Stayer Spare Parts for Chain Saw OLMO G1-250B
€45.33
Tax included
Stayer Spare Parts for Chain Saw OLMO G1-250B
Stayer genuine spare parts for the replacement or repair of Chain Saw OLMO G1-250B.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Stayer Spare Parts for Chain Saw OLMO G1-250B
Stayer genuine spare parts for the replacement or repair of Chain Saw OLMO G1-250B.In the following table, look for the model of the Chain Saw and the respective parts of the code.
| Chain Saw OLMO G1-250B | ||
| A | ||
| 1 | 81421 | CYLINDER |
| 2 | 81422 | NEGATIVE PRESSURE PIPE |
| 3 | 81423 | INPUT AIR FLANGE |
| 4 | 81424 | SCREW M4×14 |
| 5 | 81425 | SPRING WASHER4 |
| 6 | 81426 | WASHER 4 |
| A-1 | ||
| 1 | 81427 | NEGATIVE APRESSURE PIPE |
| 2 | 81428 | CIRCLIP 7# |
| B | ||
| 1 | 81429 | PISTON |
| 2 | 814210 | PISTON-RING |
| 3 | 814211 | PISTON-PIN |
| 4 | 814212 | SNAP SPRING |
| 5 | 814213 | RETAINER RING |
| 6 | 814214 | NEEDLE BEARING K81186 |
| 7 | 814215 | CRANK SHAFT ASSY |
| 8 | 814216 | BEARING-BALL |
| 9 | 814217 | RIGHT OIL RING |
| 10 | 814218 | LEFT OIL RING |
| C | ||
| 1 | 814219 | CRANKCASE |
| 2 | 814220 | FLAT WASHER 5 |
| 3 | 814221 | STRETCH WASHER 5 |
| 4 | 814222 | NUT M5×20 |
| D | ||
| D | 8142437 | IGNITION SYSTEM |
| 8 | 814230 | GUIDE HOLDER |
| 9 | 814231 | HIGH PRESSURE PAD |
| 10 | 814232 | SPARK PLUG |
| E | ||
| 1 | 814233 | WASHER MUFFLER |
| 2 | 814234 | MUFFLER |
| 3 | 814235 | SHIELD-MUFFLER |
| 4 | 814236 | BOLT M5x44 |
| F | ||
| 1 | 814237 | ENGINE SUPPORT BRACKET |
| 2 | 814238 | SCREW M5×20 |
| 3 | 814239 | STRETCH WASHER 5 |
| 4 | 814240 | FLAT WASHER 5 |
| 5 | 814241 | PAD-RUBBER |
| 6 | 814242 | SCREW ST4 8×13 |
| 7 | 814243 | PAD-RUBBER COVER |
| 8 | 814244 | CHAIN CATCHER |
| 9 | 814245 | BOLT ST52×16-35 |
| 10 | 814246 | PLATE-BAR(LEFT) |
| 11 | 814247 | BOLT ST4×11-8 |
| 12 | 814248 | BREATH APPARATUS |
| 13 | 814249 | SPONGE BREATH APPARATUS |
| 14 | 814250 | SNAP SPRING BREATH APPARATUS |
| 15 | 814251 | FRONT COVER |
| 16 | 814252 | BOLT ST4 2×13 |
| 17 | 814253 | FUEL BREATH BASE |
| 18 | 814254 | FUEL BREATH |
| 19 | 814255 | OIL SCALE |
| 20 | 814256 | FUEL CAN CAP SEAL |
| 21 | 814257 | FUEL CAN CAP |
| 22 | 814258 | OIL CAN CAP SEAL |
| 23 | 814259 | CHAIN TANK CAP |
| 24 | 814260 | PRIMER PUMP |
| 25 | 814261 | COVER-TOP |
| 26 | 814262 | BOLT |
| 27 | 814263 | HEAT –PROOF PAPER GASKET |
| 28 | 814264 | OIL PUMP SEALED CAP |
| 29 | 814265 | BOLT ST4 2×13 |
| 30 | 814266 | NYLON TAPE 13×65 |
| 31 | 814267 | HOOK |
| 32 | 814268 | BOLT ST4×10 |
| G | ||
| 1 | 814269 | REAR HANDLE |
| 2 | 814270 | AIR INPUT FLANGE PLATE |
| 3 | 814271 | CARBURETOR PAD |
| 4 | 814272 | CARBURETOR |
| 5 | 814273 | AIR FILTER HOUSING |
| 6 | 814274 | COVER-AIR FILTER |
| 7 | 814275 | STRETCH WASHER 5 |
| 8 | 814276 | BOLT M5×48 |
| 9 | 814277 | SPONGE-AIR FILTER |
| 10 | 814278 | TOP AIR FILTERF814269 |
| 11 | 814279 | COVER-AIR FILTER |
| 12 | 814280 | KNOB-AIR FILTER |
| 13 | 814281 | GROMMET-CHOKE KNOB |
| 14 | 814282 | CHOKE KNOB |
| 15 | 814283 | ROD THROTTLE |
| 16 | 814284 | PIN 5×25 |
| 17 | 814285 | TRIGGER |
| 18 | 814286 | SPRING-TRIGGER |
| 19 | 814287 | LEVER-SAFETY TRIGGER |
| 20 | 814288 | COVER-REAR HANDLE |
| 21 | 814289 | BOLT ST4 2×13 |
| 22 | 814290 | WASHER-REAR HANDLE |
| 23 | 814291 | ON/ OFF SWITCH |
| 24 | 814292 | EARTHING LINE |
| 26 | 814294 | NYLON TAPE 13×65 |
| 27 | 814295 | PAD-RUBBER |
| 28 | 814296 | BOLT ST4 8×13 |
| 29 | 814297 | PAD-RUBBER COVER |
| H | ||
| H | 8142441 | STARTER DISCRETENESS |
| 1 | 814298 | HOUSING- STARTER |
| 2 | 814299 | GUIDE BUSH-ROPE |
| 3 | 8142100 | SPRING-STARTER |
| 4 | 8142101 | COVER-SPRING |
| 5 | 8142102 | STARTER PULLEY |
| 6 | 8142103 | PULLEY CABLE |
| 7 | 8142104 | HANDLE-STARTER |
| 8 | 8142105 | BUFFERTING SPRING CAP |
| 9 | 8142106 | BUFFERTING SPRING |
| 10 | 8142107 | WASHER 5（φ55×φ16×1） |
| 11 | 8142108 | BOLT ST4 8×16 |
| 12 | 8142109 | GUIDE FAN HOUSING |
| 13 | 8142110 | BOLT ST42×13 |
| 14 | 8142111 | VENT PIPE |
| 15 | 8142112 | BOLT ST4 2×16 |
| I | ||
| 1 | 8142113 | HANDLE-FRONT |
| 2 | 8142114 | PAD-RUBBER |
| 3 | 8142115 | BOLT ST48x16 |
| 4 | 8142116 | SHOCK ABSORBERS PAD |
| 5 | 8142117 | NYLON TAPE 13×65 |
| 6 | 8142118 | BOLT ST42×13 |
| 7 | 8142119 | PAD -FRONT HANDLE |
| J | ||
| 1 | 8142120 | OIL PUMP |
| 2 | 8142121 | WORN ROD WASHER |
| 3 | 8142122 | STREW M4×14 |
| 4 | 8142123 | STRETCH WASHER 4 |
| 5 | 8142124 | FLAT WASHER 4 |
| 6 | 8142125 | WORN ROD |
| 7 | 8142126 | OIL PUMP SEALED SPONGE |
| 8 | 8142127 | OIL PUMP SPONGE |
| J-1 | ||
| 1 | 8142128 | INPUT-OIL TUBE |
| 2 | 8142129 | OIL FILTER ASSY |
| 3 | 8142130 | OUTPUT-OIL TUBE |
| K | ||
| 1 | 8142131 | NEEDLE BEARING K1013125 |
| 2 | 8142132 | DRIVEN WHEEL |
| 3 | 8142133 | WASHER-DRUM CLUTCH |
| 4 | 8142134 | CLUTCH |
| L | ||
| 1 | 8142135 | SPROCKET COVER |
| 2 | 8142136 | BAND BRAKE |
| 3 | 8142137 | SPRING-ACTUATION |
| 4 | 8142138 | PLATE-BRAKE |
| 5 | 8142139 | BRAKE LINK |
| 6 | 8142140 | PIN D3×87 |
| 7 | 8142141 | BRAKE ROCKER |
| 8 | 8142142 | COVER-CHAIN BRAKE |
| 9 | 8142143 | BOLT ST4×10 |
| 10 | 8142144 | CHAIN TENSION PIN |
| 11 | 8142145 | CHAIN ADJUST GEAR |
| 12 | 8142146 | CHAIN TENSION AXIS |
| 13 | 8142147 | PLATE-BAR |
| 14 | 8142148 | BOLT ST42×13 |
| 15 | 8142149 | PIN D3×14 |
| 16 | 8142150 | BUFFER SPRING CUSHION |
| 17 | 8142151 | BUFFER SPRING CUSHION PAD |
| 18 | 8142152 | SPRING-LEVERAGE |
| 19 | 8142153 | LEVERAGE-BRAKE |
| 20 | 8142154 | NUT M5 |
| 21 | 8142155 | FLAT WASHER 5 |
| 22 | 8142156 | TORSION SPRING |
| 23 | 8142157 | FRONT BRAKE GUIDE |
| 24 | 8142158 | BUMP HAMMER AXIS |
| 25 | 8142159 | BRAKE AXIS |
| 26 | 8142160 | BOLT M5×30 |
| 27 | 8142161 | NUT M8×1 |
| M | ||
| 1 | 8142162 | BAR |
| 2 | 8142163 | CHAIN |
| 3 | 8142164 | BAR SHEATH |
| 1 | 8142165 | FUEL PIPE BASE |
| 2 | 8142166 | FUEL FILTER |
| 3 | 8142167 | CIRCLIP NO7 |
| 4 | 8142168 | FULE PIPE I |
| 5 | 8142169 | CIRCLIP NO5 |
| 6 | 8142170 | FUEL PIPE CONNECTION |
| 7 | 8142171 | FUEL PIPE II |
| 8 | 8142172 | CIRCLIP NO4 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stayer websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stayer brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Stayer OLMO G1-250B
5 Items
