-03013-004-008
203-0004-00000-001
303-01003-004-001
403-M04014003-020
305-00093-000-001
304-03011-004-034
304-04012-000-004
303-01065-004-006
303-01066-004-006
403-M04016003-020
406-M05030080-090
406-M05020080-050
201-0120-0164-001
201-0015-00026-001
303-01296-000-001
403-M04012002-050
302-04009-000-004
418-M05000080-050
303-01295-000-001
0201-0020-00026-010
204-0021-20000-010
407-M04010070-050
303-01297-000-001
299-0002-20000-075
407-M05080095-020
302-05514-000-008
299-0001-20000-105
302-05515-000-001
303-02002-004-035
201-0003-00164-054
303-02009-004-017
302-05502-000-001
302-04162-901-002
302-03030-901-002
302-06005-000-030
302-06036-000-010
302-05107-000-004
422-W14-0
302-06008-000-031
302-06019-000-003
422-W18-0
302-06008-000-032
303-02002-004-023
0201-0002-00026-123
406-M05012080-070
303-02009-004-018
201-0068-00164-001
0299-0018-00000-023
406-M05050080-030
303-02002-004-018
303-02002-004-017
422-S25-0
302-05519-000-003
421-05040-10
422-R52-0
470-0
302-04225-907-001
303-02009-004-071
302-05404-000-001
302-04226-907-001
303-02009-004-021
201-0069-00001-001
203-0001-00000-004
305-00302-004-005
303-03005-000-001
303-02009-004-062
403-M04008003-050
407-M04008070-050
0299-0141-00000-001
305-00093-000-002
426-040000-00
407-M04006070-120
0299-0172-00000-004
303-02063-004-001
202-0055-00901-005
0299-0093-00000-015
302-04498-000-001
303-01388-004-001
401-M06060100-080
206-201503210-01
0299-0093-00000-014
307-03006-000-006

Quantity

on Demand Only Call Us Before

Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Description
Product Details
Attachments

AGP Europe Parts for Diamond Core Drill DM6P

Fix Your DM6P/3 Speed Diamond Core Drill. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Concrete Grinderl and the respective parts of the code.

MODEL : DM6P Diamond core drilling machine (Pistol-Handle Model) (AGP Europe) Version 2.6
NO.	CODE	Parts Name
1	206-031503014-01	POWER SUPPLY CABLE (VDE-1.5x3Cx1.4M-H07RNF)
2	304-03013-004-008	PRCD INTERRUPTER PROTECTION (220V)
3	203-0004-00000-001	CORD ARMOR
4	303-01003-004-001	CABLE CLIP
5	403-M04014003-020	PANHEAD TAPPING SCREW-B (M4x14)
6	305-00093-000-001	BULLS-EYE LEVEL
7	304-03011-004-034	SWITCH (110V&220V)
8		N/A
9	304-04012-000-004	LED OVERLOAD LAMP (110V & 220V)
10		N/A
11	303-01065-004-006	HANDLE HALF-RIGHT (BLACK)
12	303-01066-004-006	HANDLE HALF-LEFT (BLACK)
13	403-M04016003-020	PANHEAD TAPPING SCREW-B (M4x16)
14	406-M05030080-090	SOCKET CAP SCREW (M5x30xP0.8)
15	406-M05020080-050	SOCKET CAP SCREW (M5x20xP0.8)
16	201-0120-0164-001	BUTT PLATE (RED-187C)
17	201-0015-00026-001	MOTOR END CASTING (GRAY-RAL7016)
18	303-01296-000-001	INSULATING COVER
19	403-M04012002-050	PANHEAD TAPPING SCREW-B (M4x12)
20		N/A
21	302-04009-000-004	BRUSH SPRING (0.4x4x3T)
22	305-00001-000-031	CARBON BRUSH (7x17x19)(220V)
23		N/A
24		N/A
25	418-M05000080-050	NYLOCK NUT (M5xP0.8)
26	303-01295-000-001	INSULATING SLEEVE
27	0201-0020-00026-010	MOTOR HOUSING (GRAY-RAL7016)
28	204-0021-20000-010	ELECTRONICS UNIT (220V)
29	407-M04010070-050	PANHEAD MACHINE SCREW (M4x10xP0.7)
30	303-01297-000-001	MOTOR INSULATION SLEEVE
31	299-0002-20000-075	STATOR (220V-81x45.8x70)
32	407-M05080095-020	PANHEAD MACHINE SCREW (M5x95xP0.8)
33	302-05514-000-008	BALL BEARING (6200)
34	299-0001-20000-105	ARMATURE (220V-81x45.8x70)
35	302-05515-000-001	BALL BEARING (6201)
36	303-02002-004-035	OIL SEAL (Ø12xØ22x7)
37	201-0003-00164-054	GEAR PLATE (RED-187C)
38	303-02009-004-017	O-RING (Ø92x2)
39	302-05502-000-001	BALL BEARING (608)
40	302-04162-901-002	CLUTCH NUT (M10xP1.25x8.1T)
41		N/A
42	302-03030-901-002	PRESSURE DISC (Ø12.1xØ28x2.65)
43		N/A
44	302-06005-000-030	INPUT GEAR (M1.0x38T)
45		N/A
46	302-06036-000-010	INPUT SHAFT (M1.25x24Tx12Tx8T)
47		N/A
48	302-05107-000-004	NEEDLE BEARING (HK 1010)
49	422-W14-0	INTERNAL CIRCLIP (IS14)
50	302-06008-000-031	OUTPUT GEAR (M1.25x29T)
51	302-06019-000-003	SPINDLE GEAR (M1.25x42T)
52	422-W18-0	INTERNAL CIRCLIP (IS18)
53	302-06008-000-032	OUTPUT GEAR (M1.25x46T)
54	303-02002-004-023	OIL SEAL (Ø22xØ32x7)
55	0201-0002-00026-123	GEAR HOUSING (GRAY-RAL7016)
56	406-M05012080-070	SOCKET CAP SCREW (M5x12xP0.8)
57		N/A
58		N/A
59	303-02009-004-018	O-RING (Ø20x3)
60	201-0068-00164-001	GEAR SELECTOR (RED-187C)
61		N/A
62		N/A
63	0299-0018-00000-023	WATER FEED CONNECTOR KIT (1/2")
64		N/A
65	406-M05050080-030	SOCKET CAP SCREW (M5x50xP0.8)
66	303-02002-004-018	OIL SEAL (Ø25xØ45x7)
67	303-02002-004-017	OIL SEAL (Ø25xØ47x7)
68		N/A
69	422-S25-0	EXTERNAL CIRCLIP (S-25)
70	302-05519-000-003	BALL BEARING (6205)
71	421-05040-10	PARALLEL KEY (5x5x40)
72		N/A
73		N/A
74	422-R52-0	INTERNAL CIRCLIP (R-52)
75	470-0	DOWEL PIN (Ø4x11.8)
76	302-04225-907-001	ANTI-SEIZE CUP
77	303-02009-004-071	O-RING (Ø32x1.5)
78	302-05404-000-001	THRUST RING (3252)
79	302-04226-907-001	ANTI-SEIZE RING
80	303-02009-004-021	O-RING (Ø49x1.5)
81	201-0069-00001-001	HANDLE CLAMP (SILVER)
82		N/A
83		N/A
84	203-0001-00000-004	FRONT HANDLE (M12xP1.75)
85	305-00302-004-005	WRENCH (M32)
86	303-03005-000-001	FAN BAFFLE (Ø48xØ87.5x1)
87		N/A
88		N/A
89	303-02009-004-062	O-RING (Ø30x1.5)
90	403-M04008003-050	PANHEAD TAPPING SCREW-B (M4x8)
91	407-M04008070-050	PANHEAD MACHINE SCREW (M4x8xP0.7)
92	0299-0141-00000-001	BRUSH HOLDER PLATE ASSY.
93	305-00093-000-002	SPIRIT LEVEL (10x10x29)
94	426-040000-00	EXTERNAL STAR WASHER (M4)
95	407-M04006070-120	PANHEAD MACHINE SCREW (M4x6xP0.7)
96	0299-0172-00000-004	CLUTCH DISC SET
97	303-02063-004-001	GASKET (BLACK)
98		N/A
99		N/A
100	202-0055-00901-005	SELECTOR DISC
101	0299-0093-00000-015	SPINDLE SET (1 1/4"-7 x 1/2"BSP)
102	302-04498-000-001	STAINLESS BUSHING (Ø23xØ25x9)
103	303-01388-004-001	HAND KNOB
104	401-M06060100-080	HEX BOLT (M6x60xP1.0)
105	206-201503210-01	POWER SUPPLY CABLE (NO PLUG-1.5x3Cx2.1M-H07RNF)
106	0299-0093-00000-014	SPINDLE SET (1/2"BSP)
107		N/A
108	307-03006-000-006	BUSHING (Ø12xØ18x5)
