Telwin Spare Parts for Flux Welding Technomig 225 PULSE 230V
We have the original Spares TELWIN for welding machine Flux and Mig-mag Technomig 225 PULSE 230V + ACC.- 852026, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.In the following table, look for the model of the welding machine and theirs spare parts codes.
| TECHNOMIG 225 PULSE 230V + ACC.- 852026 Pag.1 | ||
| # | Description | Part Num. |
| 1 | RESISTANCE | 112048 |
| 2 | RELAY' | 112342 |
| 3 | RECTIFIER | 112357 |
| 4 | CAPACITOR | 112514 |
| 7 | IGBT | 116155 |
| 8 | SENSOR HALL | 116297 |
| 9 | RESISTANCE | 116307 |
| 10 | CONTROL CABLE | 120872 |
| 11 | SWITCH | 121507 |
| 12 | SOLENOID | 122035 |
| 13 | THERMOSTAT | 122571 |
| 14 | BUTTON | 121191 |
| 15 | THERMOSTAT | 122988 |
| 16 | CABLE ALIM. 3G04.00 2:00 M | 132345 |
| 17 | FAN | 152101 |
| 18 | MOTOR 24VDC | 153032 |
| 19 | INDUCTANCE FILTER | 164741 |
| 20 | TRANSFORMER KIT | 980152 |
| 21 | INDUCTANCE | 169476 |
| 22 | PIN | 252000 |
| 23 | PROTECTION CONNECTION TORCH | 312045 |
| 24 | FLYER | 312048 |
| 25 | FRONT | 313980 |
| 26 | REEL | 322172 |
| 27 | RING FOR ASPO | 322173 |
| 28 | FLYER FOR ASPO | 322174 |
| 29 | Chusura SLIDE | 322487 |
| 30 | FRAME | 322537 |
| 31 | HANDLE | 322538 |
| 32 | ASSEMBLY KNOB TO SWITCH | 323101 |
| 33 | SPRING FOR ASPO | 452065 |
| 34 | COAT | 655472 |
| 35 | SIDE PANEL | 655473 |
| 36 | SOCKET DX 50 | 712036 |
| 37 | ATTACK TORCH TOWING | 723163 |
| 38 | TOWING GROUP | 723231 |
| 39 | KIT FUND | 980110 |
| Torch TECHNOMIG 225 PULSE 230V + ACC.- 852026 Pag.2 | ||
| 1 | NUT FIXING | 722007 |
| 2 | NUT FIXING SHEATH | 722013 |
| 3 | TORCH CONNECTION | 742175 |
| 4 | TUBE CONTACT D. 1 MM FE | 722681 |
| 4 | TUBE CONTACT D. 0,6 MM FE | 722415 |
| 4 | TUBE CONTACT D. 1,2 MM IN / FLUX | 722553 |
| 4 | TUBE CONTACT D. 1,2 MM FE | 722682 |
| 4 | TUBE CONTACT D. 0,8 MM FE | 722680 |
| 4 | TUBE CONTACT D. 1 MM IN / FLUX | 722552 |
| 5 | HOUSING GUIDANCE D. 0.6-0.8 MM 3 M | 722437 |
| 5 | HOUSING GUIDANCE D. 1-1.2 MM 3 M | 722689 |
| 5 | HOUSING GUIDANCE D. 1-1.2 MM 3 M AL | 722516 |
| 6 | NOZZLE CONE | 722685 |
| 6 | NOZZLE HEAD END | 722686 |
| 6 | NOZZLE FOR SPOTTER D. 18 MM | 722687 |
| 6 | NOZZLE ROUND | 722684 |
| 7 | NIPPLES STOPS GUAINA | 722598 |
| 8 | RING OR | 722606 |
| 8 | RING OR | 722601 |
| 10 | TUBE HOUSING STOPS | 722600 |
| 11 | GAS DIFFUSER | 722688 |
| 13 | SPRING FOR NOZZLE | 722690 |
| 15 | INSULATION BODY TORCH | 722693 |
| 16 | LANCE | 722696 |
| 17 | TORCH BODY | 722441 |
| 18 | RING FOR TORCH | 742171 |
| 19 | SUPPORT + SPRING TORCH | 742173 |
| 20 | SPRING TORCH | 742174 |
