Tanaka Spare Parts for Chainsaw TCS-3401S
€1.11
Tax included
Tanaka Spare Parts for Chainsaw TCS-3401S
Tanaka genuine spare parts or replacement parts for to fix Engine Chainsaw TCS-3401S.Fix Your Chainsaw TCS-3401S. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Tanaka Spare Parts for Chainsaw TCS-3401S
Tanaka genuine spare parts or replacement parts for to fix Engine Chainsaw TCS-3401S.
In the following table, look for the model of the Engine Chainsaw and the respective parts of the code.
| Chainsaw Tanaka TCS 3401S | ||
| Starter TCS 3401S - D090650 Pag.1 | ||
| # | Part Num. | Description |
| 0 | 6692911 | COMPLETE STARTER |
| 1 | 6685275 | SCREW |
| 2 | 6689681 | WASHER |
| 3 | 6693060 | STARTER PULLEY |
| 4 | 6693159 | STARTER CORD |
| 5 | 6693093 | STARTER SPRING |
| 7 | 6693229 | STARTER KNOB |
| 9 | 6686951 | CARTER |
| 10 | 6684636 | SCREW D.4.5x16 |
| 11 | 6687481 | GROMMET |
| 12 | 6687327 | CONVEYOR |
| 13 | 6687183 | GROMMET |
| 14 | 6685153 | Screw |
| Starter TCS 3401S - D090651 Pag.2 | ||
| 0 | 6692911 | STARTER COMPL. |
| 1 | 6684679 | SCREW |
| 2 | 6685183 | SPRING |
| 3 | 6685184 | PULLEY |
| 4 | 6685186 | ROPE |
| 5 | 6685185 | SPRING ASSEMBLY |
| 7 | 6685188 | STARTER HANDLE |
| 8 | 6687481 | GROMMET |
| 9 | 6686952 | STARTER CARTER (S-START) |
| 10 | 6684636 | SCREW |
| 11 | 6687183 | RUBBER |
| 12 | 6687327 | CONVEYOR |
| 14 | 6685182 | PLATE |
| 15 | 6685189 | STOP ROPE |
| 16 | 6685153 | SCREW |
| Carburator TCS 3401S Pag.3 | ||
| 0 | 6690647 | CARBURETOR WT551 |
| 0 | 6690650 | CARBURETOR WT553 |
| 2 | 6684700 | FILTER |
| 3 | 6685211 | COVER |
| 3 | 6691416 | BODY PUMP |
| 4 | 6685210 | SCREW |
| 5 | 6685212 | SEAL |
| 6 | 6685213 | DIAPHRAGM |
| 7 | - | ADJUSTING SCREW |
| 8 | 6692048 | SPRING |
| 9 | 6685217 | LEVER |
| 10 | 6685218 | SCREW |
| 11 | 6690872 | SPRING |
| 12 | 6685219 | BOLT |
| 13 | 6685222 | LITTLE COVER |
| 14 | 6690827 | DIAPHRAGM DISC |
| 15 | 6685220 | DIAPHRAGM DISC |
| 16 | 6685215 | NEEDLE |
| 21 | 6685297 | SPRING |
| 22 | 6685298 | ADJUSTING SCREW |
| 23 | - | ADJUSTING SCREW |
| 24 | 6690897 | ADJUSTMENT SPRING |
| 25 | 6685223 | ADJUSTING SCREW |
| Engine Housing TCS 3401S Pag.4 | ||
| 19 | 6686474 | SHIM |
| 19 | 6685098 | SHIM |
| 19 | 6685099 | SHIM |
| 21 | 6685104 | FLYWHEEL NUT |
| 22 | 6695222 | WASHER |
| 23 | 6685103 | WASHER |
| 24 | 6685102 | THEY FLY |
| 26 | 6685334 | PAWL |
| 27 | 6685105 | PAWL SPRING |
| 28 | 6685101 | SEEGER |
| 36 | 6695340 | SCREW |
| 41 | 6686524 | ENGINE CASE |
| 42 | 6684607 | SEAL |
| 43 | 6686702 | GASKET |
| 44 | 6685096 | BEARING 6201 A2C3 |
| 46 | 6685095 | LOCK PIN |
| Engine Housing - Air Filter TCS 3401S Pag.5 | ||
| 47 | 6687421 | FILTER BODY |
| 48 | 6689876 | GASKET |
| 49 | 6685202 | FLANGE |
| 50 | 6689787 | INTAKE MANIFOLD |
| 50 | 6689787 | INTAKE MANIFOLD |
| 51 | 6691367 | ENGINE HOUSING |
| 52 | 6685173 | BREATHER VALVE |
| 53 | 6685203 | SPOUT |
| 54 | 6685175 | BREATHER VALVE |
| 57 | 6684634 | SCREW |
| 58 | 6690843 | VALVE |
| 59 | 6692404 | AIR LEVER |
| 60 | 6692596 | SHIM |
| 61 | 6692591 | GROMMET |
| 62 | 6692514 | LEVER |
| 64 | 6687958 | GROMMET |
| 64 | 6687959 | GROMMET |
| 65 | 6685224 | GROMMET |
| 67 | 6686304 | HALF CARTER |
| 68 | 6689735 | SCREW |
| 69 | 6690074 | AIR CLEANER ELEMENT |
| 70 | 6684595 | SCREW |
| 71 | 6685153 | SCREW |
| 73 | 6695348 | SCREW |
| 73 | 6695428 | SCREW |
| 74 | 6695505 | HEX HOLE BOLT 5X18PS |
| 75 | 6685853 | GROMMET |
| 76 | 6684918 | WASHER |
| 77 | 6684864 | WASHER |
| 78 | 6684864 | WASHER |
| Cylinder Piston - Crank Shaft TCS 3401S Pag.6 | ||
| 1 | 6687479 | SPARK PLUG CAP |
| 2 | 6685768 | SPARK PLUG |
| 6 | 6685460 | CYLINDER AND GASKET |
| 7 | 6684586 | BOLT |
| 9 | 6685725 | CYLINDER GASKET |
| 10 | 6686122 | PISTON RING |
| 11 | 6685880 | PISTON |
| 12 | 6686008 | PIN |
| 13 | 6685078 | CIR CLIP |
| 16 | - | CRANKSHAFT |
| 17 | 6695592 | BEARING |
| 18 | 6684899 | KEY 4X18 WS |
| 31 | 6695407 | SCREW |
| 32-1 | 6687667 | ELECTRONIC IGNITION COIL till series A289400 |
| 32 | 6685089 | IGNITION COIL |
| 33 | 6687890 | HIOGHTENSION CORD 110L |
| 34 | 6684602 | SLEEVE |
| 35 | 6687349 | COMPLETE ELECTRONIC IGNITION COIL FROM series A289401 |
| 35-1 | 6687667 | COMPLETE STARTER COIL fino alla serie A289400 |
| 66 | 6692900 | ISOLATOR |
| * | 6695828 | CYLINDER AND PISTON SET |
| Accessories TCS 3401S Pag.7 | ||
| 1 | 6693809 | COMBINED KEY |
| 1 | 6685257 | KEY |
| 2 | 6686632 | SCREWDRIVER |
| 3 | 6685275 | SCREW |
| 4 | 6685270 | SPIKED BUMPER |
| Oil Filter TCS 3401S Pag.8 | ||
| 1 | 6691121 | TUBE |
| 2 | 6692312 | LOCK RING |
| 3 | 6684661 | WASHER M5 |
| 4 | 6690919 | OIL FILTER |
| 5 | 6685249 | BUTTON |
| 10 | 6685196 | FITTING |
| 11 | 6685139 | PRIMER |
| 12 | 6685267 | TUBE |
| 13 | 6692353 | TUBE |
| 14 | 6697632 | TUBE |
| 16 | 6688155 | MIXTURE TUBE |
| 17 | 6685199 | FILTER |
| 35 | 6692111 | FUEL TANK CAP |
| 35 | 6685180 | FUEL TANK CAP |
| 37 | 6685179 | FUEL TANK CAP GASKET |
| 60 | 6697756 | OIL TANK CAP |
| 62 | 6697888 | OIL TANK CAP PACKING |
| Clutch and Chain Brake TCS 3401S Pag.9 | ||
| 1 | 6687105 | NUT |
| 2 | 6685166 | NUT |
| 4 | 6685142 | COMPLETE CLUTCH |
| 5 | 6685143 | NEEDLE BEARING |
| 6 | 6685144 | CLUTCH DRUM |
| 7 | 6685145 | CLUTCH WASHER |
| 21 | 6689491 | CLUTCH ARM |
| 22 | 6689496 | CLUTCH FLANGE |
| 23 | 6689424 | SPRING |
| 24 | 6689527 | PLATE |
| 25 | 6695240 | WASHER |
| 31 | 6685161 | SCREW 4X10 |
| 32 | 6690790 | PLATE |
| 32 | 6697599 | GUIDE PLATE |
| 33 | 6687072 | CHAIN TENSIONER |
| 37 | 6685146 | SPACER |
| 46 | 6686110 | CHAIN CARTER ASSY |
| 46 | 6686110 | CHAIN CARTER ASSY |
| 47 | 6690756 | GUIDE PLATE |
| 48 | 6695269 | SCREW |
| 49 | 6697958 | HAND GUARD |
| 50 | 6685169 | CHAIN TENSIONER BOLT |
| 51 | 6685168 | CHAIN TENSIONER GEAR |
| 52 | 6689712 | COVER |
| 54 | 6689705 | SPRING |
| 55 | 6685119 | LEVER |
| 56 | 6685141 | PIN MM 3X9.8 |
| 57 | 6685121 | LEVER |
| 58 | 6689728 | BRAKE BAND |
| 59 | 6690805 | BUSHING |
| 60 | 6685120 | BUSHING |
| 61 | 6686046 | SIDE CARTER |
| 62 | 6685122 | SPRING |
| 63 | 6685148 | SCREW |
| Handle TCS 3401S Pag.10 | ||
| 6 | 6695107 | SCREW 5X35 |
| 9 | 6690805 | BUSHING |
| 10 | 6688263 | DAMPER |
| 11 | 6695108 | SCREW 5X40 |
| 12 | 6688481 | SPACER |
| 15 | 6685074 | SCREW 5X16 |
| 16 | 6685651 | HALF HANDLE RIGHT |
| 17 | 6692680 | BUTTON |
| 18 | 6686447 | SPRING |
| 20 | 6686430 | PLUG |
| 26 | 6688363 | LEVER |
| 27 | 6686395 | THROTTLE LEVER |
| 28 | 6686416 | ACCELERATOR LEVER SPRING |
| 33 | 6685623 | HALF HANDLE LEFT |
| 39 | 6685148 | SCREW 4X15 |
| 41 | 6688085 | SIDE HANDLE |
| 42 | 6685252 | CABLE |
| 43 | 6687838 | CABLE |
| 44 | 6685239 | SWITCH |
| 45 | 6693874 | THROTTLE CABLE |
| 46 | 6688011 | CLAMP |
| 47 | 6691379 | COVER |
| 48 | 6685153 | SCREW |
| Muffler TCS 3401S Pag.11 | ||
| 26 | 6697139 | SCREW |
| 27 | 6684661 | WASHER M5 |
| 28 | 6692448 | MUFFLER FULL |
| 29 | 6692628 | MUFFLER BODY |
| 30 | 6692679 | INTERNAL MUFFLER |
| 31 | 6692834 | SEAL |
| 32 | 6692608 | HALF MUFFLER |
| 33 | 6692735 | GASKET |
| Oil Pump TCS 3401S Pag.12 | ||
| 8 | 6695416 | SCREW 5X14 |
| 11 | 6686764 | PUMP COVER |
| 12 | 6691223 | OIL TUBE |
| 13 | 6686645 | WORM SCREW |
| 14 | - | FILTER |
| 15 | 6687325 | OIL PUMP ASS'Y |
| 16 | 6690957 | GROMMET |
| 17 | 6691070 | ADJUSTING SCREW |
| 18 | 6695663 | O-RING |
| 19 | 6686681 | OIL PUMP |
| 20 | 6695663 | O-RING |
| 36 | 6685275 | SCREW 5X14 |
| 38 | 6685154 | TUBE |
| 39 | 6685155 | LOCK CHAIN |
| 42 | 6685152 | SCREW 5X14 |
| 501 | 452701 | Bar 35 cm 14" 3/8", 1.3 mm - .050" 52 P. (ADAPTABLE) |
| 502 | 459205 | LP chain 3/8" 1,3 mm .050" - 52 links Prof. S.round low profile with anti-rebound(ADAPTABLE) |
