We have the original Spares STAYER for Angle Grinder SAB22-18 the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
Fix Your Angle Grinder SAB22-18. All Spares are original and can be supplied at discounted prices. Our Spares are Genuine Parts Guaranteed.
In the following table, look for the model of the hammerr and the respective parts of the code.![]()
| ANGLE GRINDER SAB22-18 | ||
| 1 | 5019310 | OUTER FLANGE |
| 3 | 5019311 | INNER FLANGE |
| 4 | 5019312 | PROTECT GUARD 180MM |
| 5 | 5019313 | PROTECT GUARD 230MM |
| 5 | 5019314 | SCREW |
| 6 | 5019315 | NUT |
| 7 | 5019316 | DUST COVER |
| 8 | 5019317 | SCREW |
| 9 | 5019318 | SPRING WASHER |
| 10 | 5019319 | WASHER |
| 11 | 5019320 | FRONT COVER |
| 12 | 5019321 | RING |
| 13 | 5019322 | BEARING 6203-2Z |
| 14 | 5019323 | FRONT BEARING COVER |
| 15 | 5019324 | SPRING WASHER |
| 16 | 5019325 | SCREW |
| 17 | 5019326 | KEY |
| 18 | 5019327 | SPINDLE |
| 19 | 5019328 | WHEEL GEAR |
| 20 | 5019329 | CIRLIP |
| 21 | 5019330 | BEARING 609-2Z |
| 22 | 5019331 | TOP PIN |
| 23 | 5019332 | SIDE HANDLE |
| 24 | 5019333 | SCREW |
| 25 | 5019334 | GEAR BOX |
| 26 | 5019335 | SPINDLE LOCK |
| 27 | 5019336 | LOCK SPRING |
| 28 | 5019337 | CIRCLIP |
| 29 | 5019338 | ANTI-DUST CAP |
| 30 | 5019339 | NUT |
| 31 | 5019340 | PINION GEAR |
| 32 | 5019341 | BEARING 6301-2Z |
| 33 | 5019342 | BEARING COVER |
| 34 | 5019343 | ARMATURE |
| 35 | 5019344 | ANTI-DUST RING |
| 36 | 5019345 | BEARING 6200-2Z |
| 37 | 5019346 | BEARING SLEEVE |
| 38 | 5019347 | SCREW |
| 39 | 5019348 | WIND GUARD |
| 40 | 5019349 | STATOR |
| 41 | 5019350 | HOUSING |
| 42 | 5019351 | SCREW |
| 43 | 5019352 | CARBON BRUSH COVER |
| 44 | 5019353 | CARBON BRUSH |
| 45 | 5019354 | CARBON BRUSH HOLDER |
| 46 | 5019355 | SPRING BRUSH |
| 47 | 5019356 | LEFT HANDLE |
| 48 | SOFT START | |
| 49 | 5019358 | CAPACITOR |
| 50 | 5019359 | SCREW |
| 51 | 5019360 | RIGHT HANDLE |
| 52 | 5019361 | SCREW |
| 53 | 5019362 | SWITCH |
| 54 | 5019363 | CABLE CLAMP |
| 55 | 5019364 | CABLE PROTECTOR |
| 57 | 5019366 | SPANNER |
| 58 | 5019367 | HEX WRENCH |
| 59 | 5019650 | WASHER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stayer websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stayer brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
