Lavor Original Parts for Pressure Cleaner Tomcat
€120.09
Tax included
Lavor Original Parts for Pressure Cleaner Tomcat
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner 80680614 - Idro TOMCAT 220-240/50-60 -G/N- TS EU 2L (20L) LWS.Fix Your Pressure Cleaner. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner Tomcat
Fix Your Cold Water High Pressure Cleaner 80680614 - Idro TOMCAT 220-240/50-60 -G/N- TS EU 2L (20L) LWS. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| 80680614 - IDRO TOMCAT 220-240/50-60 -G/N- TS EU 2L (20L) LWS pag.1 | ||
| # | Part Num. | Description |
| . | R50010717C | MOTOP.SPAZZ.PT'03EVO 230/50 4'45 TS MOLLA 13KG (7630PF-ALL) -C- |
| . | RW8000SE03 | WIRING DIAGRAM |
| 000 | 5.001.I841C | MOTORPUMP PT'03EVO 230/50 TS 4'45 (7630PF-AL) |
| 001 | 4.008.1132 | HANDLE |
| 002 | 4.013.0553 | LEFT+RIGHT COVER |
| 003 | 5.009.0213 | SWITCH WITH PROTECTION 12(10) |
| 004 | 4.008.0791 | BLACK WHEEL FOR TIGER |
| 005 | 4.012.0174 | CABLE H05VV-F 2X1 MT.5,4 F/F SCHUKO PLUG |
| 007 | 4.008.0031 | INLET WATER FILTER H2O D.16 CONICAL |
| 008 | 7.102.0449 | STICKER 'MADE IN ITALY' 37X48mm 3C (PVC) |
| 009 | 6.001.0076 | GUN S'09 WITH INTEGRAL QUICK JOINT LAVOR |
| 010 | 7.100.1468 | MANUALE GENERALE IDRO HOBBY 20L A5 96F |
| 011 | 4.008.1172 | AIR CONVEYOR FOR U76 |
| 012 | 4.018.0094 | HOSE 1/4 180BAR L=4000 M22x1,5 D.15-RAPID FIX W/SPIRAL SLEEVE |
| 014 | 4.008.1139 | COPERTURA ESTETICA WASHER -G- C/TAMP.TOMCAT LAVOR (P80.0434) |
| 016 | 6.002.0340 | LANCE S'12 WITHOUT NOZZLE HEAD WITH QUICK COUPLING/COGETIL |
| 016 | 6.002.0341 | NOZZLE HEAD LANCE S'12 D.0,9 (PINK) W/QUICK COUPLING (FIXED FAN JET) |
| 017 | 6.002.0346 | ROTOX NOZZLE HEAD LANCE S'12 D.1,025 WITH QUICK COUPLING |
| 80680614 - IDRO TOMCAT 220-240/50-60 -G/N- TS EU 2L (20L) LWS pag.2 | ||
| . | R50090837C | GRUPPO C.GUIDA C/TS 13KG +TESTATA (PT'03EVO) |
| 001 | 5.009.0821 | ASSEMBLY MOTOR PT'03 230/50 WITH CAPACITOR (U7630PF-ALL) |
| 002 | 6.005.0311 | THRUST RING KIT (PT'03 U76) |
| 003 | 4.007.0205 | PIN 10X70 |
| 004 | 5.009.0728 | 4'45 WOBBLE PLATE ASSEMBLY W/CROWN Z 62 (PT'03) |
| 005 | 4.007.0328 | THRUST BEARING 35X55X12 PT'03 |
| 006 | 5.009.0837C | BODY GUIDE+HEAD ASSEMBLED TS WITHOUT SUCTION (SPRING 13KG) - PT'03EVO- |
| 80680614 - IDRO TOMCAT 220-240/50-60 -G/N- TS EU 2L (20L) LWS pag.3 | ||
| . | R50070248 | CORPO GUIDA PT'03EVO PIST.D.12 C/TS-VALV.COMP. S/ASP. MOLLA 13KG |
| .. | R50080261 | TESTATA PT'03EVO D.12 |
| 001 | 5.007.0248 | BODY GUIDE ASSEMBLED PT'03EVO WITH TS/COMP.VALVE WITHOUT SUCTION S.13KG |
| 002 | 6.005.0282 | KIT 348 SPACER FOR WATER SEAL |
| 003 | 5.008.0261 | PT'03EVO HEAD D.12 |
| 80680614 - IDRO TOMCAT 220-240/50-60 -G/N- TS EU 2L (20L) LWS pag.4 | ||
| 001 | 4.005.0299 | PISTON BODY GUIDE PT'03EVO |
| 002 | 5.009.0716 | COMPLETED VALVE TS PT'03 CABLE L=530 SPRING 13KG (WHITE FASTON COVER) |
| 003 | 6.005.0181 | KIT 167 LW PISTON |
| 004 | 6.005.0226 | KIT 209 O-RING |
| 005 | 6.005.0281 | KIT 256 VALVE GUIDE RID. W/O SUCTION PT'03C |
| 006 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 007 | 4.007.0314 | PIN 3,5x30 ZNT |
| 80680614 - IDRO TOMCAT 220-240/50-60 -G/N- TS EU 2L (20L) LWS pag.5 | ||
| 001 | 4.005.0298 | PT''03EVO PARTNER HEAD |
| 002 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
| 003 | 6.005.0588 | KIT LW VALV.ASP./MAND.+TAPPI PT' 03EVO |
