Ricambi originali DeWalt per la sostituzione o riparazione della Idropulitrice DXPW008E - 25160.
Nella tabella seguente, cercate il modello della Idropulitrice ed il rispettivo codice del ricambio.![]()
| Cofano DXPW008E - 25160 Pag.1 |
||
| Pos. | Codice | Descrizione |
| 1 | 2060200 | Vite |
| 2 | 2100300 | Vite |
| 3 | 2360760 | Manopola |
| 4 | 3960500 | Supporto |
| 5 | 3960330 | Protezione |
| 6 | 380250 | Vite |
| 7 | 390311 | Rondella |
| 8 | 160311 | Dado |
| 9 | 620440 | Vite |
| 10 | 1270960 | Tubo detergente |
| 11 | 1341030 | Filtro |
| 12 | 1269114 | Premontaggio tubo |
| 13 | 3120110 | Dado |
| 14 | 1340260 | Filtro |
| 15 | 3960300 | Protezione |
| 16 | 3960280 | Manico |
| 17 | 3960150 | Protezione |
| 18 | 3960160 | Protezione |
| 19 | 3960490 | Porta-accessori |
| 20 | 3960290 | Protezione |
| 21 | 3969004 | Manopola |
| 22 | 3960830 | Protezione |
| 23 | 2180150 | Tubo detergente |
| 24 | 50016 | Tappo |
| 25 | 3960530 | Ruota |
| 26 | 3960510 | Telaio |
| 27 | 1060120 | Dado |
| 28 | 3960350 | Protezione |
| 29 | 3960340 | Protezione |
| 30 | 3960360 | Antivibrante |
| 31 | 44803 | Motore |
| 32 | 3960540 | Distanziale |
| 33 | 380210 | Vite |
| 34 | 3960520 | Telaio |
| 35 | 881090 | Linguetta |
| Pompa DXPW008E - 25160 Pag.2 |
||
| 1 | 960090 | Tappo |
| 2 | 960160 | Guarnizione OR |
| 3 | 889052 | Valvola completa |
| 4 | 800860 | Vite |
| 5 | 1381850 | Rondella |
| 6 | 3200090 | Disco |
| 7 | 180101 | Guarnizione OR |
| 8 | 50129 | Valvola |
| 9 | 740290 | Guarnizione OR |
| 10 | 1980740 | Tappo |
| 11 | 880581 | Tappo |
| 12 | 820510 | Guarnizione OR |
| 13 | 2760220 | Anello |
| 14 | 1342761 | Tenuta acqua |
| 15 | 3200680 | Anello |
| 16 | 3220150 | Guida pistone |
| 17 | 3200690 | Guarnizione |
| 18 | 3200700 | Anello |
| 19 | 770260 | Guarnizione OR |
| 20 | 3220140 | Guida pistone |
| 21 | 1260110 | Dado |
| 22 | 1260100 | Rondella |
| 23 | 1780070 | Pistone |
| 24 | 1260091 | Disco |
| 25 | 1260460 | Tenuta olio |
| 26 | 3220010 | Corpo pompa |
| 27 | 880130 | Tappo |
| 28 | 480480 | Guarnizione OR |
| 29 | 3220060 | Pistone |
| 30 | 3220070 | Spina |
| 31 | 3220040 | Biella |
| 32 | 651540 | Guarnizione OR |
| 33 | 3220030 | Coperchio |
| 34 | 3200220 | Vite |
| 35 | 820510 | Guarnizione OR |
| 36 | 880581 | Tappo |
| 37 | 1200430 | Vite |
| 38 | 3200070 | Supporto |
| 39 | 880830 | Guarnizione OR |
| 40 | 3200430 | Tappo |
| 41 | 3229603 | Premontaggio livello olio |
| 42 | 650560 | Guarnizione OR |
| 43 | 200390 | Anello |
| 44 | 1981210 | Cuscinetto |
| 45 | 1080550 | Anello |
| 46 | 3229201 | Premontaggio testa |
| 47 | 23214 | Pompa |
| 48 | 3220450 | Albero |
| 49 | 820440 | Vite |
| 50 | 3220260 | Cuscinetto |
| 51 | 3220430 | Guarnizione OR |
| 52 | 3220270 | Anello |
| 53 | 3220230 | Flangia |
| 54 | 780060 | Vite |
| 55 | 1260770 | Anello |
| 56 | 3220780 | Anello |
| 57 | 40786 | Manometro |
| A | 1818 | Kit valvole |
| B | 2739 | Kit pistoni |
| C | 42555 | Kit tenute olio |
| E | 42556 | Kit tenute acqua |
| F | 42550 | Kit guarnizioni |
| G | 2191 | Kit anelli appoggio |
| Pompa DXPW008E - 25160 Pag.3 |
||
| 1 | 25184 | Valvola completa |
| 2 | 2840970 | Vite |
| 3 | 1060120 | Dado |
| 4 | 3740100 | Tappo |
| 5 | 2500540 | Inserto |
| 6 | 2500550 | Copiglia |
| 7 | 1980220 | Piattello |
| 8 | 2760410 | Molla |
| 9 | 2760400 | Pistone |
| 10 | 2260100 | Guarnizione OR |
| 11 | 660190 | Guarnizione OR |
| 12 | 2760210 | Anello |
| 13 | 2760570 | Guida |
| 14 | 1200690 | Guarnizione OR |
| 15 | 394280 | Guarnizione OR |
| 16 | 2260070 | Otturatore |
| 17 | 2760980 | Sede |
| 18 | 770140 | Guarnizione OR |
| 19 | 2760640 | Anello |
| 20 | 390080 | Guarnizione OR |
| 21 | 1540272 | Vite |
| 22 | 1982520 | Portagomma |
| 23 | 480480 | Guarnizione OR |
| 24 | 1250280 | Sfera |
| 25 | 1560520 | Molla |
| 26 | 2260190 | Guarnizione OR |
| 27 | 3740010 | Corpo valvola |
| 28 | 600180 | Guarnizione OR |
| 29 | 1540630 | Guarnizione OR |
| 30 | 3740020 | Corpo |
| 31 | 880270 | Guarnizione OR |
| 32 | 2260420 | Vite |
| 33 | 2101770 | Guarnizione OR |
| 34 | 2760131 | Otturatore |
| 35 | 2760200 | Molla |
| 36 | 2760120 | Inserto |
| 37 | 1470210 | Guarnizione OR |
| 38 | 2760270 | Guarnizione OR |
| 39 | 2760230 | Raccordo |
| 40 | 480440 | Guarnizione OR |
| 41 | 3600760 | Raccordo |
| 42 | 1122260 | Raccordo |
| F | 42780 | Kit guarnizioni |
| Accessori DXPW008E - 25160 Pag.4 |
||
| 1 | 41843 | Pistola |
| 2 | 40826 | Lancia |
| 3 | 2000570 | Guarnizione OR |
| 4 | 3961050 | Tubo alta pressione |
| 5 | 391000 | Guarnizione OR |
| 6 | 3195 | Ugello |
