Tanaka Spare Parts for Brush Cutter TBC-230S
€1.11
Tax included
Tanaka Spare Parts for Brush Cutter TBC-230S
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brush Cutter TBC-230S.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Tanaka Spare Parts for Brush Cutter TBC-230S
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brush Cutter TBC-230S.
In the following table, look for the model of the Brush Cutter and the respective parts of the code.
| Brush Cutter TBC-230S | ||
| # | Part Num. | Description |
| 1 | 6687468 | SPARK PLUG CAP ASS'Y |
| 3 | 6685489 | CYLINDER SET |
| 4 | 6684586 | HEX.HOLE BOLT M5X18/S |
| 5 | 6685709 | CYLINDER GASKET |
| 6 | 6686118 | PISTON RING |
| 7 | 6685869 | PISTON COMPLETE |
| 8 | 6684590 | CIR CLIP |
| 9 | 6696944 | PISTON PIN |
| 10 | 6686217 | CRANK SHAFT COMP. |
| 11 | 6687888 | HIGH TENSION CORD 140L |
| 13 | 6684682 | HEX. HOLE BOLT 4X15/PS |
| 14 | 6699772 | IGNITION COIL ASS'Y - DISCONTINUED |
| 15 | 6684602 | RUBBER CAP |
| 17 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 31 | 6689177 | GEAR SHAFT SHIM 0.10 |
| 31 | 6689178 | GEAR SHAFT SHIM 0.15 |
| 31 | 6684604 | GEAR SHAFT SHIM 0.20 |
| 35 | 6686719 | CRANK CASE GASKET |
| 36 | 6684586 | HEX.HOLE BOLT M5X18/S |
| 38 | 6684611 | BOLT WASHER M8 |
| 51 | 6689890 | INLET MANIFOLD GASKET |
| 52 | 6689914 | CARB INSULATOR SET |
| 53 | 6684615 | CARBURETOR GASKET |
| 54 | 6695514 | HEX.HOLE BOLT 5X22/WS |
| 55 | 6695354 | SCREW 5X60/S |
| 56 | 6684661 | WASHER 5 |
| 57 | 6688174 | SHIELD TUBE |
| 58 | 6685198 | CLIP D6 |
| 60 | 6691592 | TANK, WHITE |
| 61 | 6685049 | TANK CAP ASS'Y |
| 62 | 6692244 | COLLAR 5.8 |
| 63 | 6690512 | CARBURETOR SET WYL182 |
| 63 | 6690513 | CARBURETOR SET WYL189 |
| 64 | 6690512 | CARBURETOR SET WYL182 |
| 65 | 6695504 | HEX. HOLE BOLT 5X16/PS |
| 65A | 6696574 | BOLT (W/FLANGE) L17.8 |
| 66A | 6696574 | BOLT (W/FLANGE) L17.8 |
| 68 | 6684880 | FUEL PIPE 3X5X85 |
| 69 | 6697846 | RETURN GROMMET |
| 71 | 6691389 | AIR VENT ASS'Y |
| 73 | 6692171 | AIR VENT VALVE ASS'Y |
| 74 | 6691592 | TANK, WHITE |
| 74B | 6691592 | TANK, WHITE |
| 75 | 6685049 | TANK CAP ASS'Y |
| 75B | 6685049 | TANK CAP ASS'Y |
| 76 | 6695354 | SCREW 5X60/S |
| 77 | 6684661 | WASHER 5 |
| 78 | 6691337 | SWIVEL CAP |
| 91A | 6692809 | MUFFLER PROTECTOR BLACK |
| 94 | 6684637 | TAPPING SCREW D4.5X12 |
| 95 | 6685114 | HEX. SOCKET HD. BOLT M5X50 |
| 96 | 6684918 | WASHER M5 (BLACK) |
| 100 | 6692745 | MUFFLER GASKET |
| 101 | 6687253 | HEAT SHIELD |
| 104 | 6688616 | CLUTCH SHOE COMP.,T-16 |
| 105 | 6689430 | CLUTCH SPRING |
| 107A | 6684646 | STEP BOLT |
| 108 | 6684648 | BENT WASHER 8 |
| 110 | 6684647 | HEX. HOLE BOLT M5X18/WS |
| 111 | 6685191 | TAPPING SCREW D4.5X20 |
| 112 | 6684973 | HEX.HOLE BOLT M5X30/WS |
| 113 | 6688011 | CORD CLAMP COMP. |
| 115 | 6688616 | CLUTCH SHOE COMP.,T-16 |
| 116 | 6689430 | CLUTCH SPRING |
| 117A | 6684646 | STEP BOLT |
| 118A | 6697655 | CLUTCH SET |
| 121 | 6692883 | MUFFLER SPECIAL GASKET |
| 123 | 6685109 | MACHINE SCREW (W/SP. WASHER) M4X8 |
| 131 | 6692986 | RECOIL STARTER BODY ASS'Y |
| 133 | 6693038 | RECOIL STARTER BODY COMP |
| 134 | 6693168 | ROPE |
| 135 | 6693138 | RECOIL SPRING |
| 137 | 6693101 | SPRING CASE ASS'Y |
| 139 | 6693079 | STARTER PULLEY |
| 140 | 6687947 | SPECIAL WASHER 5.2X15 |
| 141 | 6685275 | TAPPING SCREW D5X14 |
| 145 | 6685153 | TAPPING SCREW D4.5X14 |
| 146 | 6693408 | STARTER PULLEY ASS'Y |
| 151 | 6692988 | RECOIL STARTER BODY ASS'Y |
| 155 | 6693139 | RECOIL SPRING |
| 157 | 6693080 | STARTER ROPE REEL |
| 158 | 6687947 | SPECIAL WASHER 5.2X15 |
| 159 | 6685275 | TAPPING SCREW D5X14 |
| 160 | 6695508 | HEX. HOLE BOLT 4X18WS |
| 161 | 6695169 | FLUNGE NUT 5 |
| 162 | 6693408 | STARTER PULLEY ASS'Y |
| 171A | 6699995 | RECOIL STARTER BODY ASS'Y |
| 172 | 6684673 | RECOIL STARTER BODY COMP. |
| 174 | 6684675 | RECOIL SPRING |
| 175A | 6699997 | STARTER ROPE REEL |
| 176 | 6684677 | DAMPER SPRING |
| 177A | 6699996 | CAM PLATE |
| 178 | 6684679 | SET SCREW |
| 179 | 6684680 | STARTER HANDLE |
| 180 | 6684681 | STARTER PULLEY ASS'Y |
| 181 | 6695508 | HEX. HOLE BOLT 4X18WS |
| 182 | 6684683 | STOP RING E-5 |
| 183 | 6684684 | STARTER PAWL SPRING |
| 184 | 6684685 | STARTER PAWL |
| 185 | 6699691 | CAMPLATE ASS'Y |
| 185 | 6699691 | CAMPLATE ASS'Y |
| 191 | 6684938 | RECOIL STARTER BODY ASS'Y |
| 193 | 6684941 | STARTER ROPE REEL |
| 194 | 6684942 | RECOIL SPRING |
| 196 | 6684679 | SET SCREW |
| 199 | 6684680 | STARTER HANDLE |
| 201 | 6684937 | STARTER PULLEY |
| 202 | 6684682 | HEX. HOLE BOLT 4X15/PS |
| 211A | 6699995 | RECOIL STARTER BODY ASS'Y |
| 212 | 6684673 | RECOIL STARTER BODY COMP. |
| 214 | 6684675 | RECOIL SPRING |
| 215A | 6699997 | STARTER ROPE REEL |
| 216 | 6684677 | DAMPER SPRING |
| 217A | 6699996 | CAM PLATE |
| 218 | 6684679 | SET SCREW |
| 219 | 6684680 | STARTER HANDLE |
| 220 | 6684681 | STARTER PULLEY ASS'Y |
| 221 | 6695508 | HEX. HOLE BOLT 4X18WS |
| 222 | 6685101 | D4E RETAINING RING |
| 223 | 6684684 | STARTER PAWL SPRING |
| 224 | 6684685 | STARTER PAWL |
| 225 | 6699691 | CAMPLATE ASS'Y |
| 225 | 6699691 | CAMPLATE ASS'Y |
| 231 | 6690048 | CLEANER ASSY |
| 233 | 6684654 | AIR CLEANER ELEMENT |
| 234 | 6689737 | SPECIAL SCREW |
| 235 | 6684656 | CLEANER BODY COMP. |
| 237 | 6684658 | WAVE WASHER 8 |
| 238 | 6684659 | COLLAR 8 |
| 251 | 6690048 | CLEANER ASSY |
| 253 | 6684654 | AIR CLEANER ELEMENT |
| 253A | 6690347 | CLEANER ELEMENT |
| 254 | 6689737 | SPECIAL SCREW |
| 255 | 6684656 | CLEANER BODY COMP. |
| 257 | 6684658 | WAVE WASHER 8 |
| 258 | 6684659 | COLLAR 8 |
| 259 | 6690801 | COLLAR |
| 281 | 6684879 | PUMP BODY COMP. |
| 282 | 6684687 | PRIMING PUMP COMP. |
| 284 | 6684689 | PRIMING BODY |
| 285 | 6690830 | METERING DIAPHRAGM COMP. |
| 286 | 6684691 | DIAPHRAGM GASKET |
| 287 | 6684693 | PUMP DIAPHRAGM |
| 288 | 6691457 | PUMP GASKET |
| 289 | 6691844 | MAIN JET #38 |
| 290 | 6684695 | O-RING |
| 291 | 6684696 | STOP RING |
| 292 | 6684697 | SWIVEL |
| 293 | 6684698 | THROTTLE SET SCREW |
| 295 | 6684700 | INLET SCREEN |
| 301 | 6695969 | CLUTCH SHAFT COMP. |
| 302 | 6684664 | STOP RING C-12 OUTER |
| 303 | 6691839 | ANTI-VIBE RUBBER |
| 304 | 6695046 | HEX. HOLE BOLT 5X16 |
| 305 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 306 | 6687029 | FAN CASE, OR |
| 307 | 6689651 | PIPE HOLDER, TPE |
| 308 | 6684918 | WASHER M5 (BLACK) |
| 309 | 6689159 | GEAR CASE WASHER |
| 310 | 6689664 | METAL FITTING |
| 321 | 6696009 | TRASMISSION |
| 322 | 6689410 | DRIVE SHAFT PIPE COMP.1450L |
| 323 | 6684831 | BUSH ASS'Y |
| 324 | 6684835 | HEX.NUT 6 |
| 325 | 6684836 | HANDLE - UPPER |
| 326 | 6684837 | HANDLE - LOWER |
| 327 | 6684838 | BOLT 6X43/P (BLACK) |
| 332 | 6693769 | THROTTLE LEVER ASS'Y |
| 335 | 6687452 | STOP BUTTON COMP. |
| 337 | 6684721 | TRIGGER LOCK OUT |
| 338 | 6684722 | RETURN SPRING |
| 341 | 6684727 | CONTAL NUT 5 |
| 342 | 6684725 | SCREW M4X20 (BLACK) |
| 343 | 6684804 | THROTTLE LEVER |
| 351 | 6688817 | GEAR CASE ASS'Y 24 |
| 352 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 353 | 6684732 | STOP RING C-24,INNER |
| 354 | 6695281 | STOP RING C-9, OUTER |
| 355 | 6684735 | BALL BEARING 609Z ST |
| 356 | 6688815 | GEAR CASE 24 |
| 358 | 6689109 | OILING BOLT |
| 359 | 6695567 | BALL BEARING 626 , 19MM/OD |
| 361 | 6695527 | BALL BEARING 6000D, 26MM/OD |
| 362 | 6695294 | RETAINING RING C-TYPE D26 |
| 363 | 6689033 | CUTTER HOLDER |
| 364 | 6689056 | CUTTER HOLDER CAP |
| 366 | 6689075 | FIXING NUT L/H |
| 367 | 6688917 | GEAR CASE COVER |
| 369 | 6688883 | GEAR/PINION SET |
| 371 | 6695219 | S.WASHER 6 |
| 380 | 6684714 | HEX. HOLE BUTTON SCREW M6X25S |
| 381 | 6690317 | COVER BRACKET 24 |
| 382 | 6690242 | BLADE GUARD 26 CE |
| 382A | 6684747 | BLADE GUARD 24 CE |
| 383 | 6684748 | GUARD HOLDER |
| 384 | 6690372 | COVER GUARD |
| 384A | 6684749 | COVER GUARD |
| 385 | 6693386 | KNIFE |
| 385A | 6684750 | KNIFE |
| 386 | 6695334 | SCREW 5X12/S |
| 386A | 6684751 | TAPPING SCREW 4X14 |
| 387 | 6684965 | NUT M5 |
| 388 | 6690332 | BRACKET SPACER |
| 389 | 6684753 | TAPPING SCREW 5X20 |
| 389 | 6684753 | TAPPING SCREW 5X20 |
| 389 | 6684753 | TAPPING SCREW 5X20 |
| 390 | 6684754 | KNIFE |
| 390 | 6684754 | KNIFE |
| 390 | 6684754 | KNIFE |
| 514 | 6693380 | REEL SPRING |
| 516 | 6693294 | SPOOL |
| 517 | 6693340 | CUTTING BODY CAP |
| 524 | 6693380 | REEL SPRING |
| 526 | 6693294 | SPOOL |
| 527 | 6693340 | CUTTING BODY CAP |
| 531 | 6689625 | MOUNTING NUT L/H - DISCONTINUED |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Tanaka websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Tanaka brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
