AEG Spare Parts for Compressor B 100-36
€118.92
Tax included
AEG Spare Parts for Compressor B 100/36
We have the original Spares AEG for Air Compressor B 100/36 - 1121480402 the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Air Compressor B 100/36 - 1121480402. All Spares are original and can be supplied at Low and discounted prices.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
AEG Spare Parts for Compressor B 100/36
Fix Your Air Compressor B 100/36 - 1121480402. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Air Compressor and the respective parts of the code.
| AEG Air Compressor B 100/36 - 1121480402 Pag.1 |
||
| # | Part Num. | Description |
| 1 | 4054720000 | Press. Switch kit |
| 1,01 | 7023050000 | Locking nut |
| 1,02 | 7081090000 | Joint |
| 1,03 | 7088060000 | Joint |
| 1,04 | 7090090000 | Plug |
| 1,05 | 7100640000 | Pressure reducer |
| 1,06 | 7110240000 | Pressure gauge |
| 1,07 | 7110300000 | Pressure gauge |
| 1,08 | 7130570000 | Universal Tap |
| 1,09 | 7250740000 | Pressure switch |
| 1,1 | 7326450000 | Infeed cable |
| 2 | 4080540000 | Screw kit |
| 2,1 | x | Screw |
| 2,2 | x | Screw |
| 2,3 | x | Screw |
| 2,4 | x | Screw |
| 2,5 | x | Nut |
| 2,6 | x | Nut |
| 2,7 | x | Washer |
| 2,8 | x | Washer |
| 3 | 4083010000 | Wheel kit |
| 3,1 | X | Nut |
| 3,2 | X | Wheel pin |
| 3,3 | X | Wheel |
| 4 | 4151110000 | Motor/pulley kit |
| 5 | 4170010000 | Belt guard kit |
| 6 | 5010990008 | Base |
| 7 | 7080160000 | Joint |
| 8 | 7090030000 | Plug |
| 9 | 7130160000 | Discharge tap |
| 10 | 7190090000 | Non return valve |
| 11 | 7192090000 | Safety valve |
| 12 | 7230010000 | Rilsan hose |
| 13 | 7234620000 | Infeed hose |
| 14 | 7360020000 | Rubber |
| 15 | 7360040000 | Rubber |
| 16 | 7370060000 | Belt |
| 17 | 7458510000 | Belt guard Support Staffa Paracinghia |
| 18 | 5157640008 | Tank |
| 19 | 9101880000 | Pump unit |
| FIAC Pump Unit AB 360 9101880000 Pag.2 |
||
| # | Part Num. | Description |
| 1 | 9700001075 | Crankcase |
| 2 | 9700001076 | Carter Cover |
| 3 | 9700000531 | Screw |
| 4 | 9700001077 | O_ring |
| 5 | 9100270140 | Crankshaft |
| 6 | 7060180000 | Bearing |
| 7 | 7060200000 | Bearing |
| 8 | 9100270150 | Oil seal |
| 9 | 9100270160 | Cover |
| 10 | 9100270170 | Cover |
| 11 | 9100280010 | O_ring |
| 12 | 7011420000 | Screw |
| 13 | 9100280020 | Key |
| 14 | 9100270010 | Connection Rod |
| 15 | 9100270020 | Piston pin |
| 16 | 9100270030 | Piston |
| 17 | 4080120000 | Piston rings |
| 18 | 9100270070 | Ring |
| 19 | 9100270080 | Cylinder |
| 20 | 7012220000 | Screw |
| 21 | 9700000408 | Oil level sight glass |
| 22 | 9100270180 | O_ring |
| 23 | 9100270190 | Gasket |
| 24 | x | Valve plate |
| 25 | 7198220000 | Valve stopper |
| 25A | 7010790000 | Screw |
| 26 | 7198210000 | Valve |
| 27 | 9100270210 | Gasket |
| 28 | 9100270100 | Head |
| 31 | 9700001902 | Set Intake filter |
| 33 | 7010080000 | Screw |
| 33A | 7030030000 | Washer |
| 34 | 9100270220 | Air conveyor |
| 35 | 7012090000 | Screw |
| 36 | 7011460000 | Screw |
| 37 | 9700000300 | Breather pipe plug kit |
| 38 | 7030270000 | Washer |
| 39 | 9100270230 | Flywheel |
| 41 | 9700010087 | Washer |
| 42 | 9700002651 | Aftercooler |
| 43 | 9100270280 | O_ring |
| 100 | 4231280000 | Valve plate assembly |
| 102 | 9700002034 | Piston ASSY |
| 102A | 9700010170 | CONROD PISTON KIT |
| 103 | 9700002932 | Gasket KIT |
