Stiga Spare Parts for Tiller SRC 775 RG
€38.68
Tax included
Stiga Spare Parts for Motorhoe SRC 775 RG
Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Motorhoe SRC 775 RG (2016) 212751142/14.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Stiga Spare Parts for Motorhoe SRC 775 RG
Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Motorhoe SRC 775 RG (2016) 212751142/14.
In the following table, look for the model of the Tiller and the respective parts of the code.
| STIGA SRC 775 RG (2016) 212751142/14 | ||
| Handle Pag.1 Motore Loncin TM 60 OHV 182CC |
||
| # | Part Num. | Description |
| 1 | 118802984/0 | CLUTCH LEVER |
| 2 | 118802982/0 | CLUTCH CABLE |
| 3 | 118802977/0 | PANEL [YELLOW] |
| 4 | 1483-2213-01 | HANDLE GRIP |
| 5 | 9948-0655-16 | Screw |
| 6 | 1483-2143-02 | Accelerator |
| 7 | 9747-0631-02 | LOW SELF-LOCKING NUT M6 UNI7474 ACC.6S |
| 8 | 118802969/0 | Throttle cable |
| 9 | 118802985/0 | CLUTCH LEVER-REVERSE |
| 10 | 118802983/0 | CLUTCH LEVER-REVERSE CABLE |
| 11 | 118802979/0 | Handle |
| 12 | 1483-2044-01 | Lever |
| 13 | 1483-2279-01 | Knob |
| 14 | 1483-2073-01 | Washer |
| 15 | 118802980/0 | Plate |
| 16 | 9699-0121-02 | Washer |
| 17 | 9747-1231-02 | Nut |
| 18 | 9997-0865-12 | Screw |
| 19 | 1483-2021-01 | WIRE SUPPORT PLATE - NLA |
| 20 | 112155000/0 | Nut |
| 21 | 9997-0830-16 | Screw |
| 22 | 118803004/0 | Knob |
| 23 | 9699-0122-02 | Washer |
| 24 | 1483-2166-01 | Cap |
| 25 | 118803012/0 | Nut |
| 26 | 118802978/0 | COVER [YELLOW] |
| 28 | 9747-0531-02 | Nut |
| 29 | 118802974/0 | Transmission Cover Gray |
| 30 | 1483-2186-01 | cap |
| 31 | 1483-2187-01 | Oil Seal |
| 32 | 9598-0002-02 | SPRING PIN 2.5mm L=47mm |
| 33 | 118802986/0 | DEPTH SKID |
| 34 | 9699-0104-02 | WASHER M16 17 x 30 x 3 |
| 35 | 112155000/0 | Nut |
| 36 | 9997-0855-12 | Screw |
| 37 | 118802988/0 | GUARD PLATE |
| 38 | 118802989/0 | GUARD EXTENSION |
| 39 | 9959-0616-16 | Screw |
| 40 | 118803014/0 | Washer |
| 41 | 1134-3643-01 | Nut |
| 42 | 1483-2075-01 | Cap |
| 43 | 118802987/0 | Wheel Support |
| 44 | 118802972/0 | WHEEL |
| 45 | 118802971/0 | Spring |
| 46 | 118803017/0 | SPLIT PIN |
| 47 | 9699-0104-02 | Washer |
| 48 | 1483-2195-01 | LOCK WASHER |
| 49 | 1483-2070-01 | Oil Seal |
| 50 | 118802992/0 | Dust Cover Disc |
| 51 | 9997-1050-16 | SCREW M6S M10 x 50 |
| 52 | 1483-2196-01 | Lock Pin |
| 53 | 9747-1031-02 | LOW SELF-LOCKING NUT M10 UNI7474 ACC.6S |
| 54 | 1483-2023-01 | R/H TINE ASSEMBLY |
| 54 | 1483-2024-01 | L/H TINE ASSEMBLY |
| 55 | 1483-2169-01 | TINE ASSY OUTER-RH |
| 55 | 1483-2170-01 | TINE ASSY OUTER-LH |
| 56 | 9997-1050-16 | Screw |
| 57 | 9747-1031-02 | LOW SELF-LOCKING NUT M10 UNI7474 ACC.6S |
| 61 | 1483-2022-01 | PROTECTION DISC |
| Trasmission Pag.2 | ||
| 1 | 118802981/0 | HANDLE SUPPORT |
| 2 | 112791500/0 | SCREW TE M6x25 UNI 5739 ACC.8.8 |
| 3 | 112154510/0 | LOW SELF-LOCKING NUT M6 UNI7474 ACC.6S |
| 4 | 112155000/0 | Nut |
| 5 | 112691115/0 | HEX-HEAD SCREW M8 x 40 |
| 6 | 118803015/0 | PIN |
| 7 | 118802998/0 | SHAFT GUARD |
| 8 | 118802975/0 | Transmission Plate |
| 9 | 9959-0825-16 | SCREW FLANGED TE M6SF M8 x 25 |
| 10 | 118803019/0 | Screw |
| 11 | 9959-0616-16 | SCREW M6SF M6 x 16 |
| 12 | 9997-0816-16 | Screw |
| 13 | 9699-0028-02 | Washer |
| 14 | 9699-0028-02 | Washer |
| 15 | 118802993/0 | SHAFT |
| 16 | 9549-0001-00 | Ball bearing |
| 17 | 1483-2175-01 | Sprocket |
| 18 | 1483-2145-01 | Spacer |
| 19 | 118802994/0 | MOUNTING PLATE |
| 20 | 112155000/0 | Nut |
| 21 | 1483-2117-01 | Spacer |
| 22 | 1483-2176-01 | Toothed wheel |
| 23 | 118802973/0 | Motor Pulley |
| 24 | 9699-0028-02 | Washer |
| 25 | 1483-2283-01 | Screw |
| 26 | 1483-2207-01 | Spring |
| 27 | 118802996/0 | TENSION ARM |
| 28 | 112155000/0 | Nut |
| 29 | 1483-2207-01 | Spring |
| 30 | 118802997/0 | TENSION ARM |
| 31 | 112155000/0 | Nut |
| 32 | 118802995/0 | Pulley |
| 33 | 1483-2149-01 | DRIVE BELT X10-1128 |
| 34 | 118802965/0 | Belt |
| 35 | 9699-0105-02 | Washer |
| 36 | 9747-1031-02 | LOW SELF-LOCKING NUT M10 UNI7474 ACC.6S |
| 37 | 118803014/0 | Washer |
| 38 | 118802976/0 | BELT COVER [YELLOW] |
| 39 | 9959-0616-16 | SCREW M6SF M6 x 16 |
| 40 | 112791400/0 | SCREW TE M6x20 UNI 5739 ACC.4.8 |
| 41 | 9747-0631-02 | LOW SELF-LOCKING NUT M6 UNI7474 ACC.6S |
| Engine - Ass. Starter - Fuel Tank Pag.3 | ||
| 1 | 118551189/0 | Muffler |
| 3 | 112154210/0 | Nut |
| 4 | 118551190/0 | Muffler gasket |
| 5 | 112793102/0 | Screw |
| 6 | 118551271/0 | Air Cleaner Assembly |
| 7 | 118551192/0 | Knob |
| 8 | 118550495/0 | Air Cleaner Cover |
| 9 | 118551281/0 | Wing Nut |
| 10 | 118551187/0 | Filter element |
| 11 | 118551202/0 | Gasket |
| 12 | 118551188/0 | Air Filter Base |
| 13 | 118550456/0 | Breather Fuel pipe |
| 14 | 118550806/0 | Nut |
| 15 | 118551191/0 | Muffler Protection |
| 16 | 118550861/0 | Screw |
| 17 | 118551170/0 | Guard |
| 21 | 118551193/0 | Starter assembly |
| 24 | 118551171/0 | Cover |
| 26 | 118550336/0 | Nut |
| 27 | 118551194/0 | Starter Cup |
| 28 | 118551169/0 | Flywheel Fan |
| 29 | 118550489/0 | Flywheel Ass'y |
| 30 | 118551195/0 | Electronic Ignition coil |
| 32 | 9400-0289-01 | Spark plug (Rn9Yc) |
| 33 | 118550869/0 | Screw |
| 34 | 118551270/0 | Remote Control Ass'y |
| 35 | 118550810/0 | Spring |
| 36 | 118550811/0 | Screw |
| 37 | 118550808/0 | Spring |
| 38 | 118550807/0 | Arm Governor |
| 39 | 118550805/0 | Screw |
| 40 | 118550806/0 | Nut |
| 41 | 118551178/0 | Governor lInk |
| 42 | 118550492/0 | Spring |
| 43 | 112791500/0 | Screw |
| 44 | 118551183/0 | Tank Support |
| 45 | 118551182/0 | Tank Support |
| 46 | 118550504/0 | Fuel Pipe |
| 47 | 118550872/0 | Pipe Clip |
| 48 | 118550500/0 | Fuel Tank Hose connection |
| 49 | 118550501/0 | Fuel tank |
| 50 | 118551176/0 | Fuel Filter |
| 51 | 118551177/0 | Fuel Tank cap |
| 52 | 112790781/0 | Screw |
| Engine - Piston - Crankshaft Motore Loncin TM 60 OHV 182CC Pag.4 |
||
| 1 | 118550816/0 | Screw |
| 2 | 118550784/0 | Cover |
| 3 | 118551163/0 | Gasket |
| 4 | 118550273/0 | Valve Arm Set |
| 5 | 118550475/0 | Valve lifter |
| 6 | 118550474/0 | Push Rod |
| 7 | 118550623/0 | Valve lifter |
| 8 | 118551166/0 | Valve keeper |
| 9 | 118551167/0 | Retainer |
| 10 | 118551300/0 | Spring |
| 11 | 118551303/0 | Gasket |
| 12 | 118551344/0 | Intake + Exhaust Valve Assembly |
| 13 | 118550798/0 | Cylinder Head |
| 14 | 118551200/0 | Screw |
| 15 | 118551294/0 | Gasket |
| 17 | 118550460/0 | Drain Plug Bolt |
| 18 | 118550793/0 | Washer |
| 21 | 118550379/0 | Oil Seal |
| 22 | 118550280/0 | Ball bearing |
| 23 | 118550288/0 | Woodruff key |
| 24 | 118550617/0 | Crankshaft |
| 25 | 118550470/0 | Connecting Rod Assembly |
| 26 | 118551213/0 | Piston |
| 27 | 118550915/0 | Piston pin |
| 28 | 118550914/0 | Washer, Piston Pin |
| 29 | 118550286/0 | Piston Ring Set |
| 30 | 118550782/0 | Engine Crankcase Gasket |
| 31 | 118551161/0 | Engine crankcase cover |
| 32 | 118550379/0 | Oil Seal |
| 33 | 118551160/0 | Oil cap |
| 34 | 118550624/0 | Camshaft Ass'y |
| 35 | 118550787/0 | Speed Governor assembly |
| 36 | 118550459/0 | Shaft Governor Arm |
| 37 | 118550858/0 | Washer |
| 38 | 118550856/0 | Cotter pin |
| 41 | 118551335/0 | Stud Bolt |
| 42 | 118551174/0 | Carburetor gasket |
| 43 | 118551175/0 | Intake manifold |
| 44 | 118551173/0 | Carburetor gasket |
| 45 | 118550877/0 | Carburetor |
| 47 | 118550482/0 | Spacer |
| 48 | 118550454/0 | STUD BOLT |
| 49 | 118551199/0 | Screw |
| 51 | 118550508/0 | Engine Assembly |
| 52 | 118550486/0 | Valve Float Assy |
| 53 | 118550485/0 | Gasket Carburettor Ass'y |
| 54 | 118550481/0 | Choke lever |
