FIAC Spare Parts for Piston Air Compressor Colibri' GM 191
€270.35
Tax included
FIAC Spare Parts for Piston Air Compressor Colibri' GM 191
Genuine Parts FIAC for piston Air Compressor and spare parts or replacement parts for to repair components of the Air Compressor Colibri' GM 191.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Spare Parts for Piston Air Compressor Colibri' GM 191
Genuine Parts FIAC for piston Air Compressor and spare parts or replacement parts for to repair components of the Air Compressor Colibri' GM 191.
In the following table, look for the type of the air compressor and the respective parts of the code.
| Colibri' GM 191 | ||
| # | Part Num. | Description |
| 1 | 7084040000 | Fitting "L" M3 / 8 " |
| 2 | 7041010000 | Seeger Ø12 |
| 3 | 7458340000 | Filter plate |
| 4 | 7210010000 | Filter element |
| 5 | 7210430000 | Filter cover |
| 6 | 7012010000 | Screw Ø3,9X19 UNI-6954 |
| 8 | 7458020000 | PLATE-holder D 50 ZINC |
| 10 | 7575240000 | Cylinder - DISCONTINUED |
| 12 | 4080020000 | Kit segments |
| 13 | 7015020000 | Prisoner M.8X35X14X16 |
| 14 | 7071020000 | Oil seal 2452/10 |
| 15 | 7181060000 | Dipstick |
| 16 | 7650020000 | Crankcase cover |
| 17 | 7011430000 | Screw M6X16 UNI-8112 |
| 18 | 7012100000 | Screw Ø3,9X16 |
| 19 | 7078460000 | Gasket |
| 20 | 5040840008 | Tree in Elbow |
| 21 | 7060060000 | Bearing 6205 |
| 22 | 5070320008 | Sump |
| 23 | 7660130000 | Armature |
| 24 | 7220020000 | Piston |
| 25 | 4012510000 | CRANKCASE MOTOR GM-191-H.70 V.230 / 50HZ |
| 26 | 7060010000 | Bearing 6203 ZZ 17:40:12 QE6 |
| 27 | 5110061008 | Cover |
| 28 | 7018010000 | Screw M6x139 UNI-5737 |
| 29 | 7012290000 | Screw M5X20 TAP-TITE |
| 30 | 7201280000 | Fan |
| 31 | 7013060000 | Screw M4X8 UNI-8112 |
| 32 | 5050150008 | Connecting rod |
| 33 | 7310320000 | Capacitor MF.30 V450 |
| 35 | 7150421000 | CASING GM 250-BLACK-VERS.96- |
| 36 | 7020070000 | Nut M8 UNI-5587 |
| 38 | 4081010000 | FLAP VALVE KIT 10 PCS 110-200 |
| 39 | 7050020000 | Pin Ø12 / 8X42 |
| 40 | 7011220000 | Screw M6x40 UNI-5737 |
| 41 | 7570090000 | Head |
| 50 | 7101440000 | X RING GEAR "ANI" mod.31 / S6 |
| 51 | 7110170000 | Manometer |
| 52 | 7250740000 | Pressure switch |
| 53 | 7023040000 | Nut 1/4 " |
| 54 | 7081140000 | Fitting 1/4 "MM |
| 55 | 7329070000 | Power cable |
| 56 | 7192020000 | Safety Valve M1/ 4-8,5Bar |
| 57 | 7084240000 | The connection M1/4"- Ø6 |
| 58 | 7230010000 | Rilsan tube Ø6X4 |
| 59 | 7130090000 | Drain tap M1/4" |
| 60 | 7230010000 | Rilsan tube Ø6X4 |
| 61 | 7190030000 | CHECK VALVE FM 1 / 2X3 / 8 |
| 62 | 7030020000 | Ø6 washer UNI-6592 |
| 63 | 7270010000 | Rubber Sucking foot |
| 64 | 7014080000 | Screw M6x14 UNI-6107 |
| 65 | 7239520000 | Tube feeding |
| 66 | 7085210000 | Fitting 1 / 4-1 / 8 FM |
| 67 | 7130200000 | RUB LINE CALIPER 1/4 M |
| 68 | 7100280000 | RID PR 1/4 Art.31 / S6 S / C RUB / RING |
| 69 | 7084220000 | Fitting DIR.M1 / 4 "-6 QUICK |
| 70 | 7285000000 | LOCK RUBBER HANDLE insulating COLIBRI |
| 71 | 5155830008 | Tank |
| 100 | 4082670000 | Valve plate kit |
| 101 | 4191020000 | Kit piston rod |
| 102 | 4280032000 | GR.CARTER-SHAFT-ROTOR-GM 191 H.70 |
| 103 | 4082010000 | Gasket Kit |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Fiac Colibri' GM 191
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- MORE INFO:
- info@bricoutensili.com
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
