Hitachi Spare Parts for Engine Chainsaw CS25EC-SC
Hitachi-HIKOKI Tanaka original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair problems for Pruning Chainsaw CS25EC-SC.
In the following table, look for the model of the chainsaw and ripettivo spare part.
| CHAINSAW CS25EC-SC EU | ||
| C2401 CYLINDER/PISTON/CRANK SHAFT Pag.1 | ||
| # | Part Num. | Description |
| 1 | 6687468 | SPARK PLUG CAP ASS'Y |
| 2 | 6685086 | SPARK PLUG BPMR6A |
| 6 | 6685461 | CYLINDER SET |
| 9 | 6685726 | CYLINDER GASKET |
| 10 | 6686119 | PISTON RING |
| 11 | 6685881 | PISTON SET |
| 12 | 6684591 | PISTON PIN |
| 13 | 6684590 | PISTON PIN CIR CLIP |
| 16 | 6686173 | CRANK SHAFT COMP. |
| 31 | 6684682 | HEX.HOLE BOLT 4X15/PS |
| 32 | 6687668 | IGNITION COIL COMP. - discontinued |
| 35 | 6692900 | CORD INSULATOR TUBE |
| 6601179 | IGNITION COIL + AIR DEFLECTOR SET | |
| C2402 CRANK CASE Pag.2 | ||
| 19 | 6685098 | SHIM S T0.2 |
| 19 | 6685099 | SHIM S T0.3 |
| 19 | 6686475 | SHIM 0.4 |
| 21 | 6685104 | FLYWHEEL NUT |
| 23 | 6685103 | BOLT WASHER M7 |
| 24 | 6687378 | MAGNETO ROTOR SET |
| 26 | 6693305 | STARTER PAWL |
| 27 | 6685105 | STARTER PAWL SPRING |
| 28 | 6685101 | D4E RETAINING RING |
| 30 | 6692412 | FUEL PIPE 2.5X4.5X175 |
| 31 | 6692304 | CLIP 4.5 |
| 35 | 6684597 | INSULATOR TUBE 50L |
| 36 | 6695046 | HEX. HOLE BOLT 5X16 |
| 37 | 6685226 | WASHER M5 (BLACK) |
| 41 | 6686526 | CRANK CASE ASSY |
| 42 | 6684607 | OIL SEAL TB 12227 |
| 43 | 6686703 | CRANK CASE GASKET |
| 44 | 6695535 | BALL BEARING 6001 C3 |
| 46 | 6685095 | NEEDLE ROLLER 2.5X9.8 |
| 50 | 6695514 | HEX.HOLE BOLT 5X22/WS |
| C2403 ENGINE CASE/AIR CLEANER Pag.3 | ||
| 40 | 6687328 | AIR DEFLECTOR ASS'Y |
| 42 | 6691466 | PIPE HOLDING GROMMET |
| 45 | 6689872 | INLETMANIFOLD GASKET |
| 49 | 6689819 | INLETMANIFOLD SPACER |
| 50 | 6689788 | INLETMANIFOLD COMP. - DISCONTINUED |
| 58 | 6689997 | CARB. FIXING PLATE |
| 60 | 6690811 | DUST COVER |
| 61 | 6692587 | CHOKE ROD HOLDING RUBB |
| 62 | 6692515 | CHOKE BUTTOM COMP. |
| 63 | 6690679 | CARUB. SUPPORT PLATE |
| 64 | 6687960 | ADJUSTER CAP |
| 65 | 6687980 | IDLE GROMMET |
| 66 | 6695157 | UNUT 5 |
| 70 | 6695484 | HEX. HOLE BOLT 4X10S |
| 72 | 6684661 | WASHER 5 |
| 73 | 6694908 | SCREW 5X45 |
| C2404 FUEL LINE/OIL FILTER Pag.4 | ||
| 1 | 6685247 | SHIELD TUBE |
| 2 | 6685198 | CLIP D6 |
| 3 | 6684661 | WASHER 5 |
| 4 | 6690919 | OIL FILTER |
| 5 | 6685249 | OIL FILTER BODY ASS'Y |
| 8 | 6685246 | PROTECTIVE COIL |
| 10 | 6692126 | PUMP FIXING PLATE |
| 11 | 6685139 | PRIMING PUMP COMP. |
| 12 | 6692413 | FUEL PIPE |
| 13 | 6692350 | FUIL PIPE 2.5X4.5X140 |
| 16 | 6692422 | FUEL GROMMET |
| 17 | 6685199 | PUMP FILTER BODY |
| 20 | 6691286 | RETURN GROMMET - DISCONTINUED |
| 30 | 6687504 | STOP SWITCH COMP. |
| 35 | 6685180 | TANK CAP ASS'Y |
| 37 | 6685179 | TANK CAP GASKET |
| 50 | 6685136 | SEAL LOCK BOLT M5X15 |
| 51 | 6691368 | ENGINE CASE ASS'Y |
| 52 | 6685173 | AIR VENT VALVE (B) |
| 54 | 6692086 | AIR VENT ASS'Y |
| 55 | 6691380 | ENGINE CASE COVER |
| 60 | 6685178 | OIL TANK CAP ASS'Y |
| 62 | 6685177 | OIL TANK CAP PACKING |
| C2405 RECOIL STARTER Pag.5 | ||
| 0 | 6692912 | RECOIL STARTER ASS'Y |
| 1 | 6684679 | SET SCREW |
| 2 | 6685183 | DAMPER SPRING |
| 3 | 6685184 | STARTER PULLEY |
| 4 | 6685186 | ROPE |
| 5 | 6685185 | SPRING CASE SET |
| 7 | 6685188 | STARTER HANDLE |
| 9 | 6686953 | FAN CASE COMP. |
| 10 | 6685191 | TAPPING SCREW D4.5X20 |
| 14 | 6692936 | CAM PLATE |
| 15 | 6685189 | PLATE |
| 16 | 6690065 | CLEANER FILTER ELEMENT |
| 17 | 6686315 | CLEANER COVER |
| 18 | 6685228 | CLEANER KNOB |
| C2406 CARBURETOR Pag.6 | ||
| 0 | 6690651 | CARBURETOR ASS'Y WT797A |
| 2 | 6684700 | INLET SCREEN |
| 3 | 6691438 | PUMP COVER |
| 4 | 6685210 | SCREW |
| 5 | 6685212 | PUMP GASKET |
| 6 | 6685213 | PUMP DIAPHRAGM |
| 9 | 6685217 | CONTROL LEVER |
| 10 | 6685218 | HINGE PIN SET SCREW |
| 11 | 6690873 | VALVE SPRING |
| 12 | 6685219 | HINGE PIN |
| 13 | 6685222 | DIAPHRAGM COVER |
| 14 | 6690827 | METERING DIAPHRAGM COMP. |
| 15 | 6685220 | DIAPHRAGM PACKING |
| 16 | 6685215 | NEEDLE VALVE |
| 21 | 6690766 | IDLE ADJUST SPRING |
| 22 | 6690736 | IDLE ADJUST SCREW |
| 25 | 6685223 | SET SCREW |
| C2407 OIL PUMP/MUFFLER Pag.7 | ||
| 10 | 6685152 | TAPPING SCREW D4.5X14 |
| 11 | 6686765 | OIL PUMP COVER |
| 12 | 6685150 | OIL PIPE (A) |
| 13 | 6685151 | SCREW GEAR |
| 14 | 6691401 | AIR VENT SPONGE |
| 15 | 6685135 | OIL PUMP CASE ASS'Y |
| 16 | 6685132 | PUMP GEAR COMP. |
| 17 | 6685131 | PUMP GEAR SPRING |
| 18 | 6685130 | OIL PUMP ADJUST CAP |
| 19 | 6685134 | OIL PUMP CASE COMP. |
| 20 | 6685129 | ADJUSTER SPRING |
| 21 | 6685070 | BOLT WASHER M4 |
| 25 | 6685128 | OIL PUMP ADJUSTER |
| 26 | 6685133 | MACHINE SCREW M3X8 |
| 28 | 6692450 | MUFFLER SET |
| 31 | 6685149 | MACHINE SCREW (W/SP. WASHER) M4X14 |
| 30 | 6690959 | OIL ADJUST GROMMET |
| 33 | 6692734 | MUFFLER GASKET |
| 36 | 6695054 | HEX. HOLE BOLT 5X40 |
| 37 | 6684661 | WASHER 5 |
| 38 | 6685154 | FUEL PIPE |
| 39 | 6685155 | CHAIN CATCHER |
| 40 | 6692753 | MUFFLER COVER |
| 42 | 6685152 | TAPPING SCREW D4.5X14 |
| 43 | 6685275 | TAPPING SCREW D5X14 |
| 45 | 6696077 | GUIDE PLATE A |
| 46 | 6685161 | TAPPING SCREW D4X10 |
| C2408 CLUTCH/CHAIN BRAKE Pag.8 | ||
| 2 | 6685166 | NUT |
| 4 | 6688560 | CLUTCH COMP. |
| 5 | 6685143 | NEEDLE BEARING |
| 6 | 6689036 | CLUTCH HOUSING COMP. 1/4" |
| 6 | 6689037 | CLUTCH HOUSING COMP. 3/8" |
| 7 | 6689635 | CLUTCH WASHER |
| 8 | 6689641 | CLUTCH WASHER |
| 31 | 6685161 | TAPPING SCREW D4X10 |
| 32 | 6690765 | GUIDE PLATE B |
| 33 | 6687074 | TENTION ADJUST BOLT COMP. |
| 34 | 6685168 | GEAR (A) |
| 35 | 6693485 | HAND GUARD WEIGHT |
| 37 | 6691198 | CRANK SHAFT COLLAR 6 |
| 38 | 6685069 | NUT M4 |
| 41 | 6685068 | MACHINE SCREW (W/SP. WASHER) M4X12 |
| 46 | 6686112 | SIDE CASE ASS'Y |
| 49 | 6689677 | BRAKE HANDLE |
| 52 | 6689713 | BRAKE LINK COVER |
| 54 | 6689707 | BRAKE SPRING |
| 55 | 6685119 | BRAKE SUPPORT PLATE COMP. |
| 56 | 6685141 | NEEDLE ROLLER 3X9.8 |
| 57 | 6685121 | BRAKE LINK COMP. |
| 58 | 6689729 | BLAKE BAND |
| 59 | 6690805 | CLEANER FIXING COLLAR |
| 60 | 6685120 | COLLAR |
| 61 | 6686049 | SIDE COVER ASSY - DISCONTINUED - BUY 6686112 |
| 62 | 6685122 | BRAKE LEVER SPRING |
| 63 | 6685148 | TAPPING SCREW D4X15 |
| C2409 HANDLE Pag.9 | ||
| 4 | 6695107 | TAPPING SCREW 5X35 |
| 5 | 6690805 | CLEANER FIXING COLLAR |
| 8 | 6695108 | TAPPING SCREW 5X40 |
| 9 | 6688480 | DAMPER COLLAR A |
| 10 | 6688117 | DAMPER A |
| 11 | 6685275 | TAPPING SCREW D5X14 |
| 15 | 6685074 | TAPPING SCREW D5X16 |
| 16 | 6685653 | REAR HANDLE B |
| 26 | 6688363 | SAFETY LEVER |
| 27 | 6686395 | THROTTLE LEVER |
| 28 | 6686416 | THROTTLE LEVER SPRING |
| 33 | 6685628 | REAR HANDLE A |
| 39 | 6685148 | TAPPING SCREW D4X15 |
| 41 | 6688088 | FRONT HANDLE |
| 45 | 6693875 | THROTTLE WIRE COMP. |
| 47 | 6688262 | DAMPER COMP. |
| C2410 COVER/CHAIN/CHAIN BAR Pag.10 | ||
| 1 | 6685257 | COMBI BOX SPANNER 10/19MM |
| 6 | 6686632 | 4X50 MINUS DRIVER |
| 40 | HGA781120 | CHAIN 10" 3/8" LP 1,3 mm 0.50" 40 M. |
| 40 | HGA781110 | CHAIN 10" 1/4" 1,3 mm 0.50" 60 M. |
| 41 | HGA6686879 | CHAIN BAR 10" |
| 41 | GHATKBC10 | CARVING CHAIN BAR 10" no hitachi |
| 65 | 6694796 | GUIDE BAR COVER, 10 |
