Lavor Original Parts for Pressure Cleaner FUEGO 1007 - 8.052.0818
€14.85
Tax included
Lavor Original Parts for Pressure Cleaner FUEGO 1007 - 8.052.0818
Lavor original spare parts for to replace broken parts for to fix Hot Water High Pressure Cleaner FUEGO 1007 230/50 TS- GR - 8.052.0818Fix Your Pressure Cleaner FUEGO 1007. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner FUEGO 1007 - 8.052.0818
Fix Your Hot Water High Pressure Cleaner FUEGO 1007 230/50 TS- GR - 8.052.0818. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee
In the following tables, look for the spare part and its respective code.
| Lavorwash Pressure Cleaner FUEGO 1007 230/50 TS- GR - 8.052.0818 | ||
| BOLIER Pag.1 | ||
| # | Part Num. | Description |
| 001 | 4.007.0183 | NUT FOR PIN NOZZLE HOLDER |
| 002 | 3.100.0075 | CONIC CONNECTION M 1/8 F D.4 CURVED FOR GASOIL HOSE VITON O- RING |
| 003 | 4.012.0102 | CABLE L=600 SEC.0,75 IEC227-3/1979 |
| 004 | 4.608.0145 | RILSAN GASOIL HOSE X PARANA' L =500 |
| 005 | 4.005.0194 | BOILER COVER FKX |
| 006 | 4.007.0303 | TUBE D.40 L=325 FE 37 PREZINCE D |
| 007 | 4.008.0447 | ELECTRICAL BOX COVER |
| 008 | 5.009.0213 | SWITCH WITH PROTECTION 12(10) |
| 011 | 3.004.0002 | PLAIN WASHER 4.3X9X0.8 UNI6592 |
| 012 | 3.405.0011 | TERMINAL BOARD PA 32/6 |
| 013 | 4.008.0127 | CABLE HOLDER FOR ELECTRICAL BO X |
| 014 | 4.008.0446 | ELECTRICAL BOX BASE |
| 015 | 3.403.0012 | ELECTRICAL BOARD |
| 019 | 4.008.0470 | FAN MOTOR COVER |
| 020 | 4.007.0180 | BOILER STAY M6X352 |
| 021 | 3.004.0010 | WASHER D6X11 Sp0,7 DIN6798A ZN T |
| 022 | 3.003.0011 | NUT M6 UNI 5588 |
| 023 | 3.304.0056 | BURNER MOTOR 230/50 C/W FAN, FLANGE, CABLES AND COVER |
| 024 | 4.008.0658 | THERMORESISTANT FELT BOTTOM PL ATE X FKX/PARANA' |
| 025 | 4.008.0450 | THERMORESISTANT PAD |
| 026 | 4.007.0158 | BOILER PAD |
| 027 | 4.007.0200 | WASHER20.2X26X3 |
| 028 | 6.005.0319 | JUNCTION |
| 029 | 5.609.0260 | SECURITY VALVE G1/8 M D6 200BAR MTM 00036021 |
| 030 | 4.005.0186 | BOILER BASE PLATE X FKX (LIKE DIE CASTING ) |
| 031 | 4.007.0185 | SPACER FOR FIXING CLAMP |
| 034 | 6.605.0275 | CLA IGNITION TRANSFORMER WITH CABLES |
| 035 | 5.611.0100 | HIGH VOLTAGE CABLE WITH PROTEC TION X ELECTRON.TRK1 (L=280) |
| 036 | 4.008.0459 | TRANSFORMER CAP |
| 037 | 4.006.0187 | NOZZLE HOLDER PIN |
| 038 | 3.104.0008 | DIESEL NOZZLE 0.60 60/A MONEL FILTER |
| 039 | 6.005.0307 | COMPLETE ELECTRODE DEFLECTORDI D.2 FKX |
| 040 | 5.013.0027 | DISK HEAD HOLDER |
| 041 | 4.604.0011 | COIL D.202 |
| 042 | 5.013.0050 | BODY BOILER |
| 043 | 5.009.0304 | ADJUSTING VALVE SET (SPRING L=20) |
| 046 | 3.099.0110 | D.12 CLAMP |
| 047 | 3.551.0014 | DIESEL PUMP |
| 048 | 5.611.0043 | DIESEL FILTER ASS'Y |
| 049 | 3.411.0001 | ELECTROLYTIC PIPE D.4 |
| 050 | 4.608.0038 | RUBBER PROTECTION FOR THERMIC |
| 051 | 3.403.0003 | THERMAL PROTECTOR L01.090.05.7 00 |
| 052 | 4.606.0002 | DELIVERY CONNECTION |
| 053 | 4.007.0322 | TUBE FKX L=42 |
| 054 | 4.008.0449 | THERMORESISTANT COUPLING BOW 17X23XL40 |
| 055 | 5.001.I763C | MOTORPUMP PT'03 230/50 COMP.VALVE 7'10 TS WITH SUCTION SPRING 13KG(8850) |
| 056 | 5.009.0611 | INLET JOINT WITH GASKET |
| 058 | 4.008.0503 | BAND IN CERAMIC FIBER |
| 060 | 4.007.0256 | BASE FKX |
| 061 | 5.009.0637 | BOILER CAP KIT |
| CHASSIS Pag.2 | ||
| 001 | 7.101.6614 | FUEGO STICKER 267X265 4C DX |
| 002 | 4.013.0479 | UPPER GREY PLASTIC COVER |
| 003 | 4.007.0382 | HANDLE |
| 004 | 4.007.0383 | PLATE FOR HANDLE |
| 005 | 6.005.0650 | BLACK DIESEL-DETER. TANK X FKX |
| 006 | 4.008.0789 | HOSE REEL TIGER |
| 007 | 7.101.6615 | FUEGO STICKER 267x265 4C SX |
| 011 | 4.608.0180 | TANK CAP |
| 012 | 4.012.0149 | CABLE H05VV-F 3X1 MT.5,4 SCHUKO PLUG F/F |
| 014 | 6.005.0190 | WHEEL KIT |
| 016 | 3.099.0120 | PLASTIC PLUG FOR TANK |
| 017 | 3.700.0036 | HP SPRAY GUN S'02 3/8' |
| 018 | 4.618.0049 | HOSE R1 1/4 8MT 3/8F-M22 (MAX 21MPa) |
| 019 | 3.712.0022 | LANCE A/B 1.10 M22 |
| 020 | 3.100.0062 | QUICK COUPLING WITH VALVE (3029) |
| 021 | 7.100.1726 | INSTRUCTION MANUAL |
| MOTOR + PUMP Pag.3 | ||
| 000 | 5.001.I763C | MOTORPUMP PT'03 230/50 COMP.VALVE 7'10 TS WITH SUCTION SPRING 13KG(8850) |
| 001 | 5.009.0924 | BRUSH MOTOR '03 230/50 WITH CAPACITOR (8850) |
| 002 | 6.005.0180 | KIT 166 FOOTSTEP BEARING 3047 PT' 03-SD |
| 003 | 4.007.0205 | PIN 10X70 |
| 004 | 5.009.0657 | 7'30 PLATE ASSEMBLY W/CROWN Z 50 |
| 005 | 4.007.0328 | THRUST BEARING 35X55X12 PT'03 |
| 006 | 6.005.0181 | KIT 167 LW PISTON |
| 009 | 6.005.0226 | KIT 209 O-RING |
| 010 | 6.005.0183 | KIT 169 LW INJECTOR 1,7 |
| 011 | 6.005.0184 | KIT 170 LW HEAD VALVE KIT |
| 012 | 4.005.0210 | '03 PARTNER HEAD |
| 013 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 014 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
| 015 | 6.005.0134 | KIT 125 O-RING SEAL |
| 017 | 4.005.0211 | PISTON BODY GUIDE PT'03 WITH HOLE FOR SUCTION |
| 018 | 5.009.0716 | COMPLETED VALVE TS PT'03 CABLE L=510 SPRING 13KG |
| 019 | 5.007.0187C | BODY GUIDE PT'03 PISTONS D.12 W/ASS,DETERG.SUCTION |
| 020 | 5.008.0182C | '03 PARTNER HEAD D.12 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor FUEGO 1007 - 8.052.0818
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
