Milwaukee AGV 24-230 GE DMS Angle Grinder Spare Parts
Fix Your Milwaukee AGV 24-230 GE DMS 230 mm. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Milwaukee AGV 24-230 GE DMS Angle Grinder Spare Parts
Fix Your Milwaukee AGV 24-230 GE DMS 230 mm. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Drill Driver and their spare part.
| AGV24-230GE/DMS ANGLE GRINDER IN2 PARTS 4933402520 - AGV24-230GE DMS - 4000402669 |
||
| Pag.1 | ||
| # | Part Num | Description |
| 4 | 4931455392 | CONNECTION CABLE |
| 5 | 4931387206 | PROTECTING COVER |
| 6 | 4931622765 | SCREW N874101-1 SHR C-K5X45/20 KOMBITORX |
| 10 | 4931476759 | RATING PLATE |
| 100 | 4931402268 | MOTOR HOUSING |
| 103 | 4931402176 | SWITCH HANDLE |
| 106 | 4931442695 | ARMATURE |
| 107 | 4931334394 | FAN |
| 108 | 4931341741 | BALL BEARING |
| 109 | 4931329086 | RUBBER SLEEVE |
| 110 | 4931402219 | SEAL RING |
| 114 | 4931402269 | AIR DEFLECTOR RING |
| 116 | 4931381694 | BRUSH HOLDER |
| 117 | 4931402169 | COVER |
| 118 | 4931624538 | SCREW |
| 119 | 4931331734 | SCREW |
| 121 | 4931619992 | SPRING WASHER D 137 B 4 |
| 126 | 4931624537 | SCREW |
| 131 | 4931369479 | CARBON BRUSH SET |
| 141 | 4931329273 | CABLE COLLAR |
| 143 | 4931624537 | SCREW |
| 144 | 4931618253 | SCREW |
| 147 | 4931402013 | DUST SEAL |
| 149 | 4931455265 | DAMPER |
| 152 | 4931402039 | PRESSURE SPRING |
| 154 | 4931402029 | SPRING WASHER |
| 156 | 4931402286 | DUST SEAL |
| 200 | 4931402161 | GEAR BOX |
| 201 | 4931621981 | SLEEVE |
| 202 | 4931621629 | DISC N874237 22,5X35X0,3 |
| 204 | 4931624305 | BALL BEARING |
| 205 | 4931622897 | DISC |
| 206 | 4931334400 | LOCKING RING |
| 209 | 4931402166 | LOCKING BOLT |
| 210 | 4931329173 | PRESSURE SPRING |
| 212 | 4931622764 | O-RING |
| 216 | 4931402546 | DRIVE GEAR |
| 218 | 4931407540 | GEAR ENDPLATE |
| 219 | 4931624672 | SEAL RING |
| 220 | 9170316990 | BEARING |
| 223 | 4931402150 | BEARING COVER |
| 224 | 4931624147 | SCREW D 7500 M 3X12 |
| 225 | 4931279734 | RUBBER SLEEVE |
| 226 | 4931329178 | GREASE RETAIN.DISC |
| 227 | 4931329494 | NUT |
| 228 | 4931409592 | BEVEL GEAR PAIR |
| 230 | 4931624147 | SCREW D 7500 M 3X12 |
| 232 | 4931409816 | SPINDLE |
| 235 | 4931623312 | WASHER N874237 |
| 236 | 4931624701 | DISC |
| 237 | 4931622747 | COMPENSATING WASHER |
| 238 | 4931624591 | WASHER |
| 239 | 4931941094 | DISC N874237 18X27,9X0,5 |
| 242 | 4931329150 | GASKET |
| 400 | 4931476901 | REPAIR KIT |
| 500 | 4931428099 | CUTTING GUARD |
| 600 | 4931426625 | GUARD CAP |
| 601 | 201256002 | CATCH LEVER |
| 602 | 4931402063 | FLANGE |
| 603 | 4931402089 | PRESSURE SPRING |
| 604 | 4931624491 | SCREW |
| 703 | 4931398251 | HANDLE |
| 714 | 4931402435 | AUTOBALANCER |
| Accessories Pag.2 | ||
| 702 | 4932367712 | PIN SPANNER 115-230/WP/WSAP1 A/M |
| 711 | 4932345628 | FLANGE NUT M14 3MM P1 A/M |
