Telwin Parts for Inverter INVERPULSE 320 MIG/TIG/MMA 400V
€10.50
Tax included
Telwin Parts for Inverter INVERPULSE 320 MIG/TIG/MMA 400V
Original spare parts and replacement parts for Telwin MIG-MAG-FLUX Welding Machine INVERPULSE 320 MIG/TIG/MMA 400V + ACCESSORIES - 815301
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Parts for Inverter INVERPULSE 320 MIG/TIG/MMA 400V
Original spare parts and replacement parts for Telwin MIG-MAG-FLUX Welding Machine INVERPULSE 320 MIG/TIG/MMA 400V + ACCESSORIES - 815301In the following table, look for the model of the drill and the respective parts of the code.
| INVERPULSE 320 MIG/TIG/MMA 400V+ ACC. 815301 | ||
| # | Description | Part Num. |
| 1 | CAPACITOR | 113122 |
| 2 | RELAIS | 113281 |
| 3 | IGBT | 113315 |
| 4 | RESISTOR | 113334 |
| 5 | RESISTANCE | 113336 |
| 6 | FILTER CARD | 114779 |
| 7 | RECTIFIER | 116066 |
| 8 | IGBT | 116603 |
| 9 | SENSOR HALL | 116680 |
| 10 | ELECTROVALVE | 121029 |
| 11 | THERMOSTAT | 121325 |
| 12 | SWITCH | 122017 |
| 13 | FUSE HOLDER | 122159 |
| 14 | FUSE | 122437 |
| 15 | CONNECTOR CABLE | 124350 |
| 16 | TORCH BUTTON CABLE | 124351 |
| 17 | G.R.A./ELECTROVALVE CABLE | 124064 |
| 18 | MAINS CABLE H05VV-F 4G04.00 L=02.50 | 132338 |
| 19 | FAN | 152228 |
| 20 | MOTOREDUCER 24VDC | 153032 |
| 21 | INDUCTANCE | 169550 |
| 22 | HANDWHEEL | 312369 |
| 23 | HINGE SET | 312382 |
| 24 | FRONT PANEL SET | 314146 |
| 25 | SLIDING SHUTTER | 322487 |
| 26 | RING NUT | 322671 |
| 27 | FRONT PANEL | 322833 |
| 28 | BACK PANEL | 322834 |
| 29 | HANDLECOVER | 322848 |
| 30 | REEL | 322864 |
| 31 | SWITCH KNOB SET | 323101 |
| 32 | SPRING | 452138 |
| 33 | HANDLE | 641005 |
| 34 | BOTTOM | 645365 |
| 35 | DIAPHRAGM | 645482 |
| 36 | BACK PANEL | 642113 |
| 37 | FRONT PANEL | 649988 |
| 38 | COVER | 651129 |
| 39 | SIDE PANEL | 655951 |
| 40 | DOOR | 655952 |
| 41 | SOCKET DX 70/95 | 712037 |
| 42 | TORCH CONNECTION | 980127 |
| 43 | WIRE FEED ASSY | 723198 |
| 44 | TRANSFORMER KIT | 980152 |
| 45 | PRIMARY PCB KIT | 980542 |
| 46 | SECUNDARY PCB KIT | 980543 |
| 47 | HALL SENSOR CARD KIT | 980544 |
| 48 | FRONT PANEL + MODULE KIT | 980545 |
| 49 | INTERFACE CARD KIT | 980546 |
| 50 | CONTROL BOARD KIT | 980547 |
| 51 | GAS PIPE CONNECTOR KIT | 980548 |
| 52 | REEL KIT | 980549 |
| 53 | OUTPUT INDUCTANCE KIT | 980550 |
| 54 | POWER TRANSFORMER KIT | 980551 |
| 55 | CABLE BUSHING KIT | 990439 |
| 56 | 4 DIODES KIT | 990795 |
| 57 | AUXILIARY TRANSFORMER | 990987 |
| 58 | FEED ROLL D. 0,6-0,8 MM FE | 722225 |
| 59 | FEED ROLL D. 0,8-1 MM FE | 722227 |
| 60 | WIRE CONDUIT Ø 2X5 | 722358 |
| 61 | ROLLERFIXING SCREW | 742397 |
| 62 | WIRE GUIDE INLET | 742064 |
| 63 | FEED ROLL D. 0,8-1 AL | 742304 |
| 64 | LEFT ANCHOR FOR PRESSURE ROLLER | 742307 |
| 65 | RIGHT ANCHOR FOR PRESSURE ROLLER | 742308 |
| 66 | FEED ROLL D. 1-1,2 MM FE | 742366 |
| 67 | GAS HOSE KIT | 990097 |
| 68 | ARGON GAS BOTTLE IT ADAPTOR | 432036 |
| 69 | TOLEDO 400 WORK CLAMP | 712032 |
| 70 | PLUG DX 70 | 712041 |
| 71 | CABLE 70MMQ 3M-WORK CLAMP-DX 70 | 713142 |
| 72 | GAS REGULATOR 2 MANOMETERS | 722346 |
| 73 | MT36 MIG TORCH 3 M 400 A | 742186 |
| 74 | ADAPTER | 742166 |
| 75 | MOTOR DRIVE GEAR | 742348 |
| 76 | GEAR | 742495 |
| TORCIA INVERPULSE 320 MIG/TIG/MMA 400V+ACC. 815301 | ||
| 1 | RING NUT | 722007 |
| 2 | LINER NUT | 722013 |
| 3 | CONTACT TIP D. 1,2 MM AL/FLUX | 722553 |
| 3 | CONTACT TIP D. 1 MM FE | 722681 |
| 3 | CONTACT TIP D. 1 MM AL/FLUX | 722552 |
| 3 | CONTACT TIP D. 1,2 MM FE | 722682 |
| 3 | CONTACT TIP D. 1,6 MM FE | 722797 |
| 3 | CONTACT TIP D. 0,6 MM FE | 722415 |
| 3 | CONTACT TIP D. 0,8 MM FE | 722680 |
| 3 | CONTACT TIP D. 1,6 MM AL | 722818 |
| 4 | WIRE GUIDE HOSE D. 1,6-2 MM 3 M AL | 722597 |
| 4 | WIRE GUIDE HOSE D. 1-1,2 MM 3 M | 722689 |
| 4 | WIRE GUIDE HOSE D. 0,6-0,8 MM 3 M | 722437 |
| 4 | WIRE GUIDE HOSE D. 1-1,2 MM 3 M | 742164 |
| 5 | TORCH ASSY | 722441 |
| 6 | THIN HEADED NOZZLE | 722793 |
| 6 | CONICAL NOZZLE | 722792 |
| 6 | SPOT WELDING NOZZLE | 722794 |
| 7 | WIRE GUIDE LOCKING NIPPLES | 722599 |
| 7 | WIRE GUIDE LOCKING NIPPLES | 722598 |
| 8 | WIRE GUIDE LOCKING TUBE | 722600 |
| 9 | OR RING | 722606 |
| 9 | OR RING | 722601 |
| 12 | SWAN NECK | 722788 |
| 13 | CONTACT TIP HOLDER | 722789 |
| 14 | TORCH CONNECTION | 742175 |
| 15 | GAS DIFFUSER | 722791 |
| 16 | TORCH RING NUT | 742171 |
| 17 | TORCH HOLDER + SPRING | 742173 |
| 18 | TORCH SPRING | 742174 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
INVERPULSE 320 - 815301
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM OR S/N CODE TELWIN:
- TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
