authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder SAB730.
In the following table, look for the model of the hammerr and the respective parts of the code.
| ANGLE GRINDER SAB 730 | ||
| # | Part Num. | Description |
| 1 | 50081 | BEARING SLEEVE |
| 2 | 50082 | BEARING |
| 3 | 50083 | ARMATURE 220V |
| 4 | 50084 | O-RING |
| 5 | 50085 | PLETINE |
| 6 | 50086 | BEARING |
| 7-9 | 50087 | SET LOCK BUTTON |
| 10 | 50088 | SCREW |
| 11 | 50089 | HEAD |
| 12 | 500810 | NEEDLE BEARING HK0810 |
| 13 | 500811 | RING |
| 14 | 500812 | CROWN |
| 15 | 500813 | RING |
| 16 | 500814 | BEARING |
| 17 | 500815 | FRONT COVER |
| 18 | 500816 | WASHER |
| 19 | 500817 | WASHER |
| 20 | 500818 | SCREW |
| 21 | 500819 | CARTER |
| 22 | 500820 | WASHER |
| 23 | 500821 | SCREW |
| 24 | 500822 | ARMOR |
| 25 | 500823 | SCREW |
| 27 | 500825 | BOTTON COVER |
| 28 | 500826 | SCREW |
| 29 | 500827 | CARBON BRUSH SET |
| 30 | 500828 | ROLL SPRING |
| 31 | 500829 | CARBON BRUSH HOLDER |
| 32 | 5008320 | MOTOR HOUSING 2010 |
| 32 | 500830 | HOUSING |
| 33 | 500831 | PIN |
| 34 | 500832 | SCREW |
| 35 | 500833 | WASHER |
| 36 | 500834 | STATOR |
| 37 | 500835 | HANDLE |
| 38 | 500836 | PINION |
| 39 | 500837 | WASHER |
| 40 | 500838 | NUT |
| 41 | 500839 | SCREW |
| 42 | 500840 | AIR FUN |
| 44 | 500841 | CLAMP |
| 46 | 500842 | SWITCH |
| 47 | 500843 | CAPACITOR |
| 48 | 5008321 | SWITCH DRAW LEVE 2010 |
| 48 | 500844 | SWITCH DRAW LEVER |
| 49 | 5008323 | SWITCH BUTTON 2010 |
| 49 | 500845 | SWITCH BUTTON |
| 50 | 500846 | SCREW |
| 51 | 500847 | HALF ROUND PIN |
| 52 | 500848 | OUTPUT SPINDLE |
| 53 | 500849 | INNER FLANGE |
| 54 | 500850 | OUTER FLANGE |
| 3 | 5008185 | ARMATURE 120 V |
| 36 | 5008184 | STATOR 120 V |
