Telwin Spare Parts for Flux Welding Mastermig 500 - 822008
€14.36
Tax included
Telwin Spare Parts for Flux Welding Mastermig 500 - 822008
TELWIN Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for welding machine Flux and Mig-mag Mastermig 500 -822008
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Spare Parts for Flux Welding Mastermig 500 - 822008
TELWIN Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for welding machine Flux and Mig-mag Mastermig 500 -822008.In the following table, look for the model of the welding machine and theirs spare parts codes.
| SPARE PARTS MASTERMIG 500 230-400V AQUA cod. 822008 Pag.1 | ||
| # | Description | Part Num. |
| 0 | MT500 TORCIA MIG 3 M AQUA | 722625 |
| 0 | THERMOSTAT KIT | 981968 |
| 1 | THREE PHASE RECTIFIER | 121391 |
| 2 | BASE VOLTAGE CHANGE | 112163 |
| 3 | RECTIFIER PROTECTION | 112182 |
| 4 | Potentiometer | 116411 |
| 5 | Potentiometer | 113574 |
| 6 | TIMER CONTROL PCB KIT | 980714 |
| 7 | CONTACTOR | 121214 |
| 8 | SWITCH | 121399 |
| 9 | YELLOW LAMP | 122594 |
| 10 | ELECTRO VALVE | 122682 |
| 11 | SWITCH | 122725 |
| 13 | SWITCH | 121400 |
| 14 | FUSE | 122879 |
| 15 | POWER CORD 4G6 3 M | 132202 |
| 16 | ENGINE | 152083 |
| 17 | FAN | 152113 |
| 18 | 24V DC MOTOR CONTROL | 153039 |
| 19 | TRANSFORMER | 169640 |
| 20 | AUXILIARY TRANSFORMER | 164991 |
| 21 | REACTOR | 169512 |
| 22 | TORCH ATTACK PROTECTION | 312105 |
| 23 | VOLVO for ASPO | 312137 |
| 24 | HANDLE KIT | 980082 |
| 25 | REEL | 322081 |
| 26 | DISTANCE | 322180 |
| 27 | WHEEL WITH SUPPORT | 322187 |
| 28 | WHEEL | 322772 |
| 29 | FRAME | 322736 |
| 30 | ASSEMBLE THE SWITCH FOR COMMUTER | 323101 |
| 31 | WHEELS | 422020 |
| 32 | ARGON BOMB ADAPTER IT | 432036 |
| 33 | SPRING FOR ASPO | 452057 |
| 34 | TAPE APPROACHES TORCH | 644444 |
| 35 | gas cylinder | 644447 |
| 36 | HANDLE TRAINAFILO | 644449 |
| 37 | FUND | 645102 |
| 38 | BACK | 645103 |
| 39 | DIAPHRAGM | 645105 |
| 40 | FRONT | 642051 |
| 41 | SIDE | 645236 |
| 42 | SIDE | 651059 |
| 43 | FUND | 645235 |
| 44 | BACK | 645419 |
| 45 | KIT SPORTELLO | 980918 |
| 46 | KIT MANTELLO | 980866 |
| 47 | FRONT | 649829 |
| 48 | TOLEDO 400 GROUND CAPTURE | 712032 |
| 49 | SOCKET DX 50 | 712036 |
| 50 | PLUG DX 50 | 712040 |
| 51 | ROLLER 0.6-0.8 MM FE | 722225 |
| 52 | ROLLER D. 0,8-1 MM FE | 722227 |
| 53 | PRESSURE REDUCER 2 MANOMETERS | 722346 |
| 54 | CAPILLARY TUBE Ø 2X5 | 742365 |
| 55 | TORCH CONNECTION | 723229 |
| 56 | CABLE 50 MMQ 3 M MASS DX50 CURVE | 723031 |
| 57 | Wire feed assy 4 Rollers | 981928 |
| 58 | ROLLERFIXING SCREW | 742397 |
| 60 | ROLLER D. 0,8-1 AL | 742304 |
| 61 | GUIDAFILO ENTRY | 742064 |
| 62 | ALWAYS LEFT CONTRACTOR | 981929 |
| 63 | RIGHT RIGHT CONTRAST | 981930 |
| 64 | KIT SPIN 8 POLES | 990226 |
| 65 | KIT ASPO | 990264 |
| 66 | KIT KNOB | 990328 |
| 67 | KIT PRESA | 990330 |
| 68 | MOTOR INPUT KIT | 990097 |
| 69 | WHEEL TOOL | 322773 |
| 70 | TORQUE D. 1,2-1,6 MM FE | 722241 |
| 71 | TURN D. 1-1,2 MM FE | 742366 |
| 72 | PROTECTION | 322814 |
| 73 | ADAPTER | 742166 |
| 74 | ENGINE GEAR | 742348 |
| 75 | GEAR | 742590 |
| TORCHE MASTERMIG 500 230-400V AQUA cod. 822008 Pag.2 | ||
| 1 | FIXING GEAR | 722007 |
| 2 | DADO FISSAGGIO GUAINA | 722013 |
| 3 | GUAINA GUIDAFILO D. 1.6-2 MM 3 M AL | 722597 |
| 3 | GUAINA G.F. D.2-2.4 MT.3 | 722820 |
| 3 | GUIDA GUILD Ø 1,2-1,6 MM 3 M YELLOW | 722588 |
| 3 | GUIDAFILO Ø 1,0-1,2 MM 3M RED | 722590 |
| 3 | GUAINA GUIDAFILO D 1-1,2 MM 3 M | 742164 |
| 4 | CONTROL TUBE Ø 2.4 MM | 722773 |
| 4 | NOZZLE D. 1 MM FE | 722582 |
| 4 | NOZZLE D. 2 MM AL / FLUX | 722772 |
| 4 | NOZZLE D. 1 MM AL / FLUX | 722769 |
| 4 | NOZZLE D. 1.2 MM AL / FLUX | 722770 |
| 4 | NOZZLE D. 1.6 MM FE | 722587 |
| 4 | NOZZLE D. 0,8 MM FE | 722581 |
| 4 | NOZZLE D. 1.2 MM FE | 722583 |
| 4 | NOZZLE D.2,0 | 722586 |
| 4 | D. 1.6 MM FLUX NOZZLE | 722771 |
| 4 | NOZZLE D. 1,2 MM AL | 742160 |
| 4 | NOZZLE D. 1 MM AL | 742159 |
| 4 | NOZZLE D. 1.6 MM AL | 742161 |
| 5 | GAS DIFFUSER | 722593 |
| 6 | CONCEPT URGENT | 722585 |
| 6 | TUNNING SNUNE | 722594 |
| 6 | CLINICAL SUMMER | 722595 |
| 7 | NIPPLES | 722598 |
| 7 | NIPPLES | 722599 |
| 8 | NOZZLE | 722600 |
| 9 | RING OR | 722606 |
| 9 | RING OR | 722601 |
| 10 | ISOLANT WASHER | 722603 |
| 13 | CLAMP | 232114 |
| 14 | QUICK REDUCTION REDUCTION | 722608 |
| 21 | WATER / POWER CABLE MT.3 | 722615 |
| 24 | REAR TORQUE BODY | 722619 |
| 26 | BUTTON | 722677 |
| 28 | LAUNCHES | 722708 |
| 29 | CONTACT NOZZLE HOLDER | 722709 |
| WATER GROUP MASTERMIG 500 230-400V AQUA cod. 822008 Pag.3 | ||
| 1 | SWITCH | 122381 |
| 1 | COVER SWITCH | 122353 |
| 2 | CABLE ALIM. 3G1.5 0 M | 132335 |
| 3 | FAN | 152217 |
| 4 | FOOT | 323001 |
| 5 | HANDLE | 322267 |
| 6 | FILTER | 322268 |
| 7 | RAPID ATTACK | 602033 |
| 8 | RADIATOR | 602038 |
| 9 | KIT VALVE | 990955 |
| 10 | FITTING | 602051 |
| 11 | ELECTROPOMPLE KIT | 990382 |
| 13 | FRONT KIT | 990835 |
| 14 | COAT | 650687 |
| 15 | KIT PRESSACAVO + GHIERA | 990046 |
| 16 | COMPLETE TANK KIT | 990363 |
| 18 | BRACKET | 644401 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
