Tanaka Spare Parts for Brush Cutter TBC-600
€1.11
Tax included
Tanaka Spare Parts for Brush Cutter TBC-600
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brush Cutter TBC-600.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Tanaka Spare Parts for Brush Cutter TBC-600
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brush Cutter TBC-600.
In the following table, look for the model of the Brush Cutter and the respective parts of the code.
| Brush Cutter TBC-600 | ||
| # | Part Num. | Description |
| 1 | 6687468 | SPARK PLUG CAP ASS'Y |
| 2 | 6688336 | SPARK PLUG RUBBER COVER |
| 4 | 6685470 | CYLINDER SET |
| 5 | 6684586 | HEX.HOLE BOLT M5X18/S |
| 6 | 6685738 | CYLINDER GASKET |
| 7 | 6686126 | PISTON RING |
| 8 | 6685887 | PISTON SET |
| 9 | 6686019 | PISTON PIN 10X35 |
| 10 | 6686026 | PISTON PIN CIRCLIP |
| 11 | 6685993 | PISTON PIN COLLAR |
| 12 | 6686190 | CRANK SHAFT - DISCONTINUED |
| 13 | 6695602 | NEEDLE BEARING, 2X8.8 |
| 14 | 6686457 | WOOD-RUFF KEY 3X13X5 |
| 31 | 6695139 | SMALL NUT 10 |
| 32 | 6686553 | CRANK CASE ASS'Y |
| 33 | 6686713 | CRANK CASE GASKET |
| 34 | 6695637 | OIL SEAL UD15257 |
| 35 | 6202C3 | BALL BEARING 6202C3 |
| 36 | 6686463 | CRANK SHAFT WASHER 15.2X22 |
| 37 | 6686470 | SHIM 0.10 |
| 37 | 6686471 | SHIM 0.15 |
| 37 | 6686472 | SHIM 0.20 |
| 37 | 6686473 | SHIM 0.30 |
| 39 | 6684826 | S.WASHER 6 |
| 40 | 6684825 | HEX. SOCKET HD. BOLT (W/BUTTON) M6 |
| 41 | 6684872 | LOCK NUT M6 |
| 43 | 6687371 | MAGNETO ROTOR COMP. |
| 46 | 6687662 | IGNITION COIL |
| 48 | 6684864 | SMALL WASHER 5 |
| 71 | 6692225 | FUEL TANK CUSHION RUBBER |
| 72 | 6689883 | INLET MANUFOLD GASKET |
| 73 | 6689950 | CARB. INSULATOR SET |
| 74 | 6689826 | CARBURETOR GASKET |
| 75 | 6690468 | CARBURETOR SET HDA306 |
| 75A | 6697706 | CARBURETOR SET HDA180A |
| 77 | 6691004 | CHOKE LEVER |
| 78 | 6685267 | FUEL PIPE 2.5X4X90 |
| 78A | 6692347 | FUEL PIPE 2.5X4X80 |
| 79 | 6695139 | SMALL NUT 10 |
| 80 | 6695235 | INNER TOOTHED WASHER 10 |
| 81 | 6690080 | PRIMING PUMP COMP. |
| 81A | 6685139 | PRIMING PUMP COMP. |
| 83 | 6684619 | CLIP,6.3 DIA. |
| 84 | 6692273 | PUMP FILTER BODY ASS'Y |
| 85 | 6691526 | FUEL TANK, WHITE |
| 86 | 6697846 | RETURN GROMMET |
| 87 | 6691763 | TANK CAP D ASS'Y, BLACK |
| 87 | 6691715 | TANK CAP D ASS'Y,BLACK |
| 88 | 6691927 | TANK HOLDING BAND |
| 89 | 6692193 | CUSHION RUBBER |
| 90 | 6695386 | SCREW 5X16/PS |
| 93 | 6691337 | SWIVEL CAP |
| 112 | 6695383 | SCREW 5X12/PS |
| 113 | 6684667 | HEX.HOLE BOLT M5X12/S |
| 114 | 6684918 | WASHER M5 (BLACK) |
| 115 | 6695088 | HEX. HOLE BUTTON SCREW 6X65 |
| 116 | 6684639 | BOLT WASHER 6 |
| 117 | 6692463 | MUFFLER SET |
| 118 | 6692883 | MUFFLER SPECIAL GASKET |
| 119 | 6692648 | TAIL PIPE SET, SPARE |
| 120 | 6695325 | SCREW 4X8/S |
| 120 | 6685109 | MACHINE SCREW (W/SP. WASHER) M4X8 |
| 121 | 6692741 | MUFFLER GASKET |
| 122 | 6687242 | HEAT SHIELD |
| 123 | 6695389 | SCREW 5X18/PS |
| 124 | 6692205 | TANK BRACKET |
| 125 | 6692227 | FUEL TANK CUSHION RUBBER |
| 126 | 6689645 | CLUTCH WASHER B |
| 127 | 6688615 | CLUTCH ARM |
| 128 | 6689429 | CLUTCH SPRING |
| 129 | 6695203 | WAVE WASHER 10 |
| 130 | 6689628 | CLUTCH STEP BOLT |
| 151A | 6697645 | RECOIL STARTER BODY ASS'Y |
| 152 | 6693025 | RECOIL STARTER BODY COMP. |
| 152A | 6697646 | RECOIL STARTER BODY COMP |
| 153 | 6693007 | STARTER ROPE REEL |
| 153A | 6697647 | STARTER ROPE REEL |
| 154 | 6693114 | RECOIL SPRING |
| 156 | 6693607 | STARTER HANDLE CAP |
| 157 | 6693232 | STARTER HANDLE |
| 158 | 6693634 | SET SCREW |
| 159 | 6693302 | STARTER PAWL |
| 160 | 6685101 | D4E RETAINING RING |
| 160 | 6685101 | D4E RETAINING RING |
| 161 | 6695395 | SCREW 5X25PS |
| 162 | 6693345 | STARTER PAWL SPRING |
| 163 | 6693395 | STARTER PULLEY |
| 163A | 6697644 | STARTER PULLEY ASS'Y |
| 181 | 6699506 | CLEANER BODY SET |
| 182 | 6692244 | COLLAR 5.8 |
| 183 | 6690848 | BLOW OVER CHECK BOARD COMP. |
| 184 | 6690357 | CLEANER ELEMENT |
| 185 | 6690149 | CLEANER COVER ASS'Y |
| 186 | 6690383 | COVER FIXING BOLT |
| 187 | 6695354 | SCREW 5X60/S |
| 201 | 6685210 | SCREW |
| 202 | 6691420 | PUMP BODY |
| 203 | 6691455 | PUMP GASKET |
| 204 | 6691446 | PUMP DIAPHRAGM |
| 205 | 6684700 | INLET SCREEN |
| 206 | 6690766 | IDLE ADJUST SPRING |
| 207 | 6690736 | IDLE ADJUST SCREW |
| 208 | 6685215 | NEEDLE VALVE |
| 211 | 6685219 | HINGE PIN |
| 212 | 6685218 | HINGE PIN SET SCREW |
| 213 | 6690840 | DIAPHRAGM GASKET |
| 213A | 6690838 | DIAPHRAGM GASKET |
| 214 | 6690829 | METERING DIAPHRAGM COMP. |
| 214A | 6690828 | METERING DIAPHRAGM COMP. |
| 215 | 6690434 | AIR PURGE COMP. |
| 217A | 6685223 | SET SCREW |
| 221 | 6688585 | CLUTCH DRUM COMP. |
| 222 | 6695559 | BALL BEARING #6202Z, 35MM/OD |
| 223 | 6695296 | STOP RING C-35, INNER |
| 224 | 6695285 | STOP RING C-15, OUTER |
| 225 | 6695093 | HEX.HOLE BOLT 6X25 |
| 226 | 6686975 | FAN CASE OR |
| 228 | 6695183 | SMALL WASHER 6 |
| 231 | 6689476 | DRIVE SHAFT, 1552L |
| 232 | 6689403 | DRIVE SHAFT PIPE |
| 233 | 6689515 | BUSHING ASS'Y |
| 234 | 6691207 | KNOB BOLT |
| 235 | 6691143 | HANDLE BRACKET A |
| 236 | 6691159 | HANDLE BRACKET B |
| 237 | 6691237 | SUPPORT HOLDER |
| 238 | 6691232 | HANDLE SUPPORT COMP. |
| 239 | 6689102 | SPECIAL NUT M6X1.0 |
| 240 | 6689165 | ANTI-VIBE RUBBER |
| 241 | 6695175 | LOCK NUT 6 UPS-P |
| 242 | 6695094 | HEX. HOLE BOLT 6X30 |
| 243 | 6688016 | CORD CLAMP |
| 245 | 6688025 | CORD CLAMP |
| 246 | 6691079 | HANDLE |
| 247 | 6693730 | THROTTLE LEVER 20 |
| 248 | 6687549 | PROTECTION TUBU 990L |
| 249 | 6684721 | TRIGGER LOCK OUT |
| 250 | 6684722 | RETURN SPRING |
| 251 | 6684723 | THROTTLE LEVER |
| 253 | 6684725 | SCREW M4X20 (BLACK) |
| 255 | 6684727 | CONTAL NUT 5 |
| 256 | 6687440 | STOP BOTTOM COMP. |
| 256A | 6687441 | STOP SWITCH COMP. |
| 257 | 6694009 | THROTTLE WIRE |
| 258 | 6693955 | THROTTLE WIRE COMP. |
| 258A | 6693956 | THROTTLE WIRE COMP. |
| 271 | 6688801 | GEAR CASE ASS'Y, 30 DIA |
| 272 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 273 | 6684741 | STOP RING C-28,INNER |
| 274 | 6684664 | STOP RING C-12 OUTER |
| 275 | 6695532 | BALL BEARING #6001Z, 28MM/OD |
| 277 | 6688703 | GEARCASE, SILVER |
| 278 | 6684834 | SPRING WASHER 5 |
| 279 | 6684829 | HEX. SOCKET HD. BOLT M5X12 |
| 282 | 6688942 | GEAR SHAFT 6X11X14 |
| 284 | 6695298 | STOP RING C-40, INNER |
| 285 | 6689022 | CUTTER HOLDER |
| 286 | 6689052 | CUTTER HOLDER CAP.6X11X14 |
| 287 | 6688982 | PROTECTION COVER A COMP. |
| 288 | 6695418 | SCREW 5X16/WS |
| 289 | 6689072 | CUTTER FIXING NUT,L/H |
| 291 | 6688866 | GEAR-PINION SET, SPARE |
| 292 | 6684714 | HEX. HOLE BUTTON SCREW M6X25S |
| 293 | 6690299 | COVER BRACKET |
| 294 | 6690230 | BLADE GUARD 30 CE |
| 294A | 6690264 | BLADE GUARD 30 CE |
| 295 | 6684748 | GUARD HOLDER |
| 296 | 6690372 | COVER GUARD |
| 296A | 6690376 | BLADE GUARD |
| 297 | 6693386 | KNIFE |
| 297A | 6684750 | KNIFE |
| 298 | 6695334 | SCREW 5X12/S |
| 298A | 6684751 | TAPPING SCREW 4X14 |
| 299 | 6684965 | NUT M5 |
| 300 | 6684753 | TAPPING SCREW 5X20 |
| 300 | 6684753 | TAPPING SCREW 5X20 |
| 301 | 6684754 | KNIFE |
| 301 | 6684754 | KNIFE |
| 304 | 6685075 | NUT M5 (BLACK) |
| 305 | 6684834 | SPRING WASHER 5 |
| 508 | 6695792 | BLADE B3/12/3.0 |
| 519 | 6693358 | REEL SLIDER |
| 520 | 6693338 | CUTTING BODY CAP |
| 523 | 6688994 | PROTECTION COVER B |
| 524 | 6688986 | WINDING PROTECTOR COVER |
| 525 | 6695797 | SHOULDER HARNESS D5 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Tanaka websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Tanaka brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
