Stayer Spare Parts for Mitre Saw SC250W
Stayer Genuine spare parts or replacement parts for to repair Mitre Saw SC250W.Fix Your Mitre Saw SC250W. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Stayer Spare Parts for Mitre Saw SC250W
Fix Your Mitre Saw SC250W. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of the Mitre Saw and the respective parts of the code.
| Mitre Saw Stayer SC250W | ||
| # | Part Num. | Description |
| 1 | 5009436 | SCREW |
| 2 | 5009437 | LOCK HANDLE COVER |
| 3 | 5009438 | KNOB |
| 4 | 5009439 | SPRING WASHER |
| 5 | 5009440 | STEEL BALL |
| 6 | 5009441 | O-RING |
| 7 | 5009442 | LOCK HANDLE CONNECT |
| 8 | 5009443 | WASHER |
| 9 | 5009444 | SCREW |
| 10 | 5009445 | STEEL SET |
| 11 | 5009446 | WASHER |
| 12 | 5009447 | SCREW |
| 13 | 5009448 | WAVE WASHER |
| 14 | 5009449 | SPRING |
| 15 | 5009450 | STEEL BALL |
| 16 | 5009451 | BASE |
| 17 | 5009452 | EXTENSION SUPPORT |
| 18 | 5009453 | ROUND BASE POINTER |
| 19 | 5009454 | SCREW |
| 20 | 5009455 | ROUND BASE LINING PLATE |
| 21 | 5009456 | SCREW |
| 22 | 5009457 | BLADE PROTECTER |
| 23 | 5009458 | SCREW |
| 24 | 5009459 | ROUND BASE |
| 25 | 5009460 | CLAMPING BOARD |
| 26 | 5009461 | LEFT FIXED PROTECTER |
| 27 | 5009462 | SCREW |
| 28 | 5009463 | ROUND BASE COVER BOARD |
| 29 | 5009464 | SCREW |
| 30 | 5009465 | JOINT SHAFT |
| 31 | 5009466 | SPRING |
| 32 | 5009467 | PUSHER |
| 33 | 5009468 | SCREW |
| 34 | 5009469 | SCREW |
| 35 | 5009470 | SCREW |
| 36 | 5009471 | BAR HOLDER |
| 37 | 5009472 | POINTER |
| 38 | 5009473 | SCREW |
| 39 | 5009474 | LABEL |
| 40 | 5009475 | SUPPORT |
| 41 | 5009476 | RUBBER FEET |
| 42 | 5009477 | SUPPORT PUSHER AXIS |
| 43 | 5009478 | SCREW |
| 44 | 5009479 | SCREW |
| 45 | 5009480 | CLAMPING HANDWHEEL |
| 46 | 5009481 | CLAMPING HOLDER |
| 47 | 5009482 | WASHER |
| 48 | 5009483 | SPRING |
| 49 | 5009484 | CLAMPING PAN |
| 50 | 5009485 | WASHER |
| 51 | 5009486 | SCREW |
| 52 | 5009487 | SWITCH |
| 53 | 5009488 | RIGHT FIXED PROTECTED |
| 54 | 5009489 | FRAME COVER |
| 55 | 5009490 | SCREW LEFT THREAD M8x20 |
| 56 | 5009491 | CLAMPING BOARD WASHER |
| 57 | 5009492 | OUTER FLANGE |
| 58 | - | BLADE |
| 59 | 5009493 | INNER FLANGE |
| 60 | 5009494 | COVER RIVET |
| 61 | 5009495 | TRANSPARENT GUARD |
| 62 | 5009496 | LOCATION BOARD |
| 63 | 5009497 | CIRCLIP |
| 64 | 5009498 | SCREW |
| 65 | 5009499 | BEARING HOUSE |
| 66 | 5009500 | COLLAR |
| 67 | 5009501 | BALL BEARING 6203 |
| 68 | 5009502 | GEAR |
| 69 | 5009503 | PRINCIPLE AXIS |
| 70 | 5009504 | WASHER |
| 71 | 5009505 | ELASTIC COLLAR |
| 72 | 5009506 | PUSH BAR |
| 73 | 5009507 | LOCK KNOB |
| 74 | 5009508 | SCREW |
| 75 | 5009509 | FRAME |
| 76 | 5009510 | PUSHER |
| 77 | 5009511 | TWO CORE WIRE |
| 78 | 5009512 | BALL BEARING 6201 |
| 79 | 5009513 | CLAMPING HANDWHEEL |
| 80 | 5009514 | ARMATURE |
| 81 | 5009515 | BALL BEARING 629 |
| 82 | 5009516 | TIGHTED WASHER |
| 83 | 5009517 | SCREW |
| 84 | 5009518 | WINDING GUARD RING |
| 85 | 5009519 | SCREW |
| 86 | 5009520 | SPRING WASHER |
| 87 | 5009521 | STATOR - FIELD |
| 88 | 5009522 | UPPER HANDLE |
| 89 | 5009523 | CAPACITANCE |
| 90 | 5009524 | SCREW |
| 91 | 5009525 | CONNECTION POLE |
| 92 | 5009526 | ELECTRONIC BOARD |
| 93 | 5009527 | BRUSH HOLDER |
| 94 | 5009528 | COPPER SET |
| 95 | 5009529 | CARBON BRUSH |
| 96 | 5009530 | MOTOR HOUSING |
| 97 | 5009531 | SCREW |
| 98 | 5009532 | HOUSING COVER |
| 99 | 5009533 | LOWER HANDLE |
| 100 | 5009534 | SCREW |
| 101 | 5009535 | SWITCH COVER BOARD |
| 102 | 5009536 | UPPER CONNECT BAR |
| 103 | 5009537 | LEFT TABLE PROTECTER |
| 104 | 5009538 | WASHER |
| 105 | 5009539 | MIDDLE CONNECT BAR |
| 106 | 5009540 | SCREW |
| 107 | 5009541 | LOWER CONNECT BAR |
| 108 | 5009542 | SCREW |
| 109 | 5009543 | PUSHER |
| 110 | 5009544 | RING |
| 111 | 5009545 | BEARING HK0910 |
| 112 | 5009546 | SPRING |
| 113 | 5009547 | SCREW |
| 114 | 5009548 | WASHER |
| 115 | 5009549 | POTHOOK |
| 116 | 5009550 | BLADE FELLOW |
| 117 | 5009551 | PUSH BAR SET |
| 118 | 5009552 | RIVET - NO LONGER AVAILABLE |
| 119 | 5009553 | WASHER |
| 120 | 5009554 | PUSH BAR BOLT |
| 121 | 5009555 | WASHER |
| 122 | 5009556 | WASHER |
| 123 | 5009557 | RUBBER DUST PROTECTER |
| 124 | 5009558 | LABEL SCALE |
| 125 | 5009559 | LOWER CONNECT BOX |
| 126 | 5009560 | CABLE ARMOR |
| 127 | 5009561 | CABLE & PLUG |
| 128 | 5009562 | INDUCTOR |
| 129 | 5009563 | CABLE LOCATED SET |
| 130 | 5009564 | SCREW |
| 131 | 5009565 | UPPER CJUNCTION BOX |
| 132 | 5009566 | SCREW |
| 133 | 5009567 | WASHER |
| 134 | 5009568 | SCREW |
| 135 | LABEL | |
| 136 | 5009569 | SPANNER SET |
| 137 | 5009570 | SCREW |
| 138 | 5009571 | GUIDE SPRING BAR |
| 139 | 5009572 | GUIDER SPRING |
| 140 | 5009573 | TABLE GUIDER |
| 141 | 5009574 | GUIDER CLAMPING PLATE |
| 142 | 5009575 | GUIDER CLAMPING HANDWHEEL |
| 143 | 5009576 | SCREW |
| 144-150 153-157 |
5009577 | SET GONIOMETRO |
| 151 | 5009578 | TOP TABLE |
| 152 | 5009579 | TABLE LINING PLATE |
| 158 | 5009580 | PUSH BAR |
| 159 | 5009581 | SCREW |
| 160 | 5009582 | RIGHT TABLE PROTECTER |
| 161 | 5009583 | SCREW |
| 162 | 5009584 | TABLE CONNECT BAR |
| 163 | 5009585 | SCREW |
| 164 | 5009586 | SPANNER |
| 165 | 5009587 | FLAT BLADE SPANNER |
| 166 | 5009588 | SLEEVE BLADE SPANNER |
| 167 | 5009589 | SCREW |
| 168 | 5009590 | SPANNER |
| 169 | 5009591 | TABLE GUIDER |
| 170 | 5009592 | SCREW |
| 171 | 5009593 | SPANNER |
| 172 | 5009594 | BACK EXTENSION SUPPORT |
| 173 | 5009595 | SCREW |
| 174 | 5009596 | BACK EXTENSION SUPPORT BOARD |
| 175 | 5009597 | EXTENSION FEET SPRING |
| 177 | 5009730 | DUST BAG |
| 65-71 | 5009692 | SPINDLE SET |
| 25-27-30 31-33-37 39-40-42 44-53-79 82 |
5009693 | SUPPORTING ASSEMBLY |
| 103-162 160-159 |
5009694 | SET UPPER CARTER |
| 72-73-115 | 6009695 | SET LEVER |
| 136-171 | 5009696 | SET ELEVATION GUIDE |
| 61-102-105 107 |
5009699 | SET CARTER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stayer websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stayer brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
