Lavor Floor Scrubber Drier L5 50B CBT Parts
€97.10
Tax included
Lavor Pro Original Parts for Floor Scrubber Drier LAVOR L5 50B CBT
Lavor original spare parts for to replace broken parts for to fix Floor Scrubber Drier LAVOR L5 50B CBT-8.527.0068.Fix Your Floor Scrubber Drier LAVOR L5 50B CBT-8.527.0068. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Pro Original Parts for Floor Scrubber Drier LAVOR L5 50B CBT
Lavor original spare parts for to replace broken parts for to fix Floor Scrubber Drier LAVOR L5 50B CBT+2XSPIRALCELL-GIALLO/GR.SC.-8.527.0068.In the following tables, look for the spare part and its respective code.
| LAVOR L5 50B CBT+2XSPIRALCELL-GIALLO/GR.SC.-8.527.0068 | ||
| Pag.1 | ||
| # | Part Num | Description |
| 0 | 5.511.2238 | SWEEPER ASSEMBLY Y21B MOD PP0.6 D483 |
| 0 | 5.511.1930 | LOWER TANK ASSEMBLY + UPPER FREE B+CBT |
| 0 | 5.511.1886 | FREE COVER ASSEMBLY |
| 0 | 5.511.2268 | FREE SQUEGEE ASSEMBLY 2.0 |
| 1 | 5.511.1886 | FREE COVER ASSEMBLY |
| 2 | 4.508.0551 | FREE UPPER RECOVERY TANK |
| 3 | 0.108.0025 | ON-BOARD BATTERY CHARGER POWER CABLE EU SCHUKO PLUG |
| 4 | 0.107.0054 | 12V 75AH BT DC 5.5 GEL BATTERY |
| 5 | 5.511.0673 | BATTERY CONNECTION WIRING ASSEMBLY W/ EYELET CABLE |
| 6 | 5.511.2268 | FREE SQUEGEE ASSEMBLY 2.0 |
| 7 | 5.511.2238 | SWEEPER ASSEMBLY Y21B MOD PP0,6 D483 |
| 8 | 4.508.1554 | BOOMPER FOR FREE/SWIFT EVO PLATE L=1470 H=30 |
| 9 | 7.504.0219 | MANUAL FREE/A5/SWIFT EVO+CE LAVOR 17L A5 260F |
| ASSIEME SPAZZ. Y21B MOD PP0,6 D483 Pag.2 | ||
| 1 | 5.511.2201 | BIDIRECTIONAL BRUSH CONNECTOR ASSEMBLY WITH PRESSURES |
| ASSIEME SERBATOIO INF.+SUP. FREE B+CBT Pag.3 | ||
| 0 | 5.511.1923 | UPPER TANK ASSEMBLY FREE B+CBT |
| 0 | 5.511.1920 | LOWER TANK ASSEMBLY FREE B |
| 1 | 5.509.2208 | COMPACT FREE SUCTION TUBE ASSEMBLY WITH SLEEVES |
| 2 | 4.507.0854 | SQUEEGEE LIFT WIRE BRACKET |
| 3 | 4.508.0803 | TANK ROTATION SPACER |
| 4 | 4.508.0738 | TANK ROTATION TUBE |
| 5 | 4.507.0701 | TANK LOCKING PIN |
| 6 | 4.507.0707 | TANK LOCKING SPRING |
| 7 | 3.099.0307 | BLACK TIE ROD HANDLE MODEL MT/58/FFC-M6 |
| 8 | 4.508.1064 | SWIFT/FLICK DETERGENT TANK FILTER |
| ASSIEME COP.FREE Pag.4 | ||
| 1 | 4.508.0552 | PANDA BUTTON |
| 2 | 3.099.0647 | SUCTION LID SUPPORT BRACKET |
| 3 | 4.507.0713 | FREE SUCTION COVER GASKET KIT |
| 4 | 6.505.0092 | KIT GUARN. COP.ASP.FREE |
| ASSIEME SQUEGEE UOMO A TERRA 2.0 Pag.5 | ||
| 1 | 5.511.1823 | SQUEGEE WHEEL ASSEMBLY |
| 3 | 3.099.1900 | EXTENDED LOBE WHEEL D.52 M8X23 |
| 4 | 3.099.0467 | M8 THROUGH FLYWHEEL 177/30 |
| 5 | 4.508.0224 | BUMPER PROTECTION WHEEL |
| 6 | 4.508.1544 | BUSHING FOR BUMPER WHEEL |
| 7 | 4.505.0886 | SQG BODY DIE-CAST V L= 780MM DIRECT CONNECTION MACHINED |
| 8 | 4.508.X468 | FRONT BLADE |
| 9 | 4.508.0505 | RUBBER WIPER SUPPORT |
| 10 | 4.508.X467 | REAR BLADE |
| 11 | 3.200.0168 | SEAL OR 36.2X3.53 NBR SH.70 REF.4143 |
| 12 | 3.099.1109 | M8 THROUGH HANDWHEEL RED RAL3000-F177/30 |
| 13 | 4.508.1556 | SPRING GUIDE BUSH |
| 14 | 4.507.0062 | SQG SUSPENSION SPRING |
| 15 | 4.507.1467 | SQG WHEEL SUPPORT |
| 16 | 3.006.0075 | SQUEGEE WHEEL D.50X21 D.8 IN RUBBER |
| 17 | 4.506.0132 | SQUEEGE WHEEL BUSH |
| ASSIEME SERBATOIO SUP. FREE B+CBT Pag.6 | ||
| 0 | 5.511.1896 | BRACKET ASSEMBLY WITH ANDERSON PLUG CABLE FREE |
| 0 | 5.511.1898 | FREE BATTERY ASPIRATOR MOTOR ASSEMBLY |
| 0 | 5.511.1890 | FREE PLATE LIFT LEVER ASSEMBLY / SQEEGEE |
| 0 | 5.511.1894 | FREE PULLEY ASSEMBLY |
| 0 | 5.511.1655 | DRAIN PIPE ASSEMBLY WITH CAP AND CLAMP |
| 0 | 5.511.0672 | BFREE EVO WIRED ELECTRIC BOX |
| 1 | 5.511.1656 | FREE FLOAT BASKET ASSEMBLY |
| 2 | 4.508.1652 | MOTOR PROTECTION SPONGE |
| 3 | 4.507.0700 | TANK LOCKING BRACKET |
| 4 | 5.511.1898 | FREE BATTERY ASPIRATOR MOTOR ASSEMBLY |
| 5 | 4.508.1323 | MOTOR SPACER |
| 6 | 5.511.1894 | FREE PULLEY ASSEMBLY |
| 7 | 5.511.1655 | DRAIN PIPE ASSEMBLY WITH CAP AND CLAMP |
| 8 | 3.099.0343 | PIPE STOP CLIP DIAM.40 |
| 9 | 5.511.1896 | BRACKET ASSEMBLY WITH ANDERSON PLUG CABLE FREE |
| 10 | 4.507.0699 | CABLE PROTECTION |
| 11 | 3.099.1329 | STAINLESS STEEL CABLE D.2.5X133 L=670+SHEATH FOR SQG |
| 12 | 5.511.1890 | ASSEMBLY LEVERS LIFT PLATE/SQEEGEE FREE |
| 13 | 4.507.1174 | MINIMONEY HOLDER SHEET METAL |
| 14 | 5.511.0672 | BFREE EVO 1 WIRED ELECTRIC BOX |
| 15 | 0.108.0042 | CHARGER NE286-L 24V 10A |
| ASSIEME SERBATOIO INF. FREE B Pag.7 | ||
| 0 | 5.509.2225 | GR.BRUSH PLATE FREE EVO 50B-BT MAGNETIC PLATE WITH ELECTRIC VEHICLE B |
| 0 | 5.511.0687 | FREE /NOX COMPACT TAP ASSEMBLY |
| 0 | 5.511.1474 | FREE/SWIFT SWIVEL WHEEL ASSEMBLY |
| 0 | 5.511.1895 | FREE TRACTION SPRING PLATE ASSEMBLY |
| 0 | 5.511.1891 | FREE WATER CONTROL ASSEMBLY |
| 0 | 5.511.0939 | FREE NON-DRIVE AXLE ASSEMBLY |
| 0 | 5.511.1882 | FREE/SWIFT EVO SQUEGEE SUPPORT ASSEMBLY |
| 1 | 5.511.1891 | FREE WATER CONTROL ASSEMBLY |
| 2 | 4.508.0477 | SWIFT/FREE SOLUTION LOWER TANK GR.SC.RAL.7021 |
| 3 | 4.508.0739 | FILTERING SPONGE |
| 4 | 5.511.1895 | FREE TRACTION SPRING PLATE ASSEMBLY |
| 5 | 5.509.2225 | FREE TRACTION PLATE EVO 50B-BT MAGNETIC PLATE WITH ELECTRIC VEHICLE B |
| 6 | 5.511.0687 | COMPACT FREE /NOX TAP ASSEMBLY |
| 7 | 3.102.0026 | WATER FILTER WITHOUT FLOW REGULATOR PORTAG.-PORTAG.D15 |
| 8 | 4.507.0793 | LEVER SUPPORT PLATE |
| 9 | 5.511.0939 | NON-TRACTED AXLE ASSEMBLY FREE/SWIFT |
| 10 | 4.508.0689 | WHEEL FIXING AXLE |
| 11 | 5.511.1474 | PIVOTING WHEEL ASSEMBLY FREE/SWIFT |
| 12 | 5.511.1882 | SQUEGEE SUPPORT ASSEMBLY FREE/SWIFT EVO |
| 13 | 5.511.0937 | TANK DRAIN CAP ASSEMBLY W/OR FREE/SWIFT |
| ASSIEME RUOTA SQUEGEE Pag.8 | ||
| 1 | 3.099.1109 | M8 THROUGH-HANDWHEEL RED RAL3000-F177/30- |
| 2 | 4.508.1556 | SPRING GUIDE BUSH |
| 3 | 4.507.0062 | SQG SUSPENSION SPRING |
| 4 | 4.507.1467 | SQG WHEEL SUPPORT |
| 5 | 3.006.0075 | SMALL WHEEL FOR SQUEGEE D.50X21 D.8 IN RUBBER |
| 6 | 4.506.0132 | SQUEEGE WHEEL BUSH |
| ASSIEME LEVE ALZA PIATTO/SQEEGEE FREE Pag.9 | ||
| 1 | 5.513.0133 | BRUSH LIFTER LEVER ASSEMBLY WITH PIN |
| 2 | 5.513.0134 | COMPLETE LEVER SUPPORT |
| 3 | 4.507.0845 | DISTANCE FOR LEVERS D.10X8 |
| 4 | 5.513.0132 | SQUEEGEE LIFTER LEVER ASSEMBLY WITH PIN |
| 5 | 4.508.0971 | SPECIAL LEVER HANDLE |
| ASSIEME CARRUCOLA FREE Pag.10 | ||
| 1 | 3.099.0881 | C.INX D.2.5X133 G2/B4+PR.L=685 |
| 2 | 4.506.0141 | CABLE RETURN PULLEY SQG |
| 3 | 4.507.0708 | PIN FOR PULLEY L=118 |
| 4 | 3.099.1010 | SWIFT B AXLE RETAINING TUBE L=25 |
| 5 | 4.506.0142 | PULLEY FORK |
| 6 | 3.099.1010 | SWIFT B AXLE RETAINING TUBE L=25 |
| ASSIEME TUBO DI SCARICO C/TAPPO E FASCETTA Pag.11 | ||
| 1 | 4.208.0274 | PLUG DIAM.32MM FOR EXHAUST PIPE WITH STOP RING 1 |
| 2 | 3.752.0060 | FLEXIBLE EXHAUST TUBE RECUP. TANK D.31.5 L=550 1 |
| 3 | 3.099.0742 | METAL CLAMP 25-45 WIDE BAND 9MM WITH SLOTTED SCREW |
| SCATOLA ELETTRICA CABLATA BFREE EVO Pag.12 | ||
| 1 | 4.507.0706 | DEMAND LEVER |
| 2 | 3.099.1529 | HOLE COVER CAP D. 20 |
| 3 | 7.503.0132 | AD.SCL EASY-RB/COMPACT FREEB145X87MM CONTROLS POLYEST. |
| 4 | 4.508.0396 | ELECTRIC BOX COVER WASHER DRYER U.A.T. |
| 5 | 3.401.0113 | MICROSWITCH SXG02-88-J23 |
| 6 | 3.401.0119 | THERMAL CIRCUIT BREAKER 25A |
| 7 | 3.402.0017 | AUTOMOTIVE RELAY CB1AH-24V-70A |
| 8 | 4.508.0397 | ELECTRICAL BOX BASE WASHER DRYER U.A.T. |
| 9 | 3.499.0135 | 60A TAPE FUSE CENTRE DISTANCE 30MM |
| 10 | 6.505.0071 | REPLACEMENT KIT TERMINAL BLOCK 34050045 COMPLETE |
| 11 | 3.499.0276 | DIODE TYPE 1N4007 |
| 12 | 3.410.0022 | RELAY HOLDER BASE |
| 13 | 4.515.0002 | 24V CONTROL BOARD FUNCTION NO TRACTION W/BATTERY IND. |
| 14 | 7.503.0131 | AD. DISGIUN.SPAZZ.SCL B/ A9/A5 40.7X56MM POLYCARBON. |
| 15 | 5.511.1841 | WIRED KEY BLOCK KIT |
| ASSIEME STAFFA C/CAVO SPINA ANDERSON FREE Pag.13 | ||
| 1 | 4.507.0635 | ANDERSON SOCKET BRACKET 1 |
| 2 | 5.511.0703 | BATTERY CONNECTION CABLE SET |
| ASSIEME MOTORE ASPIRAZ.FREE BATTERIA Pag.14 | ||
| 1 | 6.505.0096 | KRON ZERO/XS-R SUCTION MOTOR KIT 1 |
| 2 | 4.508.0518 | IMPELLER PROTECTION FOR HOLES D.44 1 |
| 3 | 3.099.0347 | A-FLEX PVC-GLASS TUBE D.50 |
| GR.PIATTO SPAZZOLA FREE EVO 50B-BT PIATTO MAG.C/ELETTROV. BI Pag.15 | ||
| 0 | 5.511.1982 | FREE BATTERY SOLENOID VALVE ASSEMBLY 1 |
| 0 | 5.511.1978 | FREE PULLEY AXLE ASSEMBLY 1 |
| 0 | 5.511.1981 | FREE PLATE+OMEGA ASSEMBLY 1 |
| 1 | 5.511.1978 | FREE PULLEY AXLE ASSEMBLY 1 |
| 2 | 5.511.1977 | FREE GEAR MOTOR ASSEMBLY 1 |
| 3 | 5.511.1982 | FREE SOLENOID VALVE ASSEMBLY 1 |
| 4 | 4.508.0224 | BUMPER PROTECTION WHEEL 1 |
| 5 | 4.507.0308 | BUMPER WHEEL SUPPORT 1 |
| 6 | 5.511.1981 | FREE PLATE+OMEGA ASSEMBLY 1 |
| 7 | 4.508.1543 | 50CM BRUSH COVER FOR FREE EVO INJECTION 1 |
| 8 | 4.507.1470 | CENTERING DISC FOR BRUSH INJECTION FLANGE 1 |
| 9 | 4.507.1613 | BRUSH CONNECTOR FOR FIXING WITH PRESSURES 1 |
| 10 | 4.507.1469 | BUSHING FOR HEMI-BALL CENTERING INJECTION 1 |
| 11 | 4.508.1758 | CONICAL CENTERING INN.BRUSH WITH CENTRAL SCREW |
| ASSIEME ELETTROVALVOLA FREE BATTERIA Pag.16 | ||
| 1 | 4.512.0071 | 24 V SOLENOID VALVE WIRING 1 |
| 2 | 3.412.0044 | SOLENOID VALVE COMPLETE WITH NC COIL 24V DC (D161PS8-201) 1 |
| 3 | 3.099.0336 | ARMONVILLE HNA SKEIN DI=13 SP=3.2-1 M FOR CLEAR WATER 0.2 |
| 4 | 3.099.0336 | ARMONVILLE HNA SKEIN DI=13 SP=3.2-1 M FOR CLEAR WATER |
| ASSIEME ASSE CARRUCOLA FREE Pag.17 | ||
| 1 | 3.099.1730 | FREE EVO BATTERY PLATE LIFTING FIXED CABLE WITH BARREL 1 |
| 2 | 4.506.0142 | PULLEY FORK 1 |
| 3 | 4.507.1018 | LONG PULLEY AXLE 1 |
| 4 | 3.099.1160 | RUBBER TUBE D.13 X D.7.5 1M 0.027 |
| 5 | 4.507.1482 | PLATE LIFTING WIRE BRACKET 1 |
| 6 | 4.506.0141 | PULLEY CABLE RETURN SQG |
| ASSIEME PIATTO+OMEGA FREE Pag.18 | ||
| 1 | 4.507.1465 | OMEGA BAR PLATE BRUSH FREE EVO 1 |
| 2 | 3.099.1377 | SPLIT PIN 2.5X25 UNI 1336 WHITE GALVANIZED 4 |
| 3 | 4.608.0106 | ANTI-EXTRUSION RING (FOR SEALS 15X24X5) 4 |
| 4 | 4.507.1463 | FREE EVO PLATE |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
LAVOR L5 50B CBT - 8.527.0068
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
