AGP Europe Parts for Diamond Core Drill DM14 / 4 Speed

Fix Your DM14 / 4 Speed Diamond Core Drill. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Concrete Grinderl and the respective parts of the code.

MODEL : DM14 / 4 Speed diamond core drill (AGP Europe) Version 2.4
NO.	Code	Parts Name
1.)	206-031503014-01	POWER SUPPLY CABLE (VDE-1.5x3Cx1.4M-H07RNF)
2.)	304-03013-004-008	PRCD INTERRUPTER PROTECTION (220V)
3.)	303-02001-004-006	CORD ARMOR
4.)	426-040000-00	EXTERNAL STAR WASHER (M4)
5.)	407-M04010070-050	PANHEAD MACHINE SCREW (M4x10xP0.7)
6.)		N/A
7.)		N/A
8.)	304-03017-000-005	SWITCH (220V)
9.)		N/A
10.)	403-M04025003-020	PANHEAD TAPPING SCREW-B (M4x25)
11.)	203-0108-00004-002	COVER (110V&220V)
12.)	412-M04012070-050	PANHEAD MACHINE SCREW-W/WASHER (M4x12xP0.7)
13.)	0299-0040-20000-008	ELECTRONICS UNIT (220V)
14.)	406-M05025080-160	SOCKET CAP SCREW (M5x25xP0.8)
15.)	424-051210-10	FLAT WASHER (Ø5xØ12x1)
16.)	303-01129-164-001	TOP HANDLE (RED-187C)
17.)	201-0015-00026-002	MOTOR END CASTING (GRAY-RAL7016)
18.)	302-04009-000-004	BRUSH SPRING (0.4x4x3T)
19.)	418-M05000080-050	NYLOCK NUT (M5xP0.8)
20.)	407-M04006070-120	PANHEAD MACHINE SCREW (M4x6xP0.7)
21.)	305-00001-000-031	CARBON BRUSH (7x17x20)(220V)
22.)	0299-0141-00000-002	BRUSH HOLDER PLATE ASSY.
23.)	0201-0020-00026-009	MOTOR HOUSING (GRAY-RAL7016)
24.)	406-M06075100-080	SOCKET CAP SCREW (M6x75xP1.0)
25.)	303-01297-000-002	MOTOR INSULATION SLEEVE
26.)	299-0002-20000-080	STATOR (220V-100x54.1x75)
27.)	407-M05110080-050	PANHEAD MACHINE SCREW (M5x110xP0.8)
28.)	303-01057-004-019	FAN SHROUD (BLACK)
29.)	302-05514-000-008	BALL BEARING (6200)
30.)	299-0001-23000-125	ARMATURE (220V-100x54.1x75)
31.)	302-05516-000-002	BALL BEARING (6202)
32.)	303-02002-004-036	OIL SEAL (Ø14xØ25x7)
33.)	0299-0125-00164-001	GEAR PLATE (RED-187C)
34.)	303-02054-000-001	GASKET
35.)	302-05105-000-005	NEEDLE BEARING (HK 0810)
36.)	302-04162-901-011	CLUTCH NUT (M12xP1.75x9T)
37.)		N/A
38.)	302-03220-000-001	PRESSURE DISC (Ø34.8xØ16x2.5)
39.)		N/A
40.)		N/A
41.)	302-06005-000-027	INPUT GEAR (M1.25x44T)
42.)	307-03006-000-002	BUSHING (Ø15.9xØ22x4.7)
43.)	302-06004-000-049	INPUT SHAFT (M1.75x13TxM1.5x12T)
44.)	302-05514-000-007	BALL BEARING (6200)
45.)	302-05107-000-004	NEEDLE BEARING (HK 1010)
46.)	422-W18-0	INTERNAL CIRCLIP (IS18)
47.)	302-06041-000-001	SLIDER GEAR-CD (M1.75x36T)
48.)	302-06002-000-037	LAY GEAR (M1.5x46T)
49.)	302-06042-000-001	COUNTERSHAFT GEAR (M2.0x26T)
50.)	421-05025-10	PARALLEL KEY (5x5x25)
51.)	421-06015-10	PARALLEL KEY (6x6x15)
52.)		N/A
53.)		N/A
54.)	302-05128-000-001	NEEDLE BEARING (TA1815)
55.)	422-W25-0	INTERNAL CIRCLIP (IS25)
56.)	302-06043-000-001	SLIDER GEAR-AB (M2.0x28T)
57.)	302-06008-000-039	OUTPUT GEAR (M2.0x40T)
58.)	302-04162-000-004	CLUTCH NUT (M27xP1.0x7.8T)
59.)	302-05306-000-001	THRUST BEARING (NTB3047 + AS3047)
60.)		N/A
61.)	0201-0002-00026-117	GEAR HOUSING (GRAY-RAL7016)
62.)	406-M05012080-120	SOCKET CAP SCREW (M5x12xP0.8)
63.)		N/A
64.)		N/A
65.)		N/A
66.)		N/A
67.)	303-02009-004-018	O-RING (Ø20x3)
68.)		N/A
69.)	302-05129-000-001	NEEDLE BEARING (TA3020)
70.)	302-05304-000-002	THRUST BEARING (51106)
71.)	303-02002-004-025	OIL SEAL (Ø40xØ50x7)
72.)	301-03027-000-001	WATER FEED COLLAR
73.)	0299-0018-00000-023	WATER FEED CONNECTOR KIT (1/2")
74.)		N/A
75.)	406-M05040080-000	SOCKET CAP SCREW (M5x40xP0.8)
76.)	303-02002-004-037	OIL SEAL (Ø40xØ52x7)
77.)		N/A
78.)	470-0	DOWEL PIN (Ø4x11.8)
79.)	302-04225-907-001	ANTI-SEIZE CUP
80.)	303-02009-004-071	O-RING (Ø32x1.5)
81.)	302-05404-000-001	THRUST RING (3252)
82.)	302-04226-907-001	ANTI-SEIZE RING
83.)	303-02009-004-021	O-RING (Ø49x1.5)
84.)		N/A
85.)		N/A
86.)		N/A
87.)		N/A
88.)		N/A
89.)		N/A
90.)		N/A
91.)		N/A
92.)		N/A
93.)		N/A
94.)	0299-0172-00000-001	CLUTCH DISC SET
95.)	303-02063-004-002	GASKET (BLACK)
96.)	303-02064-000-001	SWITCH BOOT
97.)	201-0068-00164-002	GEAR SELECTOR (RED-187C)
98.)	302-04026-901-079	SPRING (Ø0.6xØ3.8xØ5x11Tx35L)
99.)	201-0162-00906-001	RELEASE PIN
100.)	0299-0180-00000-002	COUNTERSHAFT SET
101.)		N/A
102.)	305-00093-000-001	BULLS-EYE LEVEL
103.)	202-0055-00901-005	SELECTOR DISC
104.)	202-0055-00901-008	SELECTOR DISC
105.)	304-04012-000-008	LED OVERLOAD LAMP (110V&220V)
106.)	303-01309-000-001	LAMP COVER
107.)	0299-0093-00000-018	SPINDLE SET (1 1/4"-7 x 1/2"BSP-300.5MM)
108.)	302-04498-000-002	STAINLESS BUSHING
109.)	423-00000-0	ZIP TIE (TCVS-170)
110.)	403-M04016002-050	PANHEAD TAPPING SCREW-B (M4x16)
111.)	456-4	BUTT SPLICE CONNECTORS
112.)	206-201503210-01	POWER SUPPLY CABLE (NO PLUG-1.5x3Cx2.1M-H07RNF)
＊	4111-2	GEAR OIL (625cc)
