Tanaka Spare Parts for Chain Saw TCS 33ED
€3.47
Tax included
Tanaka Spare Parts for Chain Saw TCS 33ED
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Chain Saw TCS 33ED.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Tanaka Spare Parts for Chain Saw TCS 33ED
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Chain Saw TCS 33ED.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
| Chainsaw TCS 33ED | ||
| # | Part Num. | Description |
| 2 | 6696821 | MUFFLER COVER |
| 4 | 6699969 | CLEANER ELEMENT (B) |
| 5 | 6699968 | CLEANER ELEMENT (A) |
| 9 | 6699976 | CARBURETOR ASS'Y |
| 10 | 6685210 | SCREW |
| 11 | 6685297 | IDLE ADJUST SPRING |
| 12 | 6685298 | IDLE ADJUST SCREW |
| 13 | 6685218 | HINGE PIN SET SCREW |
| 14 | 6685219 | HINGE PIN |
| 15 | 6685220 | DIAPHRAGM PACKING-METERING |
| 16 | 6684690 | METERING DIAPHRAGM |
| 18 | 6685223 | SET SCREW |
| 20 | 6685212 | PUMP GASKET |
| 21 | 6685213 | PUMP DIAPHRAGM |
| 22 | 6684700 | INLET SCREEN |
| 23 | 6685215 | NEEDLE VALVE |
| 25 | 6685217 | CONTROL LEVER |
| 27 | 6699951 | INTAKE |
| 30 | 6600316 | CLUTCH |
| 31 | 6685144 | CLUTCH HOUSING COMP. |
| 32 | 6685361 | NEEDLE BEARING (D) |
| 33 | 6685414 | CLUTCH WASHER |
| 34 | 6685360 | CRANK SHAFT COLLAR |
| 35 | 6699610 | OIL POMP COVER |
| 37 | 6685356 | NEEDLE ROLLER 2.5X19.8 |
| 44 | 6699957 | PUMP GEAR (ED) |
| 47 | 6600085 | PUMP ASS'Y |
| 48 | 6685371 | AIR VENT SPONGE |
| 49 | 6696811 | OIL PIPE |
| 50 | 6685358 | PIPE JOINT |
| 51 | 6600084 | ENGINE CASE ASS'Y |
| 55 | 6696816 | EXHAUST PIPE |
| 56 | 6696818 | MUFFLER SPECIAL PACKING |
| 57 | 6696817 | GAUZE FIXING PLATE |
| 58 | 6696815 | MUFFLER GAUZE |
| 65 | 6685351 | INNER CAP |
| 66 | 6698854 | FUEL TANK CAP ASS'Y (VERMILION) |
| 67 | 6685179 | TANK CAP PACKING |
| 68 | 6698358 | FUEL TANK CAP ASS'Y (BLACK) |
| 70 | 6696766 | SCAVENGING COVER (B) |
| 72 | 6685311 | CLIP |
| 74 | 6600083 | CYLINDER |
| 79 | 6696326 | HEX. SOCKET HD. BOLT (W/FLANGE) M4X18 |
| 81 | 6698700 | GLASS WASHER |
| 82 | 6699977 | IGNITION COIL |
| 84 | 6696765 | SCAVENGING COVER (A) |
| 85 | 6685326 | CIRCLIP |
| 86 | 6698806 | PISTON (M) |
| 87 | 6685331 | PISTON RING (XR1-1856) |
| 88 | 6696764 | PISTON PIN |
| 89 | 6698853 | CRANK WORM ASS'Y |
| 90 | 6685330 | WORM |
| 91 | 6685329 | OIL SEAL |
| 92 | 6685328 | BALL BEARING |
| 93 | 6696762 | CRANK SHAFT |
| 94 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 97 | 6600090 | MAGNETO SUB ASS'Y |
| 98 | 6685336 | RETAINING RING D4 |
| 100 | 6685335 | STARTER PAWL SPRING |
| 101 | 6685334 | STARTER PAWL |
| 102 | 6696880 | BOLT WASHER D7 |
| 103 | 6696879 | FLYWHEEL NUT M7 |
| 104A | 6600346 | GUIDE PLATE (C) |
| 122 | 6696782 | BRAKE SUPPORT PLATE |
| 123 | 6696783 | BRAKE LEVER SPRING |
| 124 | 6699972 | BRAKE HANDLE |
| 128 | 6685416 | CHAIN BAR CLAMP NUT |
| 129 | 6698986 | CHAIN PULLER |
| 130 | 6696784 | GUIDE PLATE (B) |
| 136 | 6685388 | BRAKE LINK |
| 137 | 6685140 | BRAKE BAND - DISCONTINUED |
| 138 | 6685391 | NEEDLE ROLLER D3 |
| 143 | 6685350 | TRIGGER LOCKOUT (VERMILION) |
| 145 | 6685282 | SPRING PIN 5X25 |
| 148 | 6696327 | DAMPER (A) |
| 149 | 696314 | DISTANCE PIECE (B) |
| 150 | 6685413 | DAMPER SET BOLT |
| 151 | 6685206 | CHOKE LEVER |
| 154 | 6698916 | THROTTLE LEVER (VERMILION) |
| 157 | 6698409 | SPRING HOLDER |
| 159 | 6698428 | ANTIVIBRATION SPRING |
| 160 | 6696167 | FUEL GROMMET |
| 164 | 6699963 | REAR HANDLE |
| 166 | 6685267 | FUEL PIPE 2.5X4X90 |
| 167 | 6685139 | PRIMING PUMP COMP. |
| 169 | 6685308 | FUEL GROMMET (A) |
| 170 | 6685370 | AIR VENT VALVE (B) |
| 171 | 6698456 | FLANGED TAPPING SCREW D5X15 |
| 173 | 6698456 | FLANGED TAPPING SCREW D5X15 |
| 176 | 6685311 | CLIP |
| 177 | 6685310 | OIL FILTER BODY |
| 179 | 6685407 | BOLT WASHER D5 |
| 180 | 6698715 | FUEL PIPE |
| 181 | 6600061 | STARTER HANDLE ASS'Y |
| 187 | 6600062 | SET SCREW (NS) |
| 188 | 6600064 | CAM PLATE (NS) |
| 193 | 6699967 | FRONT HANDLE |
| 194 | 6698865 | SPRING COVER |
| 195 | 6698859 | DAMPER SET BOLT |
| 501 | 6685439 | CHAIN COVER 14" |
| 501 | 6685440 | CHAIN COVER 16" |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Tanaka websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Tanaka brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
