Lavor Pressure Cleaner 1123 Parts
€6.67
Tax included
Lavor Original Parts for Pressure Cleaner RIO 1123 - 8.052.0701
Lavor original spare parts for to replace broken parts for to fix Pressure Washer RIO 1123 - 230/50 TS -G- LW S - 8.052.0701.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner RIO 1123 - 8.052.0701
Lavor original spare parts for to replace broken parts for to fix Pressure Washer RIO 1123 - 230/50 TS -G- LW S - 8.052.0701.
In the following tables, look for the spare part and its respective code.
| Pressure Washer RIO 1123 - 230/50 TS -G- LW S - 8.052.0701 | ||
| Pag.1 | ||
| # | Part Num | Description |
| 001 | 5.009.0213 | EXT SWITCH ASSEMBLY 0/1 BEEP 12(10)A + TRANSPARENT PROTECTION |
| 002 | 3.406.0004 | PG.11 TEARPROOF CABLE GLAND |
| 004 | 3.002.0135 | SELF-TAPPING SCREW TC-TC 2.9X13 UNI 6954 ZNT |
| 005 | 3.404.0017 | 25mF 450V CAPACITOR D.39X94 F/M |
| 006 | 4.008.0618 | LOWER RUBBER SEAL FOR ELECTRIC BOX |
| 007 | 4.008.0583 | FAN COVER FOR '96 MOTOR WITHOUT GRID |
| 008 | 3.099.0049 | STOP RING D.23 FOR FAN |
| 009 | 4.008.0714 | LOWERED PARTNER FAN h24 BLACK |
| 010 | 5.006.0171 | '02 CASING D110H100 230/50 2P (THERMAL WIRES) FOR FKX |
| 011 | 3.001.0033 | RADIAL BALL BEARING 6003 2RS (17x35x10) |
| 012 | 5.005.0049 | ROTOR SHAFT D.55 H.100 CYL. |
| 013 | 3.002.0115 | SCREW TCEI M5X35 TRILOBATE ZNT |
| 014 | 5.009.0166 | FRONT FLANGE ENGINE 110'96 PART |
| 015 | 3.201.0008 | OIL SEAL RING D.17X35X7 |
| 016 | 3.001.0030 | RADIAL BALL BEARING 6303 (17X47X14) |
| 017 | 4.005.0169 | PLATE 9'16 CYLINDRICAL HOLE PISTON D.12 |
| 018 | 3.001.0003 | EXT AXIAL BEARING RING AS4565 |
| 019 | 3.001.0025 | ROLLER CAGE TYPE AXK4565 - STEEL- |
| 020 | 4.007.0001 | EXT THRUST RING D.65x30x6 (C10Pb) FINISHED |
| 021 | 5.009.0452 | STOP/PISTON ASSEMBLY D.12 GROUND PARTNER |
| 022 | 3.200.0014 | OR SEAL 85x2.5 NITRILE |
| 023 | 4.007.0025 | PISTON RETURN SPRING D.23.8- 28.8 L=35 WIRE 2.5 C98 |
| 024 | 5.009.0516 | MICRO ASSEMBLY + CABLE TS MACH USA/EU |
| 025 | 4.006.0270 | TOTAL STOP CONNECTOR V.COMP.'02 |
| 026 | 4.006.0269 | BRASS SPACER FOR SPRING V.COMP.'03 |
| 027 | 4.007.0284 | ROD RETURN SPRING V.COMP.'02 Di7.3 L=11 WIRE D.1.3 |
| 028 | 3.200.0021 | OR SEAL 6.75x1.78 NBR SH.70 |
| 029 | 4.008.0782 | MICRO CONTROL ROD FOR NEW COMP. V. |
| 030 | 3.002.0267 | SCREW TSPEI M3x25 A2-70 AISI304 W/3M-SCOTCH-GRIP 2353 |
| 031 | 4.006.0272 | SEAL SEAT W/SPACER |
| 032 | 3.200.0113 | OR SEAL 15.08x2.62 NBR SH.70 |
| 033 | 4.007.0309 | SPRING TS V.COMP.'02 120V D.6.6 -10.2 L=22.2 WIRE D.1.8 |
| 034 | 4.006.0268 | PISTON DIAM.11 IN BRASS FOR V.COMP.'02 |
| 035 | 3.200.0059 | OR SEAL 7.66x1.78 NBR SH.82 |
| 036 | 4.608.0326 | ANTI-EXTRUSION RING DIM.8x11 x1.5 |
| 037 | 4.006.0273 | EXT PISTON SEAT AND CHECK VALVE |
| 038 | 3.200.0118 | OR SEAL 14x1.78 NBR SH.90 |
| 039 | 3.200.0029 | OR SEAL 18.72x2.62 SH.70 REF.3075 |
| 042 | 5.009.0503 | HOSE PORT SUCTION DETERG.M10 W/O-RING |
| 044 | 3.005.0001 | BALL D.5 STAINLESS STEEL 420 (precision grade G 500) |
| 045 | 4.007.0014 | EXT SPRING CHECK VALVE DETERG.De4, 5/6 L=7 WIRE D.0.3 STAINLESS STEEL |
| 046 | 4.005.0217 | GUIDE BODY D.12 COMP.VALVE'02 W/O WATER INLET REGULATION M20 |
| 048 | 5.609.0041 | EXT CHECK VALVE ASSEMBLY+OR |
| 049 | 4.007.0324 | EXT SPRING VALVE RETAINER D.4.8-6 L= 20 WIRE 0.6 STAINLESS STEEL |
| 051 | 5.009.0560 | INJECTION ASSEMBLY D.1.8 +OR |
| 052 | 3.200.0017 | OR SEAL 9.13x2.62 SH.70 REF.109 |
| 053 | 3.200.0013 | OR SEAL 11.1x1.78 REF.114 |
| 054 | 3.201.0014 | OIL SEAL RING D.12x20X5/7 |
| 055 | 3.002.0094 | TCEI SCREW M6X30 ZNT TRILOBATE |
| 056 | 5.009.0101 | SUCTION/DELIVERY VALVE CAP WITH MOUNTED OR |
| 057 | 5.009.0005 | SUCTION VALVE DELIVERY WORK 1 |
| 058 | 3.200.0019 | OR GASKET 12.42x1.78 SH.90 |
| 059 | 4.006.0109 | PLUG 1/8 GAS CONICAL |
| 062 | 3.200.0018 | OR GASKET 9.92x2.62 SH.90 |
| 064 | 4.008.0657 | OIL SEAL SPACER D.12 PARTNER |
| 065 | 4.006.0247 | SEAL SUPPORT RING PARTNER D.12 HIGH |
| 066 | 4.008.0695 | ANTI-EXTRUSION RING 12X18X1 FOR PARTNER D.12 |
| 067 | 3.201.0020 | WATER SEAL RING D.12X18X5 NBR SH.90 (SP2898N) |
| 068 | 5.009.0015 | COMPLETE SUCTION VALVE T OP |
| 069 | 4.005.0187 | HEAD PARTNER '01 FOR PISTONS D.12 FINISHED WORK |
| 070 | 3.002.0130 | TCEI SCREW M6X70 CL.12.9 UNI5931 DACROMET |
| 071 | 4.008.0031 | ORD FILTER SUCTION H2O D.16 CONICAL |
| 072 | 4.008.0376 | BOX LID ELECTRIC MOTOR '96 (X CONDENSER D.50) |
| 074 | 4.008.0356 | PARTNER ELECTRIC BOX '96 FOR INTER.WITH FRAME |
| 082 | 5.006.0216 | MOTOR '02 D110H100 230/50 2P WIRES THERMAL FOR FKX |
| 083 | 5.007.0166 | GUIDE BODY PIST. D.12 +IN.1.7 W/REG.TS ING.M20 X 110h100 |
| 084 | 5.008.0160 | PARTNER HEAD D.12 W/IND. |
| 087 | 3.406.0011 | RING FOR PG.11 ANTI-TEAR |
| Pag.2 | ||
| 001 | 4.008.0789 | TIGER-MACH PIPE SUPPORT |
| 002 | 4.013.0305 | FKX -G- UPPER FAIRING PANT.108C INJECTION |
| 003 | 6.005.0148 | 135 BLACK TANK FKX KIT W/CAP |
| 004 | 4.008.0867 | HYDRO RIO HANDLE |
| 005 | 4.008.0751 | FKX DIESEL TANK CAP 1 1/4 G |
| 006 | 4.012.0150 | H05VV-F CABLE 3X1.5 MT.5.4 SCHUKO ANTI-SPLASH F/F |
| 007 | 6.005.0190 | EXT 176 WHEELS + STUDS FOR RIO |
| 008 | 4.008.0868 | RIO NEUTRAL DETERGENT TANK |
| 009 | 4.008.0869 | HOLDER FOR HYDRO RIO |
| 010 | 3.700.0036 | EXT S'02C GUN 3/8'-M22 |
| 011 | 4.618.0049 | EXT R1 PIPE 1/4 21MPa L=8000 3/8F GIR.-M22x1.5 W/SLEEVE |
| 012 | 3.712.0018 | EXT LANCIA S/COVER A/B 1.15 -G- M22 HOT (MAX 220BAR 3200PSI) |
| 013 | 5.012.0165 | HOSE HOLDER KIT + HANDLE SCREWS/ACCESS HOLDER + CAP + RIO NEEDLE |
| Pag.3 | ||
| 001 | 4.007.0183 | NUT FOR NOZZLE HOLDER PIN FOR J ET FIRE '98 |
| 002 | 3.100.0075 | CONNECTOR M 1/8 CONICAL F D.4 CURVED COD.E2L39C02 |
| 003 | 4.012.0102 | MOTOR CABLE BRUSH L=850 SEC.0.75 IEC227-3/1979 W/O FAST. |
| 004 | 4.608.0145 | OIL DELIVERY PIPE RILSAN PARANA' L=540 |
| 005 | 4.005.0194 | COVER FOR FKX BOILER (DIE-CAST) |
| 006 | 4.007.0303 | PIPE D.40 L=325 FE 37 PRE-ZINC-COATED |
| 007 | 4.008.1169 | ELECTRIC BOX COVER FKX PAINTED SILVER RAL.9006 MET. |
| 008 | 5.009.0213 | EXT SWITCH ASSEMBLY 0/1 BIP. 12(10)A + TRANSPARENT PROTECTION |
| 009 | 3.002.0106 | SELF-FIXING SCREW TC-TC 3.9X16 UNI 6954 ZNT |
| 010 | 3.404.0017 | CAPACITOR 25mF 450V D.39X94 F/M |
| 011 | 3.004.0002 | FLAT WASHER 4.3X9 Thickness 0.8 ZNT UNI6592 |
| 012 | 3.405.0011 | TERMINAL BLOCK PA 32/6 |
| 013 | 4.008.0127 | MULTIPLE CABLE GLAND ELECTRICAL BOX FIRE |
| 014 | 4.008.0446 | FKX ELECTRICAL BOX BASE |
| 015 | 3.403.0012 | ELECTRICAL BOARD 230/50 FKX |
| 016 | 3.002.0132 | SELF-SHAPING SCREW TC-TC 3.5X9.5 UNI 6954 ZNT |
| 017 | 3.002.0080 | T.C. SCREW M4X12 TRILOBED CUT. CR. ZNT |
| 018 | 3.004.0003 | ELECTRIC TOOTHED ROUND.EX.D.4X8 Sp0.5 OF N6798A ZNT |
| 019 | 4.008.0470 | FAN MOTOR COVER FKX |
| 020 | 4.007.0180 | TIE ROD FOR FIRE '98 BOILER M6X352 ZNT |
| 021 | 3.004.0010 | ELECTRIC TOOTHED ROUND.EX.D6X11 Sp0.7 OF N6798A ZNT |
| 022 | 3.003.0011 | NUT E. M6 MEDIUM UNI 5588 CL8 ZNT |
| 023 | 3.304.0056 | MOTOR FOR BURNER 230/50 COMP. OF FAN, FLANGE, CABLES, COVER (FKX) |
| 024 | 4.008.0658 | HEAT-RESISTANT FELT BOTTOM (FKX/PARANA') |
| 025 | 4.008.0450 | HEAT-RESISTANT RIGID BOTTOM (FKX) |
| 026 | 4.007.0158 | BOILER BOTTOM FOR NUOVA FIRE |
| 027 | 4.007.0200 | WASHER 20.2X26X3 Fe37 |
| 028 | 6.005.0319 | FITTING FOR COIL WITH HOSE CONNECTOR |
| 029 | 5.609.0260 | SAFETY VALVE G1/8 M D6 200BAR MTM (00036020) |
| 030 | 4.005.0186 | BOILER BASE FKX (DIESEL CAST) |
| 031 | 4.007.0185 | SPACER FOR FIXING CLAMP FOR JET FIRE PUMP '98 |
| 032 | 3.004.0026 | FLAT WASHER D.4.3X12 ZNT UNI6593 |
| 033 | 3.002.0179 | SELF-TAP SCREW TC-TC 3.9X50 ZNT |
| 034 | 5.009.0686 | EXT TRANSF. ACC. 230-240/50-60 W/PIPETTE FKX-PARANA' + CABLE |
| 035 | 5.611.0100 | HIGH VOLTAGE CABLE L=280 W/PROT EZ.X TRK1 ELECTRONIC |
| 036 | 4.008.0459 | RUBBER CAP FOR FKX TRANSFORMER (SILICONE) |
| 037 | 4.006.0187 | NOZZLE HOLDER PIN FOR FKX BOILER |
| 038 | 6.005.0307 | EXT DIESEL NOZZLE 0.60 60 H MONEL FILTER (HAGO) |
| 039 | 3.099.0296 | FKX DEFLECTOR WITHOUT ELECTRODES |
| 040 | 5.013.0027 | MOUTHPIECE HOLDER DISC FOR FKX |
| 041 | 4.604.0011 | COIL D.202 L=15mt FOR NUOVA FIRE |
| 042 | 5.013.0050 | RIO BOILER BODY W/PAINTED SHELF |
| 043 | 5.009.0304 | PRESSURE REGULATION VALVE ASSEMBLY FOR ULKA PUMP (SPRING L=20) |
| 044 | 4.008.0465 | EXT BLACK PVC PIPE ANTI-FUEL D.9X6 L=280 |
| 045 | 3.002.0146 | TCEI SCREW 4X35 TRILOBATE ZNT |
| 046 | 3.099.0110 | CLAMP D.12 CLAMP PAS 012 FOR GAS PUMP FIXING (W/SCREW) |
| 047 | 3.551.0014 | ULKA EP 5 48W 230/50 DIESEL PUMP W/OR R4 VITON |
| 048 | 5.611.0043 | EXT FKX/RIO DIESEL FILTER GROUP (nylon filter) |
| 049 | 3.411.0001 | ELECTRIC GLASS TUBE Di.4 (VSM 040) |
| 050 | 4.608.0038 | RUBBER PROTECTION FOR FIRE THERMAL |
| 051 | 3.403.0003 | THERMAL PROTECTOR L01.080.05. UL CABLES L=1200 |
| 052 | 4.606.0002 | FLOW CONNECTOR WITH HOLE FOR THERMAL |
| 053 | 4.007.0322 | PIPE FOR DELIVERY SLEEVE FKX L=42 |
| 054 | 4.008.0449 | SOFT HEAT-RESISTANT SLEEVE 31X56 th.3 FKX |
| 055 | 5.001.0824 | MOTOP.PT'02 110h100 230/50 D.1 2 9'16 TS IN.1,7 (X FKX) |
| 056 | 4.006.0181 | WATER INLET SPACER FKX /PARANA' |
| 058 | 4.008.0503 | HEAT-RESISTANT CERAMIC FIBER BAND 120X635 th.4 |
| 060 | 4.007.0256 | SHAPED SUPPORT FOOT FKX |
| 061 | 4.008.0748 | BOILER CLOSING LID FOR FKX REGULATION |
| 062 | 4.008.0749 | AIR REGULATION BUTTERFLY FOR FKX |
