Telwin Parts for Flux Welding Digital Mig 220 230-400V
€4.01
Tax included
Telwin Parts for Flux Welding Digital Mig 220 230-400V
Telwin original spare parts for to replace broken parts for to fix Welding Machine Digital Mig 220 230-400V - 820024.Fix Your Welding Machine. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Parts for Flux Welding Digital Mig 220 230-400V
Telwin original spare parts for to replace broken parts for to fix Welding Machine Digital Mig 220 230-400V - 820024.Fix Your Welding Machine. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the welding machine and theirs spare parts codes.
| DIGITAL MIG 220 230-400V cod. 820024 Pag.1 | ||
| 1 | RECTIFIER PROTECTION | 112182 |
| 2 | RECTIFIER | 112311 |
| 3 | CABLE CARD/CONNECTOR | 120351 |
| 4 | SWITCH | 121521 |
| 5 | CONTACTOR | 122459 |
| 6 | THERMOSTAT | 122132 |
| 7 | ELECTRO-VALVE | 122682 |
| 8 | SWITCH | 122725 |
| 9 | FUSE | 122879 |
| 10 | MAINS CABLE 4G2.5 3 M | 132039 |
| 11 | SHUNT | 152028 |
| 12 | FAN MOTOR | 152110 |
| 13 | FAN BLADE | 152111 |
| 14 | WIRE FEED MOTOR | 153033 |
| 15 | TRANSFORMER | 164086 |
| 16 | AUXILIARY TRANSFORMER | 164991 |
| 17 | REACTANCE | 169370 |
| 18 | REEL HANDWHEEL | 312137 |
| 19 | HANDLE | 312328 |
| 20 | FRONT PANEL + MODULE KIT | 980660 |
| 21 | REEL | 322081 |
| 22 | SPACER | 322180 |
| 23 | FIXED WHEEL | 322200 |
| 24 | WHEEL | 322246 |
| 25 | FRONT PANEL | 322602 |
| 26 | SWITCH KNOB SET | 323101 |
| 27 | SUPPORT | 422817 |
| 28 | SWIVEL SUPPORT | 422969 |
| 29 | ARGON GAS BOTTLE IT ADAPTOR | 432036 |
| 30 | REEL SPRING | 452057 |
| 31 | BRACKET FOR BOTTLE | 644606 |
| 32 | BACK PANEL | 644757 |
| 33 | CARD COVER | 644832 |
| 34 | FRONT PANEL | 642141 |
| 35 | DIAPHRAGM | 645594 |
| 36 | BOTTOM | 644961 |
| 37 | COVER KIT | 980854 |
| 38 | DOOR KIT | 980898 |
| 39 | WHEELS AXLE | 681092 |
| 40 | TOLEDO 250 WORK CLAMP 250A | 712030 |
| 41 | SOCKET DX 25 | 712035 |
| 42 | PLUG DX 25 | 712039 |
| 43 | FEED ROLL D. 0,6-0,8 MM FE | 722112 |
| 44 | GAS REGULATOR 2 MANOMETERS | 722119 |
| 45 | TORCH CONNECTION | 723216 |
| 46 | ROLLERFIXING SCREW | 742397 |
| 47 | WIRE GUIDE INLET | 742064 |
| 48 | FEED ROLL D. 0,8-1 MM AL | 742090 |
| 49 | ANCHOR FOR PRESSURE ROLLER | 742096 |
| 50 | MT15 MIG TORCH 3 M 220 A | 742180 |
| 51 | WIRE CONDUIT Ø 2X5 | 742260 |
| 52 | BLACK KNOB SET | 980772 |
| 53 | GAS HOSE KIT | 990097 |
| 54 | REEL KIT | 990264 |
| 55 | KIT 2 ROLLS WIREFEEDER | 990632 |
| 56 | CABLE 16 MMQ 3 M - 25 | 123437 |
| TORCH DIGITAL MIG 220 230-400V cod. 820024 Pag.2 | ||
| 1 | RING NUT | 722007 |
| 2 | LINER NUT | 722013 |
| 3 | SWAN NECK DIFFUSER | 722305 |
| 5 | NOZZLE SPRING | 722319 |
| 6 | DIFFUSER INSULATION | 722326 |
| 7 | TORCH HOLDER | 742172 |
| 8 | CONTACT TIP D. 0,8 MM FE | 722416 |
| 8 | CONTACT TIP D. 0,6 MM FE | 722415 |
| 10 | CYLINDRICAL NOZZLE | 722149 |
| 10 | CONICAL NOZZLE | 722423 |
| 11 | WIRE GUIDE HOSE D. 1-1,2 MM 3 M | 722689 |
| 11 | WIRE GUIDE HOSE D. 0,6-0,8 MM 3 M | 722437 |
| 13 | TORCH ASSY | 722441 |
| 14 | TORCH CONNECTION | 742175 |
| 15 | TORCH RING NUT | 742171 |
| 16 | TORCH CONNECTION | 722325 |
| 17 | TORCH CONNECTION INSULATION | 722693 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Digital Mig 220 - 820024
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM OR S/N CODE TELWIN:
- TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
