Stayer Spare Parts for Circular Saw CM230

€2.37
Tax included

Stayer Spare Parts for Circular Saw CM230

Stayer genuine spare parts for the replacement or to fix of Circular Saw for Iron CM230
ITEM CODE: 75130
Quantity
on 10/15 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Stayer Spare Parts for Circular Saw CM230

Stayer genuine spare parts for the replacement or to fix of Circular Saw for Iron CM230

In the following table, look for the model of the CIRCULAR SAWS and the respective parts of the code.
Circular Saw for Iron CM230
CIRCULAR SAW CM230
# Part Num. Description
1 75130 ARBOR BOLT
2 75131 OUTER ARBOR FLANGE
3 75132 INNER FLANGE
4 75133 FLAT WASHER
5 75134 BEARING COVER PLATE
6 75135 LOWER RETRACTING BLADE GUARD
7 75136 SPRING
8 75137 PAN HEAD SCREW
9 75138 SPINDLE
10 75139 WOODRUFF KEY
11 75140 BALL BEARING
12 75141 CIRCLIP
13 75142 OUTPUT GEAR
14 75143 BALL BEARING
15 75144 BASE
15,1 75270 PLETINE
15,2 75271 ANGLE GUIDE
15,3 75272 PLETINE
15,4 75273 SCREW
15,5 75274 NUT
17 75145 BEVEL LOCKING BLOCK
18 75146 BEVEL LOCK KNOB
19 75147 FLAT WASHER
20 75148 SCREW
21 75149 DEPTH LOCK PIN
22 75150 DEPTH LOCK LEVER
23 75151 E-CLIP
24 75152 RIP FENCE
25 75153 COVER LOCK KNOB
26 75154 PIN
27 75155 SPRING
28 75156 OUTER BLADE COVER
29 75157 INNER BLADE COVER
30 75158 FLAT HEAD SCREW
31 75159 GEAR PLATE
32 75160 PAN HEAD SCREW
33 75161 DUST COVER PLATE
34 75162 PAN HEAD SCREW
35 75163 BUMP STOP
36 75164 MAIN BODY CASTING
37 75165 SCREW
38 75166 BALL BEARING
39 75167 MOTOR CABLE COVER PLATE
40 75168 BLADE LOCK LEVER
41 75169 FAN SHROUD
42 75170 SIDE HANDLE
43 75171 ARMATURE
44 75172 BALL BEARING
45 75269 PAN HAEAD SCREW W/SPRING WASHER
46 75173 STATOR
47 75174 MOTOR HOUSING
48 75175 FLAT WASHER
49 75176 PAN HAEAD SCREW W/SPRING WASHER
50 75177 BRUSH HOLDER
51 75178 CARBON BRUSH
52 75179 BRUSH CAP
53 75180 SCREW
54 75181 MAIN HANDLE HALF (RH)
55 75182 MAIN HANDLE HALF (LH)
56 75183 PAN HAEAD SCREW
57 75184 PAN HAEAD SCREW
58 75185 CORD CLIP
59 - POWER SUPPLY CORD
60 75187 CORD ARMOR

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stayer websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stayer brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
