Stayer Spare Parts for Mitre Saw SC391W
€0.84
Tax included
Stayer Spare Parts for Mitre Saw SC391W
STAYER Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Mitre Saw SC391W.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Stayer Spare Parts for Mitre Saw SC391W
STAYER Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Mitre Saw SC391W.
In the following table, look for the model of the Mitre Saw and the respective parts of the code.
| Mitre Saw Stayer SC391W | ||
| # | Part Num. | Description |
| 1 | 50121 | SCREW |
| 2 | 50122 | ALUM BASE |
| 3 | 50123 | SCREW |
| 4 | 50124 | SCREW |
| 5 | 50125 | PVC PLATE BASE |
| 6 | 50126 | SCREW |
| 7 | 50127 | SCREW |
| 8 | 50128 | PLETINE SCREW |
| 9 | 50129 | POINTER |
| 10 | 501210 | PIN |
| 11 | 501211 | LOCK NUT |
| 12 | 501212 | SCREW |
| 13 | 501213 | PLETINE |
| 14 | 501214 | DOWN TABLE |
| 15 | 501215 | RUBBER FEET |
| 16 | 501216 | SCREW |
| 17 | 501217 | NUT |
| 18 | 501218 | RULER |
| 19 | 501219 | SCREW |
| 20 | 501220 | RULLER SCREW |
| 21 | 501221 | WASHER |
| 22 | 501222 | NUT |
| 23 | 501223 | NUT |
| 24 | 501224 | LATERAL PLETINE |
| 25 | 501225 | SPRING |
| 26 | 501226 | PIN |
| 27 | 501227 | FIXED PLETINE |
| 28 | 501228 | SPRING |
| 29 | 501229 | PLETINE |
| 30 | 501230 | SCREW |
| 31 | 501231 | DOWN PLETINE |
| 32 | 501232 | UP PLETINE |
| 33 | 501233 | SCREW |
| 34 | 501234 | PLATE |
| 35 | 501235 | UPPER PLATE |
| 36 | 501236 | KNOB |
| 37 | 501237 | SPRING |
| 38 | 501238 | SCREW |
| 39 | 501239 | SCREW |
| 40 | 501240 | UPPER SCREW 8x65 TE/Z |
| 41 | 501241 | RETURN SPRING |
| 42 | 501242 | SPACER |
| 43 | 501243 | WASHER |
| 44 | 501244 | NUT |
| 45 | 501245 | SCREW |
| 46 | 501246 | WASHER |
| 47 | 501247 | WASHER |
| 48 | 501248 | DOWN PROTECTOR |
| 49 | 501249 | O-RING |
| 50 | 501250 | LATERAL PROTECTION |
| 51 | 501251 | WASHER |
| 52 | 501252 | SCREW |
| 53 | 501253 | SCREW |
| 54 | 501254 | PIN |
| 55 | 501255 | PLASTIC COVER |
| 56 | 501256 | SCREW |
| 57 | 501257 | SCREW |
| 58 | 501258 | HALF HANDLE |
| 59 | 501259 | SCREW |
| 60 | 501260 | CAPACITOR |
| 61 | 501262 | PUSH |
| 62 | 115612 | ELECTRONIC MODULE |
| 63 | 501263 | HALF HANDLE |
| 64 | 501264 | SWITCH |
| 65 | 501265 | SCREW |
| 66 | 501266 | PIN |
| 67 | 501267 | PUSH BUTTON |
| 68 | 501268 | PUSH BUTTON |
| 69 | 501269 | SCREW |
| 70 | 501270 | VIEWER |
| 71 | 501271 | SCREW |
| 72 | 501272 | WASHER |
| 73 | 501273 | PIN |
| 74 | 501274 | SCREW |
| 75 | 501275 | O-RING |
| 76 | 501276 | DISC GUARD |
| 77 | 501277 | LEVER |
| 78 | 501278 | O-RING |
| 79 | 501279 | INNER FLANGE DISC LOCK |
| 81 | 501280 | PLETINE |
| 82 | 501281 | PIN |
| 83 | 501282 | OUTER FLANGE DISC LOCK |
| 84 | 501283 | SCREW |
| 85 | 501284 | PUSH |
| 86 | 501285 | LATERAL COVER |
| 87 | 501286 | SCREW LEVER |
| 88 | 501287 | WASHER |
| 89 | 501288 | SPRING LEVER |
| 90 | 501289 | SPRING |
| 91 | 501290 | CARTER LEVER |
| 92 | 501291 | SCREW |
| 93 | 501292 | WASHER |
| 94 | 501293 | UPPER GUIDE |
| 95 | 501294 | SCREW |
| 96 | 501295 | TABLE SUPPORT |
| 97 | 501296 | SUPPORT TABLE |
| 98 | 501297 | PLASTIC TABLE INSERT 481022.41 |
| 99 | 501298 | SCREW |
| 100-106 | 501299 | SET UPPER CARTER |
| 107 | 5012100 | WASHER |
| 108 | 5012101 | LOCK TABLE |
| 109 | 5012102 | SPRING |
| 110 | 5012103 | PLETINE FIXED TABLE |
| 111 | 5012104 | RATCHER |
| 112 | 5012105 | GEAR HOUSING |
| 113 | 5012106 | CORD LOCKING PLATE |
| 114 | 5012107 | CABLE ARMOR |
| 115-123 | 5012108 | UPPER GUIDE |
| 115B | 5012208 | UPPER LONG GUIDE |
| 124 | 5012109 | SPRING |
| 125 | 5012110 | RUBBER SLEEVE |
| 126 | 5012111 | KNOB |
| 127 | 5012112 | O-RING |
| 129 | 5012114 | MOTOR SCREW |
| 130 | 5012115 | SPINDLE |
| 131 | 5012116 | MOTOR |
| 132 | 5012117 | SPRING HOLDER |
| 133 | 5012118 | POINTER |
| 134 | 5012119 | WASHER |
| 135 | 5012120 | SCREW |
| 136 | 5012121 | NUT |
| 137 | 5012122 | SCREW |
| 138 | 5012123 | LATERAL COVER |
| 139 | 5012124 | NUT |
| 140 | 5012125 | SPRING |
| 141 | 5012126 | WASHER |
| 142 | 5012127 | SCREW |
| 143 | 5012128 | NUT |
| 144 | 5012129 | WASHER |
| 145-148 | 5012130 | RATCHER KNOB |
| 149 | 5012131 | NUT |
| 150 | 5012132 | RETURN SPRING |
| 151 | 5012133 | LATERAL COVER |
| 152 | 5012134 | SCREW |
| 153 | 5012135 | RIP FENCE |
| 154 | 5012136 | SCREW |
| 155 | 5012137 | SUPORTING BASE |
| 156 | 5012138 | KNOB |
| 157 | 5012139 | PLETINE |
| 158 | 5012140 | WASHER |
| 159-163 | 5012141 | STOP SET |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stayer websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stayer brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
