Femi Spare Parts for Stationary Band Saws N251DA XL - 8488050

€2.37
Tax included

Femi Spare Parts for Stationary Band Saws N251DA XL - 8488050

Distribution and Sale at attractive prices of FEMI Original Spare Parts. Low prices and a professional Assistance guarantee, repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Stationary Band Saw N251DA XL - 8488050.
ITEM CODE: 0100116
Quantity
Usually Ships in: 10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Femi Spare Parts for Stationary Band Saws N251DA XL - 8488050

Distribution and Sale at attractive prices of FEMI Original Spare Parts. Low prices and a professional Assistance guarantee, repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Stationary Band Saw N251DA XL - 8488050.

In the following table, look for the model of the Band Saw and the respective parts of the code.
Femi N251DA XL - 8488050
Stationary Band Saws N251DA XL - 8488050
# Part Num. Description
1 5142108 RELEASE LEVER
2 5100157 LEVER NUT
3 5063070 BUSHING
5 5133801 TANK BASE
6 7113533 ELECTRIC PUMP
7 5130983 VICE PLATE
8 5138084 SUPPORT
9 5133802 TANK EXTENSION
10 5064030 SUPPORT FLAT BEARING
11 5133803 SWIVEL SUPPORT
12 5402759 GRADUATE PLATE
13 5100349 SUPPORT PIN
14 5100158 NUT
15 5124092 PLASTIC WASHER
16 5182592 BEARING COVER
17 0551203 BALL BEARING
20 5182593 TANK COVER
21 7130729 BAR-STOP ROD GROUP
23 5159523 INDEX
24 5100350 VICE SCREW
25 0601629 BALL BEARING
26 5102140 VICE SPRING
27 5063071 BUSHING
28 5142109 LOCKING LEVER
29 0551406 BALL BEARING
30 5182594 BEARING COVER
31 0140117 VICE HANDWHEEL
32 0144005 VICE HANDLE KNOB
33 5042905 VICE BASE
34 5152629 VICE JAW
35 5130984 MOBILE VICE
37 7241007 DOWN FEED HYDRAULIC ASSY
38 0147030 LEVER
40 5181909 PROTECTION
41 5133804 PIVOT SUPPORT
42 0144006 PANEL HANDLE
43 5133805 PANEL SUPPORT
45 0155158 PULLEY STOP RING
46 0606205 BALL BEARING
47 5214239 FREE WHEEL
48 0606205 BALL BEARING
49 5001579 PULLEY SHAFT
50 5100351 PULLEY SCREW
51 5124093 PULLEY WASHER
52 5214040 DRIVING WHEEL
53 5152630 BLADE GUIDE SUPPORT
54 5130985 BLADE GUIDE FIXING
55 5100352 SUPPORT PIN
56 5130986 SWITCH SUPPORT
57 0801213 SAFETY SWITCH
58 5080183 SPRING
59 5100353 SPRING PIN
60 0140118 SPRING KNOB
61 0526207 BALL BEARING
62 7801859 MOTOR
63 5112035 MOTOR FAN
64 5182940 MOTOR FAN COVER
66 0241466 PIPE FITTING
67 1725809 COOLANT TUBE
68 0801214 SAFETY SWITCH
69 0140119 MICROSWITCH KEY
70 5181902 BLADE PROTECTION
74 5130987 BLADE TENSIONONG PLATE
75 0100116 NUT
76 5173038 TENSIONING ROD
78 5080184 SPRING KIT
79 0241002 PRESSURE INDICATOR
80 0711831 CAGE BEARING
81 0140120 COMPLETE TENSIONING HANDLE
83 5142110 LEVER
84 0140121 HANDLE
85 5133806 COLUMN STAND
86 5181903 COLUMN PANEL
88 0600608 BALL BEARING
89 5100094 ADJUSTING SCREW
90 5100095 BEARING SCREW
91 5100354 PIN
92 5130988 BLADE GUIDE SUPPORT
93 0140122 BLADE GUIDE KNOB
94 5181904 FRONT GUIDE PROTECTION
95 5130989 FRONT BLADE SUPPORT
96 0240311 TAP
97 3236111 CLEANING BRUSH
98 5181905 BRUSH PROTECTION
99 5181906 BLADE CLEAN PROTECTION
100 5130990 REAR BLADE GUIDE SUPPORT
113 5002058 SHAFT
114 0150155 FEATHER
115 0150156 FEATHER
128 5130991 LOWER TENSIONING PLATE
130 5042906 SAW ARM
131 5130992 MICRO SWITCH SUPPORT
134 0802328 SWITCH
135 5181908 FRONT BEARING PROTECTION
137 5181910 PULLEY PROTECTION
138 7132541 FRONT COMPLETE BLADE GUIDE
139 7132542 REAR COMPLETE BLADE GUIDE
140 7211006 REDUCTOR
T01 0810024 CONTACTOR
T02 0810025 THERMIC SWITCH
T05 0820017 COMMUTATOR
T06 0840211 TRANSFORMER
T07 0892111 FUSE SUPPORT
T09 0806030 EMERGENCY BUTTON
T10 0806031 SWITCH-OFF BUTTON
T11 0806032 SWITCH-ON BUTTON
T12 0820018 SPEED COMMUTATOR
T14 0894018 TENSION LIGHT INDICATOR
500 3280045 PACKAGING N°5 BLADE 27x0,9x2480 Z 10/14
501 3280044 PACKAGING N°5 BLADE 27x0,9x2480 Z 6/10
502 3280043 PACKAGING N°1 BLADE 27x0,9x2480 Z 10/14
503 3280042 PACKAGING N°1 BLADE 27x0,9x2480 Z 6/10
504 3280041 PACKAGING N°5 BLADE 27x0,9x2480 Z 4/6
505 3280040 PACKAGING N°5 BLADE 27x0,9x2480 Z 8/12
506 3280039 PACKAGING N°1 BLADE 27x0,9x2480 Z 4/6
507 3280038 PACKAGING N°1 BLADE 27x0,9x2480 Z 8/12
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi N251DA XL - 8488050
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM CODE OR S/N FEMI:
FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS
New

Download

Diagram Femi N251DA XL - 8488050

Diagram Femi N251DA XL - 8488050

Download (297.4KB)
