We have the original Spares STAYER for Angle Grinder SAB21-180 the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
Fix Your Angle Grinder SAB21-180. All Spares are original and can be supplied at discounted prices. Our Spares are Genuine Parts Guaranteed.
In the following table, look for the model of the hammerr and the respective parts of the code.
.
| GRINDER SAB21-180 | ||
| 1 | 50001 | STATOR |
| 2 | 50002 | AIR FAN |
| 3 | 50003 | RUBBER BEARING |
| 4 | 50004 | BEARING 609 |
| 5 | 50005 | BEARING COVER |
| 6 | 50006 | ARMATURE |
| 7 | 50007 | AIR FAN |
| 8 | 50008 | CIRCLIP |
| 9 | 50009 | BEARING 6202 |
| 10 | 5000430 | PINION |
| 11 | 500011 | SPACER |
| 12 | 500012 | WASHER |
| 13 | 500013 | SCREW |
| 14 | 500014 | HEAD BUTTON |
| 15 | 500015 | SPRING HEAD |
| 16 | 500016 | RUBBER RING |
| 17 | 500017 | HEAD |
| 18 | 500018 | HANDLE |
| 19 | 500019 | BEARING 6003 |
| 20 | 500020 | WASHER |
| 21 | 5000429 | CROWN |
| 22 | 500022 | CIRCLIP |
| 23 | 500023 | BEARING 6001 |
| 24 | 500024 | RUBBER RING |
| 25 | 500025 | COVER |
| 26 | 500026 | SPINDLE |
| 27 | 500027 | COVER |
| 28 | 500028 | CARTER SCREW |
| 29 | 500029 | WASHER |
| 30 | 500030 | WASHER |
| 31 | 5000428 | CARTER |
| 32 | 500032 | INNER FLANGE |
| 34 | 500033 | OUTER FLANGE |
| 36 | 500034 | COVER SCREW |
| 37 | 500035 | WASHER |
| 38 | 500036 | WASHER |
| 40 | 500038 | CARBON BRUSH CAP |
| 41 | 500039 | SCREW |
| 42 | 500040 | COVER CARBON BRUSH |
| 43 | 500041 | CARBON BRUSH |
| 44 | 500042 | CARBON BRUSH HOLDER |
| 45 | 500044 | LEFT HANDLE |
| 47 | 500045 | CABLE ARMOR |
| 49 | 500047 | PLETINE |
| 50 | 500048 | SCREW |
| 51 | 500049 | SCREW |
| 52 | 500050 | SCREW |
| 53 | 500051 | RIGHT HANDLE |
| 54 | 500052 | SWITCH |
| 55 | 500053 | SCREW |
| 56 | 500054 | COVER |
| 57 | 500055 | CAPACITOR |
| 58 | 500056 | FIX |
| 59 | 500057 | SCREW |
| 60 | 500058 | HOUSING |
| 61 | 500059 | SERVICE KEY |
| 62 | 500060 | ALLEN KEY |
