Telwin Spare Parts for Inverter Welding SUPERTIG 200 AC/DC-HF 400V
€9.32
Tax included
Telwin Spare Parts for Inverter Welding SUPERTIG 200 AC/DC-HF 400V
TELWIN Authorized Technical Assistance and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Inverter Welding SUPERTIG 200 AC/DC-HF 400V - 832160.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Spare Parts for Inverter Welding SUPERTIG 200 AC/DC-HF 400V
TELWIN Authorized Technical Assistance and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Inverter Welding SUPERTIG 200 AC/DC-HF 400V - 832160.In the following table, look for the model of the Welding and the respective parts of the code.
| SUPERTIG 200 AC/DC-HF 400V 832160 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 112063 | CAPACITOR |
| 2 | 112182 | PROTECTION RECTIFIER |
| 3 | 980798 | KIT CONTROL BOARD |
| 4 | 980799 | BOARD KIT HF AC / DC |
| 5 | 120514 | WIRING INTAKE |
| 6 | 121064 | POTENTIOMETER KNOB |
| 7 | 122060 | KNOB FOR SWITCH |
| 8 | 122329 | THERMOSTAT |
| 9 | 122637 | SWITCH |
| 10 | 122638 | SWITCH |
| 11 | 122682 | SOLENOID |
| 12 | 122694 | RELAY |
| 13 | 122879 | FUSE |
| 14 | 132089 | CABLE ALIM. 3G6 3 M |
| 15 | 152083 | ENGINE |
| 16 | 152113 | FAN |
| 17 | 164993 | TRANSFORMER AUXILIARY |
| 18 | 169617 | TRANSFORMER |
| 19 | 169618 | REACTOR |
| 20 | 169637 | TRANSFORMER H.F. |
| 21 | 312068 | GLAND |
| 22 | 312199 | COVER BRACKET |
| 23 | 312200 | HANDLE FOR FLYER |
| 24 | 312305 | FLAG INDEX |
| 25 | 312328 | HANDLE |
| 27 | 313744 | SCREW ADJUSTMENT |
| 28 | 322200 | WHEEL FENCE |
| 29 | 322246 | WHEEL |
| 30 | 322641 | FRAME |
| 31 | 322890 | BUSH |
| 32 | 323101 | TOGETHER FOR SWITCH KNOB |
| 33 | 422969 | SUPPORT REVOLVING |
| 34 | 432036 | ADAPTOR CYLINDER ARGON IT |
| 35 | 483133 | YOKE |
| 36 | 642302 | FRONT |
| 37 | 644606 | BRACKET CYLINDER |
| 38 | 645414 | FUND |
| 39 | 645416 | RETRO |
| 40 | 651134 | COAT |
| 41 | 655981 | SIDE |
| 42 | 681092 | AXLE FOR WHEELS |
| 43 | 712030 | TOLEDO 250 MASS CLAMP 250A |
| 44 | 712035 | JACK DX 25 |
| 45 | 123437 | CABLE 16 MMQ 3 M - 25 |
| 46 | 722119 | REDUCING PRESSURE GAUGE 2 |
| 47 | 742423 | ST17 TIG TORCH 4 M 180 A |
| 48 | 980800 | KIT RECTIFIER |
| 49 | 990120 | CONNECTION KIT INLET GAS |
| 50 | 712039 | PLUG DX 25 |
| TORCH FOR SUPERTIG 200 AC/DC-HF 400V – 832160 Pag.2 | ||
| 1 | 802244 | KIT 10 CERAMIC NOZZLES NR.4 |
| 1 | 802245 | KIT 10 CERAMIC NOZZLES NR.6 |
| 1 | 802246 | KIT 10 CERAMIC NOZZLES NR.7 |
| 2 | 722248 | INSULATION |
| 4 | 802232 | KIT 10 ELETTR.TUNGSTENO CERIUM D.2,4 MM |
| 4 | 802220 | KIT 10 ELETTR.TUNGSTENO CERIUM D.1 MM |
| 4 | 802222 | KIT 10 ELETTR.TUNGSTENO CERIUM D.1,6 MM |
| 5 | 802241 | KIT 3 CLAMP ELECTRODE D.2,4 MM SERRA |
| 5 | 802240 | KIT 3 CLAMP ELECTRODE D.1,6 MM SERRA |
| 5 | 802239 | KIT 3 CLAMP ELECTRODE D.1,0 MM SERRA |
| 6 | 722192 | HOOD SHORT |
| 7 | 722193 | HOOD LONG |
| 8 | 981442 | KIT CONNECTION 25 |
| 12 | 722999 | PLUG 3P |
| 14 | 452089 | CONTACT BUTTON |
| 16 | 722061 | RING OR |
| 17 | 742042 | BUTTON |
| 18 | 722204 | BODY TORCH |
| 19 | 802251 | KIT 3 DIFFUSERS ELECTRODE D.2,4 MM |
| 19 | 802249 | KIT 3 DIFFUSERS ELECTRODE D.1 MM |
| 19 | 802250 | KIT 3 DIFFUSERS ELECTRODE D.1,6 MM |
| 21 | 990263 | FITTING KIT 3/8 "TORCH TIG |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
